TD-W254BK
3-3
Item
Parts number Parts name Ar
e
a
Electrical parts list
Remarks
Block No. 01
A
C2501 QENC1EM-475Z NP E.CAPA I.M 4.7MF 20% 25V
C2511 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C2601 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C2602 QCB31HK-222Z C CAPACITOR 2200PF 10% 50V
C8101 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C8102 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C8151 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C8152 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C8251 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C8252 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C8351 QETN1AM-477Z E CAPACITOR 470MF 20% 10V
C8352 QETN1AM-477Z E CAPACITOR 470MF 20% 10V
C8451 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C8452 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V
C8453 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C8454 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C8455 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C8481 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C8482 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C8483 QETN1EM-337Z E CAPACITOR 330MF 20% 25V
C8491 QFP32AJ-103Z PP CAPACITOR .010MF 5% 100V
C8492 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C8493 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C8494 QFN31HJ-102Z M CAPACITOR 1000PF 5% 50V
C8495 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V
C8496 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V
C8501 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C8502 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C8503 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C8511 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C8512 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C8513 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C8601 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C8602 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C8901 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
D 901 11ES2-T4 DIODE I.M
A
D 902 11ES2-T4 DIODE I.M
A
D 903 11ES2-T4 DIODE I.M
A
D 904 11ES2-T4 DIODE I.M
A
D 905 MA700A-T2 ZENER DIODE EN,U
A
D 906 1SS133-T2 SI DIODE IM
D 907 MTZJ3.6A-T2 ZENER DIODE IM J,C
D 908 1SS133-T2 SI DIODE IM
D 909 11ES2-T4 DIODE I.M
A
D 910 11ES2-T4 DIODE I.M
A
D 913 MTZJ24D-T2 Z DIODE I/M
A
D 914 1SS133-T2 SI DIODE IM
D 917 1SS133-T2 SI DIODE IM
D 918 MTZJ12C-T2 ZENER DIODE
D 921 1SS133-T2 SI DIODE IM
D 922 MTZJ6.2B-T2 ZENER DIODE
D 923 1SS133-T2 SI DIODE IM
D 924 1SS133-T2 SI DIODE IM
D 925 1SS133-T2 SI DIODE IM
D 926 MTZJ6.8B-T2 ZENER DIODE
D1511 1SS133-T2 SI DIODE IM
D2511 1SS133-T2 SI DIODE IM
D8101 1SS133-T2 SI.DIODE
D8252 1SS133-T2 SI DIODE IM
D8253 1SS133-T2 SI DIODE IM
D8351 1SS133-T2 SI DIODE IM
D8451 1SS133-T2 SI DIODE IM
D8452 1SS133-T2 SI DIODE IM
D8481 1SS133-T2 SI DIODE IM
D8513 1SS133-T2 SI DIODE IM
D8514 1SS133-T2 SI DIODE IM
IC811 AN6557F IC
IC812 BU4066BC IC
IC815 AN6557F IC
IC816 UPC1330HA IC
IC818 BU4066BC IC
IC825 BA15218N IC
IC826 BU4066BC IC
IC835 HA12142NT IC
IC845 UPC1297CA IC
IC851 AN7384N IC
IC852 BA15218N IC
IC861 BA15218N IC
IC891 M50253P IC PORTS EXPANDER
IC901 M5218AL IC
A
J 701 QMS3533-V01 JACK
J8501 QNN0135-001 PIN JACK PIN JACK
J8601 QNS0092-001 JACK
L1251 QQL30BJ-183Z INDUCTOR
L1252 QQL30BJ-472Z INDUCTOR
L1351 QQR0879-001 FILTER MPX FILTER
L1401 QQR0847-001 OSC COIL(BIAS)
L2251 QQL30BJ-183Z INDUCTOR
L2252 QQL30BJ-472Z INDUCTOR
L2351 QQR0879-001 FILTER MPX FILTER
L2401 QQR0847-001 OSC COIL(BIAS)
L8401 QQR0845-001 OSC COIL(BIAS)
P 1 QNZ0079-001Z TAB U
P 1 QNZ0107-001 TAB J,C,EN
P 3 QNZ0107-001 TAB J,C,EN
P 3 QNZ0079-001Z TAB U
Q
901 2SD882/QP/ TRANSISTOR
A
Q
903 2SB772/QP/ TRANSISTOR
A
Q
905 2SB647/CD/-T TRANSISTOR
A
Q
907 2SC3576-JVC-T TRANSISTOR I/M
Q
908 2SC3576-JVC-T TRANSISTOR I/M
Q
909 2SD882/QP/ TRANSISTOR
A
Q
912 2SD468/BC/-T TRANSISTOR
A
Q
913 KRA103M-T TRANSISTOR *
Q
915 2SD468/BC/-T TRANSISTOR
A
Q
1101 KRC103M-T TR I/M
Q
1152 2SK301/RS/-T TRANSISTOR(FET)
Q
1251 KTC3203/OY/-T TRANSISTOR
Q
1252 KRC103M-T TR I/M
Q
1261 KTC3199/GL/-T TRANSISTOR
Q
1262 KRC103M-T TR I/M
Q
1511 KTC3203/OY/-T TRANSISTOR
Q
2101 KRC103M-T TR I/M
Q
2152 2SK301/RS/-T TRANSISTOR(FET)
Q
2251 KTC3203/OY/-T TRANSISTOR
Q
2252 KRC103M-T TR I/M
Q
2261 KTC3199/GL/-T TRANSISTOR
Q
2262 KRC103M-T TR I/M
Q
2511 KTC3203/OY/-T TRANSISTOR
Q
8101 KRA103M-T TRANSISTOR
Q
8163 KRC103M-T TR I/M
Q
8171 KRA103M-T TRANSISTOR
Q
8172 KRA103M-T TRANSISTOR
Q
8251 KRA103M-T TRANSISTOR *
Q
8252 KRA103M-T TRANSISTOR *
Q
8351 KRC103M-T TR I/M
(Main board)
Item
Parts number Parts name Ar
e
a
Remarks
A
