JVC SP-AD70-A

10
Product Overview
Left Side ViewFront View
1. Speakers
2. Hand Strap
A hand strap is designed for easy carrying.
1. Jack Cover
2. AUX socket
3. RESET button
4. 5V IN Micro-USB Socket
Open the jack cover
at the left side of
the unit for the
connector panel
shown on left.
5V IN
RESET
AUX
1
4 3 2
The hand strap is not for hanging the unit.
1 2
