(No.YD091)3-9
Electrical parts list
Switching regulator board
Block No. [0][1]
Symbol No.
Part No. Part Name Description Local
PW1 LPA10314-01B1 SWITCHING REGULATOR BOARD ASSY
IC5101 STR-G6653-F9 IC
IC5301 UTCTL431-T IC
IC5301 or TL431/A/-T IC
IC5302 MM1665AH-X IC
Q5303 RT1P44HC-X DIGI TRANSISTOR
Q5303 or UN211E-X DIGI TRANSISTOR
Q5304 RT1N141C-X DIGI TRANSISTOR
Q5304 or UN2211-X TRANSISTOR
Q5305 2SC3576-JVC-T TRANSISTOR
Q5305 or 2SD2144S/VW/-T TRANSISTOR
Q5306 2SC6007/F/ POW TRANSISTOR
Q5307 2SA1585S/QR/-T TRANSISTOR
Q5308 RT1N141C-X DIGI TRANSISTOR
Q5308 or UN2211-X TRANSISTOR
Q5313 2SA1585S/QR/-T TRANSISTOR
Q5315 RT1N141C-X DIGI TRANSISTOR
Q5315 or UN2211-X TRANSISTOR
Q5316
2SC3928A/QRS/-X
TRANSISTOR
Q5316 or 2SD601A/QRS/-X TRANSISTOR
Q5317 RT1P141C-X DIGI TRANSISTOR
Q5317 or UN2111-X TRANSISTOR
Q5318 RT1N141C-X DIGI TRANSISTOR
Q5318 or UN2211-X TRANSISTOR
Q5319 2SB709A/QR/-X TRANSISTOR
Q5319 2SA1037AK/QR/-X TRANSISTOR
Q5319 2SA1530A/QR/-X TRANSISTOR
D5001 KBJ4J BRIDGE DIODE
D5001 or GBJ4J BRIDGE DIODE
D5001 or D3SBA60 BRIDGE DIODE
D5101 SARS01-T2 FR DIODE
D5103 1F4G-G-T2 FR DIODE
D5103 or 1F4G-T2 FR DIODE
D5103 or 10ERB20-T2 FR DIODE
D5104 1SS133-T2 SI DIODE
D5104 or 1SS270A-T2 SI DIODE
D5105 1F4G-G-T2 FR DIODE
D5105 or 1F4G-T2 FR DIODE
D5105 or 10ERB20-T2 FR DIODE
D5106 SBO40-T2 SB DIODE
D5106 or 1S4-T2 SB DIODE
D5202 1F4G-G-T2 FR DIODE
D5202 or 1F4G-T2 FR DIODE
D5202 or 10ERB20-T2 FR DIODE
D5204 SX34-X SB DIODE
D5205 SB240-B322-3 SB DIODE
D5205 or SB240-F26 SB DIODE
D5207 SX34-X SB DIODE
D5209 SB240-B322-3 SB DIODE
D5209 or SB240-F26 SB DIODE
D5210 1F4G-G-T2 FR DIODE
D5210 or 1F4G-T2 FR DIODE
D5210 or 10ERB20-T2 FR DIODE
D5211 RS1G-X FR DIODE
D5212 SX34-X SB DIODE
D5213 UF202G-F26 FR EIODE
D5213 or HER202G-B322-3 FR DIODE
D5214 1F4G-G-T2 FR DIODE
D5214 or 1F4G-T2 FR DIODE
D5214 or 10ERB20-T2 FR DIODE
D5303 MTZJ12B-T2 Z DIODE
D5304 MTZJ5.6C-T2 Z DIODE
D5307 MTZJ7.5B-T2 Z DIODE
D5308 DAP202U-X SI DIODE
D5309 DAP202U-X SI DIODE
D5310 1SS355-X DIODE C.M
PC5101 PC123Y82FZ PHOTO COUPLER
C5001 QFZ9073-683 MM CAPACITOR 0.068uF AC250V M
C5002 QFZ9073-223 MM CAPACITOR 0.022uF AC250V M
C5003 QETM2GM-107 E CAPACITOR 100uF 400V M
C5004 QCZ9071-222 C CAPACITOR 2200pF AC400V M
C5005 QCZ9071-101 C CAPACITOR 100pF AC400V K
C5102 QCZ0212-472 C CAPACITOR 4700pF 1kV K
C5103 QEZ0657-826Z E CAPACITOR 82uF
C5104 QCZ0136-221Z C CAPACITOR 220pF 1kV K
C5105 NDC31HJ-471X C CAPACITOR 470pF 50V J
C5106 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5107 NDC31HJ-331X C CAPACITOR 330pF 50V J
C5108 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5202 QETN2AM-475Z E CAPACITOR 4.7uF 100V M
C5204 QEZ0701-158 E CAPACITOR 1500uF
C5205 QEZ0700-228 E CAPACITOR 2200uF 10V M
C5206 QTM91AM-338 E CAPACITOR 3300uF 10V M
C5208 QEZ0700-128 E CAPACITOR 1200uF 10V M
C5209 QEZ0658-186Z E CAPACITOR 18uF 50V M
C5210 QEZ0653-227Z E CAPACITOR 220uF 6.3V M
C5211 QEZ0658-186Z E CAPACITOR 18uF 50V M
C5301 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C5302 QFLC1HJ-333Z M CAPACITOR 0.033uF 50V J
C5303 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5305 QETN1AM-227Z E CAPACITOR 220uF 10V M
C5306 QETN1AM-227Z E CAPACITOR 220uF 10V M
C5309 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5311 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5312 QETN1AM-227Z E CAPACITOR 220uF 10V M
C5321 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5322 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5323 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5324 QEZ0654-477Z E CAPACITOR 470uF 10V M
C5325 QETN1CM-477Z E CAPACITOR 470uF 16V M
R5101 QRZ0251-154 OMF RESISTOR 150k
Ω
2W J
R5102 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R5103 QRE141J-684Y C RESISTOR 680k
Ω
1/4W J
R5104 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5105 QRE141J-180Y C RESISTOR 18
Ω
1/4W J
R5106 QRE141J-392Y C RESISTOR 3.9k
Ω
1/4W J
R5107 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R5108 QRT01DJ-R33X MF RESISTOR 0.33
Ω
1W J
R5109 QRZ9051-470X FUSI RESISTOR 47
Ω
1/4W J
R5301 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5302 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R5303 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R5304 NRSA63D-682X MG RESISTOR 6.8k
Ω
1/16W D
R5305 NRSA63J-203X MG RESISTOR 20k
Ω
1/16W J
R5306 NRSA63D-392X MG RESISTOR 3.9k
Ω
1/16W D
R5313 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R5314 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R5315 QRE121J-820Y C RESISTOR 82
Ω
1/2W J
R5316 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5317 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5327 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5328 QRE141J-821Y C RESISTOR 820
Ω
1/4W J
R5329 QRE141J-821Y C RESISTOR 820
Ω
1/4W J
R5330 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R5331 QRE141J-560Y C RESISTOR 56
Ω
1/4W J
R5332 QRE141J-560Y C RESISTOR 56
Ω
1/4W J
R5333 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R5334 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5335 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
L5201 QQR1633-001 CHOKE COIL
L5203 QQR1633-001 CHOKE COIL
L5204 QQR1633-001 CHOKE COIL
L5205 QQR1633-001 CHOKE COIL
L5207 QQR1633-001 CHOKE COIL
T5001 QQS0367-001 SW TRANSF
B5310 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
CN5001 QGA7901C3-02 CONNECTOR AC IN
CN5301 QGF1208C1-15 CONNECTOR F/T 1-15
CN5302 QGA2001C1-02 CONNECTOR T0 FAN
CN5303 QGA2501C1-04 CONNECTOR T0 HDD
CN5304 QGF1208C1-19 CONNECTOR T0 JUNC
CP5301
QMFZ054-1R5X-J1
FUSE 1.5A
Symbol No.
Part No. Part Name Description Local
