JVC SP-PWC5 Service Manual

3-21
Loading board
Block No. [0][6]
R461 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R463 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R464 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R465 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R535 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R541 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R701 NRSA63J-2R2X MG RESISTOR 2.2
Ω 1/16W J
R703 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R704 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R705 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R706 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R707 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R708 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R714 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R715 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R716 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R717 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R719 NRSA63J-5R1X MG RESISTOR 5.1 Ω 1/16W J
R720 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R722 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R731 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R732 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
CN101 QGF0523F1-25W CONNECTOR FFC/FPC (1-25)
CN201 QGF1016F2-08W CONNECTOR FFC/FPC (1-8)
CN451 QGF1016F2-15W CONNECTOR FFC/FPC (1-15)
CN452 QGA2001F2-02X CONNECTOR W-B (1-2)
CN453 QGA2001F2-03X CONNECTOR W-B (1-3)
CN701 QGF1016F2-28W CONNECTOR FFC/FPC (1-28)
CN702 QGF1016F2-10W CONNECTOR FFC/FPC (1-10)
CN703 QGF1016F2-08W CONNECTOR FFC/FPC (1-8)
K351 NQR0502-001X FERRITE BEADS
K352 NQR0502-001X FERRITE BEADS
K454 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K455 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K456 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K501 NQR0502-001X FERRITE BEADS
K710 NQR0022-002X FERRITE BEADS
K732 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K733 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K734 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K735 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K736 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K737 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K738 NQR0022-005X FERRITE BEADS
K741 NQR0022-002X FERRITE BEADS
K744 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K748 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K749 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K750 NQR0022-002X FERRITE BEADS
K752 NQR0022-002X FERRITE BEADS
K754 NQR0022-002X FERRITE BEADS
K756 NQR0022-002X FERRITE BEADS
K758 NQR0022-002X FERRITE BEADS
TH301 NAD0025-103X N THERMISTOR 10k Ω
X301 NAX0741-001X CRYSTAL
X451 NAX0248-001X C OSCILLATOR 8.000MHz
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C7 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
 Symbol No. Part No. Part Name Description Local
CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-001 PUSH SWITCH
SW2 QSW0844-001 PUSH SWITCH
SW3 QSW0844-001 PUSH SWITCH
SW4 QSW0844-001 PUSH SWITCH
SW5 QSW0844-001 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW8 QSW0923-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local

JVC SP-PWC5 Specifications

General

Brand	JVC
Model	SP-PWC5
Category	Home Theater System
Language	English
