(No.MB570)1-41
4.3 DVD special mode
4.3.1 Special mode
4.3.2 DVD upgrade
4.3.3 ROM correction (System micon)
Press 10 at 10 key of remocon. DVD-DL (parallel, opposite),
Serch & jitter measurement of the
specified position of DVD-SL.
5
6
7
8
CH ECK
7
Press MENU key of remocon. Return to STEP2.
Press POWER key of main unit. Releasr the TEST MODE.
Press STOP key of main unit/
remocon.
Disc stop, LD-OFF.
Press OPEN/CLOSE key of main
unit/remocon.
Tray open/close.
Press PLAY key of main unit/
remocon.
Disc playback.
*1 Mode toggle by press MENU key.
*2 STEP2-3 and STEP3 are only for DVD-AUDIO or VR correspondence model.
STEP OPERATION MOVEMENT REMARKS
FL (LCD) indication
13121110123456789
Upper:0x00-0x06
(Measured position with VT-501)
Lower:Jitter value
Upper:Laser current value
(Backup value, Real measured value)
Lower:Jitter value
When this key is pushed any STEP, the test
mode is canceled.
Mode name Operation Function
Load up grade discDVD up grade
Load ROM CORR disc
Load ROM CORR disc
ROM CORR
(System micon)
ROM CORR
(Mecha micon)
Do the update the DVD firmware.
Do the repair of system micon problem.
Model number of ROM CORR is A300
Do the repair of mecha micon problem.
Invalid the inside of TEST mode.
Processing FL indication Display (OSD) indication Remarks
"READING"TOC READ
"UPGRADE"
"_OPEN_"
"_OPEN_"
DATA READ
WRITING
END
NOW READING TOC reading
Writing the data to flash rom.
Input a main unit and all the key of remote control are forbidden.
Upgrade completed.
Prohibition of a key input is canceled as initialization end status.
Disc data reading
Indicate firm current versin, new version and reminder sector
quantity.
Only [POWER] [OPEN/CLOSE] key of a main unit is validated.
OPEN
VERSION UP DISC
PROGRAM&DESTINATION MODE
CURRENT VERSION
NEW VERSION
READING..
SECTOR
VERSION UP DISC
PROGRAM&DESTINATION MODE
CURRENT VERSION
NEW VERSION
WRITING..
Processing FL indication Display (OSD) indication Remarks
"READING"TOC READ
"ROM_CORR"
"ROM_CORR"
"COMPLETE"
DATA READ
WRITING
END
NOW READING TOC reading
Writing the data to EEPROM.
Input a main unit and all the key of remote control are forbidden.
ROM CORRECTION completed.
Prohibition of a key input is canceled as ROM CORR completed
status.
Disc data reading
Indicate firm current versin.
Only [POWER] [OPEN/CLOSE] key of a main unit is validated.
VERSION UP DISC
SYSCON UP MODE
CURRENT VERSION
WRITING..
VERSION UP DISC
SYSCON UPG MODE
CURRENT VERSION
READING..
SECTOR 1
VERSION UP DISC
SYSCON UPG MODE
CURRENT VERSION
WRITING..
*ROM CORR data confirm
The following processings are performed in order to prevent that fault occurs, when a new micon / the old micon / ROM collection is
intermingled.
The data (ID) which a micon should make a judgment standard is stored in a [E2PROM] start address [2 bytes].
A data format presupposes that it is free (the version of the data which can be differentiated etc. is desirable).
When the [ROM coll data area] of [E2PROM] is read at the time of a reset start and data exists, it processes by judging whether it is
by the [ROM coll] data which should be applied.
In the case of the data which should be applied [good] : It progresses to the following step by un-processing.
In the case of the data which should be applied and which does not come out, it is [no] : All the [ROM coll data area] of [E2PROM] is cleared (FF).
