JVC SP-DW103 Service Manual

SP-DW103
3-8
R5004 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5005 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5006 NRSA63J-752X MG RESISTOR 7.5k Ω 1/16W J
R5007 NRSA63J-133X MG RESISTOR 13k Ω 1/16W J
R5008 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5009 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5010 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5011 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5012 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5013 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R5014 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R5015 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R5016 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R5017 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5018 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5019 NRSA63J-4R7X MG RESISTOR 4.7 Ω 1/16W J
R5020 NRSA63J-4R7X MG RESISTOR 4.7 Ω 1/16W J
R5021 NRSA63J-4R7X MG RESISTOR 4.7 Ω 1/16W J
R5022 NRSA63J-4R7X MG RESISTOR 4.7 Ω 1/16W J
R5023 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R5024 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R5025 NRSA63J-4R7X MG RESISTOR 4.7
Ω 1/16W J
R5026 NRSA63J-4R7X MG RESISTOR 4.7 Ω 1/16W J
R5027 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R5028 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5029 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R5030 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R5031 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R5032 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R5033 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R5034 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R5035 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R5036 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5037 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R5038 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R5039 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5040 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5041 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R5042 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5043 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R5044 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R5045 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R5046 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R5048 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
 R5049 QRZ9038-220X FUSI RESISTOR 22 Ω
 R5050 QRZ9015-2R2X FUSI RESISTOR 2.2 Ω
 R5051 QRZ9015-100X FUSI RESISTOR 10 Ω
 R5052 QRZ9015-220X FUSI RESISTOR 22 Ω
R5053 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R5054 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R5055 QRT01DJ-6R8X MF RESISTOR 6.8 Ω 1W J
R5056 QRT01DJ-6R8X MF RESISTOR 6.8
Ω 1W J
R5057 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R5058 NRSA63J-184X MG RESISTOR 180k Ω 1/16W J
R5059 NRSA63J-113X MG RESISTOR 11k
Ω 1/16W J
R5701 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5702 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5713 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R5714 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R5715 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R5716 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R5717 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R5718 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5719 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5720 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R5721 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5722 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5723 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R5724 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R5725 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R5726 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R5727 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R5728 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R5729 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R5730 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R5731 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5732 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J

Symbol
No.
Part No. Part Name Description Local
R5733 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5734 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R5735 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5736 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R5737 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5738 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R5739 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5740 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R5741 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5742 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R5743 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R5744 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R5745 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R5746 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R5747 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R5748 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R5749 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
 R5901 QRZ9005-100X FUSI RESISTOR 10 Ω
R5902 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R5905 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R5906 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5909 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R5910 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5911 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R5912 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R5913 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R5914 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
 R5915 QRZ9038-220X FUSI RESISTOR 22 Ω
 R5916 QRZ9038-220X FUSI RESISTOR 22 Ω
R9001 QRL027J-104 OMF RESISTOR 100k Ω 2W J
 R9002 QRZ9037-335 COMP RESISTOR 3.3M Ω 1/2W K
R9501 QRT017J-R33 MF RESISTOR 0.33 Ω 1W J
R9502 QRT017J-R33 MF RESISTOR 0.33 Ω 1W J
R9503 QRZ9005-681X FUSI RESISTOR 680 Ω
R9504 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9505 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R9506 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9508 QRL01DJ-220X OMF RESISTOR 22 Ω 1W J
R9510 QRE141J-753Y C RESISTOR 75k Ω 1/4W J
R9516 NRSA63J-133X MG RESISTOR 13k Ω 1/16W J
R9517 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9518 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9519 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9520 NRSA63J-133X MG RESISTOR 13k Ω 1/16W J
R9521 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9522 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9523 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9524 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R9525 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9526 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R9527 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R9528 QRE141J-753Y C RESISTOR 75k
Ω 1/4W J
R9529 QRE141J-753Y C RESISTOR 75k
Ω 1/4W J
VR101 QVQ0300-B24 V RESISTOR
VR151 QVQ0021-B14 V RESISTOR
VR501 QVP0008-502Z TRIM RESISTOR 5k
Ω
VR502 QVP0008-203Z TRIM RESISTOR 20k Ω
 L5001 QQR1361-001 TOROIDAL COIL
L5901 NQL114K-471X COIL 470uH K
L5902 NQL114K-471X COIL 470uH K
L5903 NQL114K-471X COIL 470uH K
L5904 NQL114K-471X COIL 470uH K
 T9501 QQS0172-001 SW TRANSF
BK501 LV33818-001A BKT(FET)
CN101 QGB2016K1-08 CONNECTOR B-B (1-8)
CN102 QGA2501C1-02 CONNECTOR W-B (1-2)
CN103 QGB2016J1-05 CONNECTOR B-B (1-5)
CN151 QGA2001C1-08 CONNECTOR W-B (1-8)
CN501 QGB2016J1-08 CONNECTOR B-B (1-8)
CN502 QGB2510K1-10 CONNECTOR B-B (1-10)
CN503 QGA3901C1-02 CONNECTOR W-B (1-2)
CN504 QGB2016J1-11 CONNECTOR B-B (1-11)
CN505 QGB2016K1-11 CONNECTOR B-B (1-11)
 CN901 QGA7901F2-02 CONNECTOR W-B (1-2)
CN951 QGB2510J1-10 CONNECTOR B-B (1-10)

Symbol
No.
Part No. Part Name Description Local
