JVC SP-DW103 Service Manual

SP-DW103
3-9
CN952 QGB2016K1-05 CONNECTOR B-B (1-5)
EP951 QNZ0136-001Z EARTH PLATE
EP952 QNZ0136-001Z EARTH PLATE
HS951 LV33802-001A HEAT SINK1
HS952 E70306-001 HEAT SINK
HS953 E70306-001 HEAT SINK
HS954 E70306-001 HEAT SINK
J1001 QNN0090-001 PIN JACK
J1002 QNB0159-002 SPK.TERMINAL
K1001 NQR0129-003X FERRITE BESDS
K5001 QQR1183-001Z FERRITE BEADS
K5002 QQR1183-001Z FERRITE BEADS
K9501 QQR0779-001Z COIL
 LF901 QQR1360-001 LINE FILTER
 LF902 QQR1360-001 LINE FILTER
RY502 QSK0148-001 RELAY
S1001 QSW1002-001 PUSH SW
S1501 QSW0999-001 PUSH SW
 S9001 QSW1001-001 POWER SW
TH501 QAD0015-153Z THERMISTOR 15k Ω
 TH591 NAD0032-330X P THERMISTOR 33 Ω
 TH592 NAD0032-330X P THERMISTOR 33 Ω
 TH593 NAD0032-330X P THERMISTOR 33 Ω
 TH594 NAD0032-330X P THERMISTOR 33 Ω
 TH901 QAD0141-6R0 THERMISTOR 6 Ω
W1001 QJB001-080706 SIN ID C-B WIR
W9001 QUB192-07PPPP SIN TWIST WIRE
W9002 QUB199-09PPPP SIN TWIST WIRE
W9003 QUB191-07PPPP SIN TWIST WIRE
W9004 QUB190-09PPPP SIN TWIST WIRE
 Z9001 QNG0003-001Z FUSE CLIP
 Z9002 QNG0003-001Z FUSE CLIP

Symbol
No.
Part No. Part Name Description Local
