JVC SR-DVM700EU - Page 90

<JUNCTION>
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
IC5501
1 4.8 4.8
2 3.7 3.7
3 3.3 3.3
4 1.3 1.2
5 0 0
6 0 0
7 0 0
8 0 0
IC5502
1 4.5 4.8
2 0 4.8
3 5.3 5.3
4 3.7 0
5 3.1 3.3
6 5.2 5.2
7 0 0
8 0 0
IC5503
1 5.0 5.0
2 0 0
3 4.8 4.8
4 0 0
5 0 0
6 5.6 5.6
IC7101
1 5.1 5.1
2 2.4 2.4
3 4.7 4.7
4 1.3 1.6
5 0 0
6 1.6 0
7 0 0
8 2.7 2.5
9 3.2 3.2
10 1.6 1.7
11 0 0
12 2.4 2.4
13 4.9 4.9
14 2.5 2.4
15 0 0
16 2.5 2.5
17 0 0
18 2.5 2.5
19 0 0
20 2.1 2.1
21 2.1 2.1
22 0 0
23 2.1 2.1
24 0 0
25 0 0
26 0 2.4
27 0 0
28 0 5.1
IC8001
1 0 0
2 0 0
3 0 0
4 -7.4 -7.4
5 0 0
6 0 0
7 0 0
8 9.5 9.5
IC8002
1 2.6 2.6
2 2.6 2.5
3 0 0
4 0 2.6
5 0 0
6 5.3 0
7 0 0
8 0 0
9 1.0 1.2
10 1.6 1.6
11 1.6 1.7
12 0 1.6
13 3.2 3.1
14 3.2 3.3
15 0 0
16 0 0
IC8201
1 0 0
2 0 1.1
3 1.4 1.7
4 -7.4 -7.4
5 1.3 1.3
6 0 1.6
7 0 -
8 9.5 9.5
IC8202
1 1.6 1.6
2 1.6 1.6
3 1.6 1.7
4 1.6 1.6
5 0 3.2
6 3.3 3.2
7 0 2.6
8 0.2 0
9 2.5 2.5
10 0 0
11 2.5 2.6
12 2.5 2.6
13 0 0
14 0 0
15 0 0
16 0 0
Q5504
E -16.8 -16.8
C -16.7 -16.6
B -16.1 -16.0
Q5505
E 1.2 1.2
C -8.6 -8.5
B 0 0
Q5508
E 11.6 11.6
C 11.6 11.5
B 10.8 10.8
Q5509
E 0 0
C 0 0
B 4.8 4.8
Q7101
E 1.8 1.8
C 0 0
B 1.2 1.2
Q8001
E 0 0
C 0 0
B -1.9 -1.4
Q8002
E 0 0
C 0 0
B -1.8 -1.8
Q8003
E 0 0
C 5.2 5.2
B 0 0
Q8004
E 0 0
C 5.2 5.2
B 0 0
Q8005
E 5.2 5.3
C 0 -1.5
B 5.3 5.2
CN5501
1 -33.2 -33.2
2 5.7 5.7
3 -22.1 -22.1
4 5.6 5.6
5 -16.6 -16.6
6 0 0
7 0 0
8 0 0
9 0 0
10 5.5 5.6
11 0 0
12 0 0
13 4.4 4.4
14 4.8 4.8
15 4.0 4.0
16 11.6 11.6
17 -7.4 -7.4
18 11.6 11.6
19 11.0 11.0
CN5502
1 0 0
2 0 0
3 3.2 3.3
4 2.3 2.4
5 1.9 1.9
6 0 1.9
CN5503
1 11.6 11.5
2 0 0
3 11.6 11.5
4 0 0
5 0 0
6 5.0 5.0
7 3.3 3.3
8 0 0
CN5505
1 4.8 4.8
2 1.9 1.9
3 1.9 1.9
4 0.8 0.9
5 -0.1 0
6 -0.1 -0.1
7 5.5 5.5
8 -0.1 -0.1
9 0.8 0.9
10 0 2.4
11 0 0
12 5.5 5.5
13 0 0
CN7102
1 4.7 4.7
2 4.8 4.9
3 4.9 4.9
4 4.3 4.2
5 - -
6 0.5 0
7 0.3 0.3
8 0 0
9 4.0 0
10 0 0
11 0 0
12 0 0
13 4.9 4.9
14 0 0
15 0 0
16 -21.8 -22.0
17 -30.7 0
18 5.0 5.1
19 0 4.8
CN7107
1 2.1 2.1
2 2.1 2.1
3 0 0
4 2.1 2.1
5 0 0
6 2.4 2.5
7 0 0
8 0 0
9 2.1 2.1
10 0 0
11 2.5 2.5
12 0 0
13 2.5 2.5
CN7108
1 1.6 1.6
2 1.1 1.1
3 1.6 1.6
4 0 0
5 1.7 1.7
6 1.2 1.1
7 0 0
8 0 0
9 1.0 1.0
10 1.1 1.1
11 1.1 1.1
12 0 0
13 3.3 3.2
14 1.1 1.1
15 0 0
16 0 0
17 0 0
18 2.4 2.4
19 1.6 1.6
20 1.9 1.9
21 3.2 3.3
22 0 0
23 3.3 3.2
24 1.6 1.6
25 0.2 0
26 1.6 1.6
27 2.7 2.7
28 1.6 1.6
CN7109
1 0 0
2 4.3 4.3
3 0 0
4 1.7 1.8
5 1.2 1.2
6 3.5 4.9
7 4.0 4.0
8 0 0
9 0 0
10 5.1 5.2
11 0 0.3
12 0 0
13 0.5 0.6
14 5.2 5.2
15 0 0
16 3.2 3.2
17 0 0
18 0 0
19 1.6 1.6
20 0 0
21 0 0
22 0 0
23 0 0
24 0 0
25 0 0
26 0 0
27 3.3 3.3
28 3.3 3.3
CN7121
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 3.2 3.2
7 3.2 3.2
8 0 0
9 0 0
10 0 0
11 0 0
12 0 0
13 0 0
14 0 0
CN7123
1 2.4 2.4
2 0 0
3 1.8 1.8
4 0 0
CN7126
1 3.2 3.2
2 3.2 3.2
3 0 0
4 0 0
5 0 0
6 0 0
CN7127
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
CN8001
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
7 0 0
8 0 0
9 0 0
10 3.2 0
11 1.6 1.6
<D-SUB>
MODE
REC PLAY
PIN NO.
IC7401
1 0 0
2 0 3.2
3 0 3.2
4 0 0
5 0 0
6 0 0
7 0 0
8 0 0
9 3.2 3.2
10 0 0
11 3.2 3.2
12 0 0
13 0 0
14 0 0
15 3.2 3.2
16 3.2 3.2
CN7401
1 3.2 3.3
2 0 0
3 3.2 3.3
4 3.2 3.2
VOLTAGE CHARTS
2-83 2-84
