JVC Serial No. - Selecting a Preset Sound Mode

ENGLISH
12
Selecting a preset sound mode
You can select a preset sound mode suitable to the music genre.
• See also page 14.
Preset value setting for each sound mode
Sound
mode
Preset value
BASS MIDDLE TREBLE LOUD
(loudness)
Freq. Level Q Freq. Level Q Freq. Level Q
USER 60 Hz 00 Q1.25 1.0 kHz 00 Q1.0 10.0 kHz 00 —
OFF
ROCK 100 Hz +03 Q1.0 1.0 kHz 00 Q1.25 10.0 kHz +02 —
CLASSIC 80 Hz +01 Q1.25 1.0 kHz 00 Q1.25 10.0 kHz +03 —
POPS 100 Hz +02 Q1.25 1.0 kHz +01 Q1.25 10.0 kHz +02 —
HIP HOP 60 Hz +04 Q1.0 1.0 kHz –02 Q1.0 10.0 kHz +01 —
JAZZ 80 Hz +03 Q1.25 1.0 kHz 00 Q1.25 10.0 kHz +03 —
Freq.: Frequency Q: Q-slope
Storing your own sound mode
You can store your own adjustments in memory.
1 Select “USER” for “EQ.”
or
2 While “USER” is shown on the display...
[Turn] = [Press]
[Turn] = [Press]
Selecting from Menu.
• See below and page 13 for “USER” settings.
