Description of parts and controls
5
Powered subwoofer
SP-PWC7/SP-PWC5
Note that the illustration below is for SP-PWC5.
SP-PWC6/SP-PWC4/SP-PWC3
NOTE
• For safety reasons, always ensure that there is sufficient space behind the powered subwoofer.
* Do not block the ventilation openings.
3
Ω
16
Ω
Front Rear
POWER ON
lamp:
pg. 16
pg. 11
Power cord:
pg. 13
pg. 13
CAUTION:
SPEAKER IMPEDANCE
4
Ω
16
Ω
Front
Rear
POWER ON lamp:
pg. 16
pg. 11
Power cord:
pg. 13
pg. 13
