Description of parts and controls
5
Powered subwoofer
SP-PWC7/SP-PWC5
Note that the illustration below is for SP-PWC5.
SP-PWC6/SP-PWC4/SP-PWC3
NOTE
For safety reasons, always ensure that there is sufficient space behind the powered subwoofer.
* Do not block the ventilation openings.
3
16
Front Rear
POWER ON
lamp:
pg. 16
pg. 11
Power cord:
pg. 13
pg. 13
CAUTION:
SPEAKER IMPEDANCE
4
16
Front
Rear
POWER ON lamp:
pg. 16
pg. 11
Power cord:
pg. 13
pg. 13
TH-C3C4C5C6C7[JC].book Page 5 Wednesday, January 26, 2005 5:29 PM
