JVC SP-DW103 Service Manual

SP-DW103
3-7
C1028 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1029 NCS31HJ-470X C CAPACITOR 47pF 50V J
C1030 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1031 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1032 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1033 QEKC1CM-106Z E CAPACITOR 10uF 16V M
C1034 QEKC1CM-106Z E CAPACITOR 10uF 16V M
C1035 QFN31HJ-153Z M CAPACITOR 0.015uF 50V J
C1036 QFVJ1HJ-124Z MF CAPACITOR 0.12uF 50V J
C1037 NCB31HK-332X C CAPACITOR 3300pF 50V K
C1038 QFVJ1HJ-684Z MF CAPACITOR 0.68uF 50V J
C1039 QFVJ1HJ-684Z MF CAPACITOR 0.68uF 50V J
C1501 QTE1V06-106Z E CAPACITOR 10uF 35V
C1502 QFN31HJ-332Z M CAPACITOR 3300pF 50V J
C5001 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5002 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5003 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5004 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5005 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5006 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5007 NCS31HJ-471X C CAPACITOR 470pF 50V J
C5008 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C5009 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5010 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5011 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C5012 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5013 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C5014 NCS31HJ-681X C CAPACITOR 680pF 50V J
C5015 NCS31HJ-470X C CAPACITOR 47pF 50V J
C5016 NCS31HJ-560X C CAPACITOR 56pF 50V J
C5017 NCS31HJ-560X C CAPACITOR 56pF 50V J
C5018 NCB11EK-224X C CAPACITOR 0.22uF 25V K
C5019 NCB11EK-684X C CAPACITOR 0.68uF 25V K
C5020 QTE1V06-106Z E CAPACITOR 10uF 35V
C5021 QFV72AJ-224Z MF CAPACITOR 0.22uF 100V J
C5022 QFG32AJ-392Z PP CAPACITOR 3900pF 100V J
C5023 QENC1HM-225Z BP E CAPACITOR 2.2uF 50V M
C5024 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C5025 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C5026 QETN2AM-475Z E CAPACITOR 4.7uF 100V M
C5702 QETN1VM-227Z E CAPACITOR 220uF 35V M
C5703 QER61CM-476Z E CAPACITOR 47uF 16V M
C5704 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5705 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5706 NCB11AK-335X C CAPACITOR 3.3uF 10V K
C5707 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5708 NCB11AK-335X C CAPACITOR 3.3uF 10V K
C5709 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C5710 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C5711 NCB11EK-224X C CAPACITOR 0.22uF 25V K
C5901 QFV72AJ-104Z MF CAPACITOR 0.1uF 100V J
C5902 QFV72AJ-104Z MF CAPACITOR 0.1uF 100V J
C5903 QEHR1HM-227Z E CAPACITOR 220uF 50V M
C5904 QEHR1HM-227Z E CAPACITOR 220uF 50V M
C5905 QER61EM-475Z E CAPACITOR 4.7uF 25V M
C5906 QER61EM-476Z E CAPACITOR 47uF 25V M
C5907 NCS31HJ-221X C CAPACITOR 220pF 50V J
C5908 NCS31HJ-221X C CAPACITOR 220pF 50V J
C5909 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C5910 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C5911 QEHR1EM-107Z E CAPACITOR 100uF 25V M
C5912 QEHR1EM-107Z E CAPACITOR 100uF 25V M
C5913 QERF1CM-106Z E CAPACITOR 10uF 16V M
C5914 QERF1CM-106Z E CAPACITOR 10uF 16V M
C5915 QTE1E51-106Z E CAPACITOR 10uF 25V
C5916 QTE1E51-106Z E CAPACITOR 10uF 25V
C5917 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C5918 NCB31HK-183X C CAPACITOR 0.018uF 50V K
 C9001 QFZ9075-224 MPP CAPACITOR 0.22uF AC275V M
 C9002 QFZ9075-104 MPP CAPACITOR 0.1uF AC275V M
 C9003 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C9004 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C9005 QFZ9075-103 MPP CAPACITOR 0.01uF AC275V M
 C9501 QEZ0603-227 E CAPACITOR 220uF
C9502 QCZ0366-102 C CAPACITOR 1000pF
C9503 NCB31HK-471X C CAPACITOR 470pF 50V K
C9504 QETN1VM-107Z E CAPACITOR 100uF 35V M

Symbol
No.
Part No. Part Name Description Local
C9505 NCB31HK-471X C CAPACITOR 470pF 50V K
C9506 QFKB2JK-103 MM CAPACITOR 0.01uF 630V K
C9507 QCZ0213-472 C CAPACITOR 4700pF 1kV K
C9508 QCZ0213-472 C CAPACITOR 4700pF 1kV K
C9509 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C9510 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C9511 QEHQ1HM-228 E CAPACITOR 2200uF 50V M
C9512 QEHQ1HM-228 E CAPACITOR 2200uF 50V M
C9513 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9514 NCB31HK-103X C CAPACITOR 0.01uF 50V K
 C9515 QCZ9079-332 C CAPACITOR 3300pF AC250V M
R1001 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R1002 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R1003 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R1004 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R1005 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R1006 QRL01DJ-471X OMF RESISTOR 470 Ω 1W J
R1007 QRL01DJ-471X OMF RESISTOR 470 Ω 1W J
R1008 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R1009 NRSA63J-154X MG RESISTOR 150k
Ω 1/16W J
R1010 NRSA63J-154X MG RESISTOR 150k
Ω 1/16W J
R1011 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R1012 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1013 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1014 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R1015 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
R1016 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1017 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
R1019 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1020 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R1021 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1022 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R1023 NRSA63J-184X MG RESISTOR 180k Ω 1/16W J
R1025 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
R1028 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
R1030 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1031 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1032 NRSA63J-684X MG RESISTOR 680k Ω 1/16W J
R1033 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1034 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1035 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1036 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1037 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R1038 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R1039 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R1040 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1041 QRE141J-470Y C RESISTOR 47
Ω 1/4W J
R1044 QRE141J-470Y C RESISTOR 47
Ω 1/4W J
R1046 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R1047 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R1048 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1049 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1050 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1051 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R1052 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1053 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R1054 NRSA63J-560X MG RESISTOR 56
Ω 1/16W J
R1055 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R1056 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1057 NRSA63J-154X MG RESISTOR 150k
Ω 1/16W J
R1059 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1060 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R1061 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R1062 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
R1064 QRE141J-470Y C RESISTOR 47
Ω 1/4W J
R1065 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R1066 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1067 NRSA63J-560X MG RESISTOR 56
Ω 1/16W J
R1068 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R1069 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1070 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R1071 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R1501 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R5001 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R5002 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5003 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J

Symbol
No.
Part No. Part Name Description Local
