Power board (Only US,UX,UG)
Block No. [0][3]
R6101 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J B,E,EN,
EV
R6101 NRSA63J-201X MG RESISTOR 200 Ω 1/16W J A
R6102 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R6103 NRSA63J-241X MG RESISTOR 240 Ω 1/16W J
R6104 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R6105 NRSA63J-241X MG RESISTOR 240
Ω 1/16W J
R6106 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6201 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R6202 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R6203 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R6204 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R6205 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R7001 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7002 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
R7003 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
R7603 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R7605 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R7606 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R7608 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R7609 NRSA63J-133X MG RESISTOR 13k Ω 1/16W J
R7610 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7611 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R7613 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7614 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R7615 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R7616 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R7617 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R7618 NRSA63J-303X MG RESISTOR 30k Ω 1/16W J
R7619 NRSA63J-303X MG RESISTOR 30k Ω 1/16W J
R7620 NRSA63J-303X MG RESISTOR 30k Ω 1/16W J
R7621 NRSA63J-303X MG RESISTOR 30k Ω 1/16W J
R7624 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7625 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7626 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7627 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7628 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R7629 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7630 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7631 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7632 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7633 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7634 NRSA63J-511X MG RESISTOR 510 Ω 1/16W J
R7635 NRSA63J-511X MG RESISTOR 510 Ω 1/16W J
R7636 NRSA63J-511X MG RESISTOR 510 Ω 1/16W J
R7637 NRSA63J-511X MG RESISTOR 510 Ω 1/16W J
R7638 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7639 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7640 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
 T1101 QQT0545-002 POWER TRANSF
CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
CN102 QGA7901C1-04 CONNECTOR W-B (1-4)
CN103 QGA3901C1-05 CONNECTOR W-B (1-5)
CN104 QGA2502C1-05 CONNECTOR W-B (1-5)
CN105 QJK012-052000-E SIN CR C-B WIRE
CN106 QJK050-092804-E SIN CR C-B WIRE
CN514 QGB2510K2-13 CONNECTOR B-B (1-13)
CN524 QGB2510K2-13 CONNECTOR B-B (1-13)
CN601 QGF1036F2-09 CONNECTOR FFC/FPC (1-9)
CN602 QGF1036F2-29 CONNECTOR FFC/FPC (1-29)
CN761 QGF1036F2-13 CONNECTOR FFC/FPC (1-13)
DI601 QLF0189-001 FL TUBE
EP101 E409182-001SM GRAND TERMINAL
FC101 QNG0003-001Z FUSE CLIP
FC102 QNG0003-001Z FUSE CLIP
FC121 QNG0003-001Z FUSE CLIP
FC122 QNG0003-001Z FUSE CLIP
FC123 QNG0003-001Z FUSE CLIP
FC124 QNG0003-001Z FUSE CLIP
FC131 QNG0003-001Z FUSE CLIP
FC132 QNG0003-001Z FUSE CLIP
FC133 QNG0003-001Z FUSE CLIP
FC134 QNG0003-001Z FUSE CLIP
FW603 QUM024-07Z4Z4-E 1.25 CONNECTOR
FW605 QUM022-08Z4Z4-E PARA RIBON WIRE
 HS121 GN30233-201A HEATSINK
 Symbol No. Part No. Part Name Description Local
J7001 QNS0276-001 JACK
J7601 QNZ0915-002 SEMENS CONNECT
K7001 NQR0007-002X FERRITE BEADS
K7002 NQR0007-002X FERRITE BEADS
K7003 NQR0007-002X FERRITE BEADS
K7004 NQR0007-002X FERRITE BEADS
K7604 NQR0022-002X FERRITE BEADS
K7605 NQR0022-002X FERRITE BEADS
K7606 NQR0502-001X FERRITE BEADS
 RY101 QSK0163-001 RELAY
S6201 QSW0683-001Z PUSH SW
S6202 QSW0683-001Z PUSH SW
S6203 QSW0683-001Z PUSH SW
S6204 QSW0683-001Z PUSH SW
S6205 QSW0683-001Z PUSH SW
S6206 QSW0683-001Z PUSH SW
S6207 QSW0683-001Z PUSH SW
W601 QUB220-09DMHP-E SIN TWIST WIRE B,E,EN,
EV
 Symbol No. Part No. Part Name Description Local
 IC111 KIA7806API IC
IC601 PT6315 IC
IC611 NJL23H380A-E IC
IC701 KIA4558F-X IC
IC702 BU9253FS-X IC
IC703 MM1615AN-X IC
IC761 NJM4565M-WE IC
IC762 NJM2717M-X IC
Q1001 RT1N141C-X DIGI TRANSISTOR
 Q1101 KTC2026/Y/ TRANSISTOR
Q1401 KTC3203/OY/-T TRANSISTOR
 Q1402 KTA1046/Y/ TRANSISTOR
Q2501 RT3WLMM/EF/-X PAIR TRANSISTOR
Q2511 RT3WLMM/EF/-X PAIR TRANSISTOR
Q2521 RT3WLMM/EF/-X PAIR TRANSISTOR
Q6101 RT1N141C-X DIGI TRANSISTOR
Q6102 RT1N141C-X DIGI TRANSISTOR
Q7101 RT1N141C-X DIGI TRANSISTOR
Q7102 2SC2412K/R/-X TRANSISTOR
Q7103 2SC2412K/R/-X TRANSISTOR
Q7104 2SA1037AK/RS/-X TRANSISTOR
D1001 1SS133-T2 SI DIODE
 D1101 1A3G-T1 SI DIODE
 D1102 1A3G-T1 SI DIODE
 D1103 1A3G-T1 SI DIODE
 D1104 1A3G-T1 SI DIODE
D1105 1SS133-T2 SI DIODE
D1106 1SS133-T2 SI DIODE
D1107 MTZJ12B-T2 Z DIODE
D1108 MTZJ6.8B-T2 Z DIODE
 D1201 GBU803 BRIDGE DIODE
 D1202 GBU803 BRIDGE DIODE
 D1301 2A02-M DIODE
 D1302 2A02-M DIODE
D1401 MTZJ6.2B-T2 Z DIODE
D1402 MTZJ30C-T2 Z DIODE
D6101 SLR-343VC-T LED
D6102 SDPB50A0/GH/ LED
D6301 SDPB50A0/GH/ LED
D7101 1SS133-T2 SI DIODE
D7102 1SS133-T2 SI DIODE
D7103 1SS133-T2 SI DIODE
 C1001 QCZ9132-472 C CAPACITOR 4700pF
 C1011 QCZ9079-102 C CAPACITOR 1000pF AC250V M
C1101 QFLC2AJ-472Z M CAPACITOR 4700pF 100V J
C1101 or QFNC2AJ-472Z M CAPACITOR 4700pF 100V J
 Symbol No. Part No. Part Name Description Local
