JVC SR-DVM700EU - Page 106

3-14(No.YD091)
Main board
Block No. [0][3]
K2202 NQR0129-002X FERRITE BEADS
K2203 NQR0129-002X FERRITE BEADS
K2204 NQR0129-002X FERRITE BEADS
K2205 NQR0129-002X FERRITE BEADS
K2206 NQR0129-002X FERRITE BEADS
K2207 NQR0129-002X FERRITE BEADS
K2208 NQR0129-002X FERRITE BEADS
K2209 NQR0129-002X FERRITE BEADS
K2210 NQR0129-002X FERRITE BEADS
K2211 NQR0129-002X FERRITE BEADS
K2212 NQR0129-002X FERRITE BEADS
K2213 NQR0129-002X FERRITE BEADS
K2214 NQR0129-002X FERRITE BEADS
K2215 NQR0129-002X FERRITE BEADS
K2216 NQR0129-002X FERRITE BEADS
K2217 NQR0129-002X FERRITE BEADS
K2218 NQR0129-002X FERRITE BEADS
K2219 NQR0129-002X FERRITE BEADS
K2220 NQR0129-002X FERRITE BEADS
K2221 NQR0129-002X FERRITE BEADS
LC1401 NQR0512-008X EMI FILTER
LC1402 NQR0512-008X EMI FILTER
LC1403 NQR0512-008X EMI FILTER
OT1 LP40769-001A SPACER
SD1 LP21298-002A S.FRAME(DIGI)
X1401 NAX0580-001X CXO 27.0000MHz
X1801 NAX0666-001X CRYSTAL 24.576000MHz
 Symbol No. Part No. Part Name Description Local
PW1 LPA10277-06A MAIN BOARD ASSY
IC201 LC74788N-9751-E IC
IC501 JCP8038 IC
IC701 JCP8038-I IC
IC701 or JCP8038 IC
IC851 SN74LV08APW-X IC
IC901 74HC4053D-X IC
IC2201 CD4052BM-X IC
IC2202 RC4558D-X IC
IC2603 CD4052BM-X IC
IC2604 RC4558D-X IC
IC2604 or BA15218F-XE IC
IC2605 CD4052BM-X IC
IC2606 RC4558D-X IC
IC2606 or BA15218F-XE IC
IC3001
HD6432194SXE28F IC(MCU) MASK
IC3002 S-80827CNNB-G-W IC
IC3004 LPN1032-001D-11 IC(EEPROM) *(REFER TO BELOW)
IC5401 MM1663DH-X IC
Q212
2SC2412K/QRS/-X TRANSISTOR
Q212 or 2SD601A/QRS/-X TRANSISTOR
Q212 or
2SC3928A/QRS/-X TRANSISTOR
Q503 2SD601A/QRS/-X TRANSISTOR
Q503 or
2SC2412K/QRS/-X TRANSISTOR
Q503 or
2SC3928A/QRS/-X TRANSISTOR
Q505 2SB709A/QR/-X TRANSISTOR
Q505 or 2SA1037AK/QR/-X TRANSISTOR
Q505 or 2SA1530A/QR/-X TRANSISTOR
Q701 2SB709A/QR/-X TRANSISTOR
Q701 or 2SA1037AK/QR/-X TRANSISTOR
Q701 or 2SA1530A/QR/-X TRANSISTOR
Q703 2SD601A/QRS/-X TRANSISTOR
Q703 or 2SC2412K/QRS/-X TRANSISTOR
Q703 or
2SC3928A/QRS/-X TRANSISTOR
Q706 2SD601A/QRS/-X TRANSISTOR
Q706 or
2SC2412K/QRS/-X TRANSISTOR
Q706 or
2SC3928A/QRS/-X TRANSISTOR
Q711 2SB709A/QR/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q711 or 2SA1037AK/QR/-X TRANSISTOR
Q711 or 2SA1530A/QR/-X TRANSISTOR
Q713 2SB709A/QR/-X TRANSISTOR
Q713 or 2SA1037AK/QR/-X TRANSISTOR
Q713 or 2SA1530A/QR/-X TRANSISTOR
Q901 2SB709A/QR/-X TRANSISTOR
Q901 or 2SA1037AK/QR/-X TRANSISTOR
Q901 or 2SA1530A/QR/-X TRANSISTOR
Q902 2SB709A/QR/-X TRANSISTOR
Q902 or 2SA1037AK/QR/-X TRANSISTOR
Q902 or 2SA1530A/QR/-X TRANSISTOR
Q911 2SB709A/QR/-X TRANSISTOR
Q911 or 2SA1037AK/QR/-X TRANSISTOR
Q911 or 2SA1530A/QR/-X TRANSISTOR
Q912 2SB709A/QR/-X TRANSISTOR
Q912 or 2SA1037AK/QR/-X TRANSISTOR
Q912 or 2SA1530A/QR/-X TRANSISTOR
Q913 2SB709A/QR/-X TRANSISTOR
Q913 or 2SA1037AK/QR/-X TRANSISTOR
Q913 or 2SA1530A/QR/-X TRANSISTOR
Q915 2SB709A/QR/-X TRANSISTOR
Q915 or 2SA1037AK/QR/-X TRANSISTOR
Q915 or 2SA1530A/QR/-X TRANSISTOR
Q2201 2SC2412K/QRS/-X TRANSISTOR
Q2201 or 2SD601A/QRS/-X TRANSISTOR
Q2201 or 2SC3928A/QRS/-X TRANSISTOR
Q2202 2SC2412K/QRS/-X TRANSISTOR
Q2202 or 2SD601A/QRS/-X TRANSISTOR
Q2202 or 2SC3928A/QRS/-X TRANSISTOR
Q2203 DTA144WKA-X TRANSISTOR
Q2203 or UN211E-X DIGI TRANSISTOR
Q2203 or RT1P44HC-X DIGI TRANSISTOR
Q2204 DTC144WKA-X DIGI TRANSISTOR
Q2204 or UN221E-X TRANSTSTOR
Q2204 or RT1N44HC-X DIGI TRANSISTOR
Q2601 2SC2412K/QRS/-X TRANSISTOR
Q2601 or 2SD601A/QRS/-X TRANSISTOR
Q2601 or 2SC3928A/QRS/-X TRANSISTOR
Q2602 2SC2412K/QRS/-X TRANSISTOR
Q2602 or 2SD601A/QRS/-X TRANSISTOR
Q2602 or 2SC3928A/QRS/-X TRANSISTOR
Q2603 DTC143TKA-X DIGI TRANSISTOR
Q2603 or UN2216-X DIGI TRANSISTOR
Q2603 or RT1N430C-X TRANSISTOR
Q2604 DTC143TKA-X DIGI TRANSISTOR
Q2604 or UN2216-X DIGI TRANSISTOR
Q2604 or RT1N430C-X TRANSISTOR
Q2605 DTA144WKA-X TRANSISTOR
Q2605 or UN211E-X DIGI TRANSISTOR
Q2605 or RT1P44HC-X DIGI TRANSISTOR
Q3004
2SC2412K/QRS/-X TRANSISTOR
Q3004 or 2SD601A/QRS/-X TRANSISTOR
Q3004 or 2SC3928A/QRS/-X TRANSISTOR
Q3008 UN221L-X DIGI TRANSISTOR
Q3008 or DTC143EKA-X DIGI TRANSISTOR
Q3008 or RT1N431C-X TRANSISTOR
Q3901 UN221E-X TRANSTSTOR
Q3901 or DTC144WKA-X DIGI TRANSISTOR
Q3901 or RT1N44HC-X DIGI TRANSISTOR
Q5401 2SB709A/QR/-X TRANSISTOR
Q5401 or 2SA1037AK/QR/-X TRANSISTOR
Q5401 or 2SA1530A/QR/-X TRANSISTOR
Q5402 UN2111-X TRANSISTOR
Q5402 or DTC114EKA-X DIGI TRANSISTOR
Q5402 or RT1N141C-X DIGI TRANSISTOR
D202 1SS133-T2 SI DIODE
D203 1SS133-T2 SI DIODE
D204 1SS133-T2 SI DIODE
D501 DA204U-X SI DIODE
D502 DA204U-X SI DIODE
D701 DA204U-X SI DIODE
D702 DA204U-X SI DIODE
D2601 1SS133-T2 SI DIODE
D2601 or 1SS270A-T2 SI DIODE
D3002 1SS133-T2 SI DIODE
D3002 or 1SS270A-T2 SI DIODE
D3003 MTZJ39C-T2 Z DIODE
 Symbol No. Part No. Part Name Description Local
After exchanging EEPROMs, a main part does not correspond to some remote control commands at Jig RCU mode.
Please cancel the Jig RCU mode of a main part after exchanging EEPROMs. Please refer to the "Canceling JIG mode"
about the release method.
