❋ Designs and specifications are subject to change without notice.
Specifications of main unit
GeneralCD/DVDVideo
Amplifier
Speakers
Tuner
FM
Power supply 120 V ~ 60 Hz
Power consumption 110 W
Net Weight 3.6 kg
External dimensions (W x H x D) 430 x 76 x 317 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
Video system NTSC
Frequency response (audio) 140 Hz to 20 kHz
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, 20 kHz LPF/A-Filter)
Dynamic range (audio) More than 75 dB
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack x 1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1
(PB)/(PR) 0.7 V (p-p), 75 ohms, RCA jack x 1
HDMI OUT 480i/480p/720p/1080i/1080p
Tuning Range 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 60 dB (Mono)
Frequency Response 140 - 10,000 Hz
Stereo mode 155 W + 155 W (4Ω at 1 kHz, THD 10 %)
Surround mode Front: 155 W + 155 W (THD 10 %)
center*: 155 W
Subwoofer*: 225 W (3Ω at 70 Hz, THD 10 %)
Inputs AUDIO IN, OPTICAL IN, AUX IN, iPod, HDMI IN
Outputs MONITOR OUT, HDMI OUT,
COMPONENT VIDEO OUT
Front/Rear Speaker Center speaker Passive Subwoofer
Type 1 Way 1 Speaker 1 Way 1 Speaker 1 Way 1 Speaker
Impedance 4 Ω 4 Ω 3 Ω
Frequency Response 120 - 18000 Hz 120 -18000 Hz 40 - 1500 Hz
Sound Pressure Level 83 dB/W (1m) 83 dB/W (1m) 82 dB/W (1m)
Rated Input Power 155 W 155 W 225 W
Max. Input Power 310 W 310 W 450 W
Net Dimensions (W x H x D)
113 x 209 x 83 mm 301 x 118 x 83 mm 236 x 435 x 391 mm
Net Weight 0.78 kg 0.9 kg 5.7 kg
Items with are measured at Front Speaker Terminals in STEREO mode
(*
Depending on the sound mode
settings and the source, there
may be no sound output.)
