JVC SP-PWC6 - Specifications

References
43
7 Center unit
(XV-THC7/XV-THC6/XV-THC5/XV-THC4/XV-THC3)
Audio section
Total Harmonic Distortion 0.02 %
NOTE: This value is measured at System cord CONNECTOR for
reference.
Digital input*
1
:
DIGITAL IN (DBS): –21 dBm to –15 dBm
(OPTICAL) (660 nm E30 nm)
*
1
Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz)
Video section
Video System: NTSC
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video output level
Composite: 1.0 V(p-p)/75 C
S-video-Y: 1.0 V(p-p)/75 C
S-video-C: 0.286 V(p-p)/75 C
Component-Y: 1.0 V(p-p)/75 C
Component-P
B/PR: 0.7 V(p-p)/75 C
Video input sensitivity/Impedance (VCR IN)
Composite: 1.0 V(p-p)/75 C
S-video-Y: 1.0 V(p-p)/75 C
S-video-C: 0.286 V(p-p)/75 C
Tuner section
Tuning Range
FM: 87.5 MHz to 108.0 MHz
AM: 530 kHz to 1 710 kHz
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 16 W (at operation)
1.3 W (in standby mode)
Dimensions (W M H M D):
400 mm M 85 mm M 399 mm
(15-3/4 inches M 3-3/8 inches M
15-3/4 inches)
Mass: 4.2 kg (9.3 lbs)
7 Subwoofer (SP-PWC7)
Amplifier section
Front/Center/Surround: 167 W per channel, RMS at 3 C at 1
kHz, with 10 % total harmonic
distortion.
Subwoofer: 167 W, RMS at 3 C at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 25 cm (9-7/8 inches) Bass-reflex
Power Handling Capacity: 170 W
Impedance: 3 C
Frequency Range: 25 Hz to 200 Hz
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 160 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
264 mm M 481 mm M 459 mm
(10-7/16 inches M 18-15/16 inches M
18-1/8 inches)
Mass: 16.5 kg (37 lbs)
7 Subwoofer (SP-PWC6)
Amplifier section
Front/Center/Surround: 167 W per channel, RMS at 3 C
at 1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 167 W, RMS at 3 C at 100 Hz, with 10
% total harmonic distortion.
Speaker section
Speaker unit: 16 cm (6-5/16 inches) Bass-reflex
Power Handling Capacity: 170 W
Impedance: 3 C
Frequency Range: 30 Hz to 200 Hz
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 160 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
169 mm M 411 mm M 451 mm
(6-11/16 inches M 16-3/16 inches M
17-13/16 inches)
Mass: 11.5 kg (25.4 lbs)
7 Subwoofer (SP-PWC5)
Amplifier section
Front/Center/Surround: 167 W per channel, RMS at 3 C at 1
kHz, with 10 % total harmonic
distortion.
Subwoofer: 167 W, RMS at 3 C at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 25 cm (9-7/8 inches) Bass-reflex
Power Handling Capacity: 170 W
Impedance: 3 C
Frequency Range: 25 Hz to 200 Hz
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 160 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
264 mm M 481 mm M 459 mm
(10-7/16 inches M 18-15/16 inches M
18-1/8 inches)
Mass: 16.5 kg (37 lbs)
7 Subwoofer (SP-PWC4)
Amplifier section
Front/Center/Surround: 167 W per channel, RMS at 3 C at 1
kHz, with 10 % total harmonic
distortion.
Subwoofer: 167 W, RMS at 3 C at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 16 cm (6-5/16 inches) Bass-reflex
Power Handling Capacity: 170 W
Impedance: 3 C
Frequency Range: 25 Hz to 200 Hz
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 160 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
169 mm M 411 mm M 451 mm
(6-11/16 inches M 16-3/16 inches M
17-13/16 inches)
Mass: 11.5 kg (25.4 lbs)
Specifications
