JVC TH-D7B

3-21
DVD module board
Block No. [0][6]
C1062 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1070 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1071 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R1001 NRSA63F-433X MG RESISTOR 43k Ω 1/16W F
R1002 NRSA63F-472X MG RESISTOR 4.7k
Ω 1/16W F
R1004 NRSA63F-511X MG RESISTOR 510
Ω 1/16W F
R1021 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1022 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1025 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1026 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1027 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1044 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R1045 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R1046 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1047 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1048 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R1049 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1050 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1051 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1052 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1053 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1054 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1055 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1056 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1058 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1060 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1061 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1063 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1065 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1066 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1068 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1069 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1070 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1071 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1073 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1074 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1075 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1077 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1078 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1080 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1081 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1082 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1083 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1084 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1086 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1087 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1089 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1091 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1092 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
L1001 NQR0597-001X EMI FILTER
L1002 NQR0597-001X EMI FILTER
L1003 NQR0597-001X EMI FILTER
L1004 NQR0597-001X EMI FILTER
CN1 QGF1016F8-08W CONNECTOR FFC/FPC (1-8)
CN2 QGB2027L1-26X CONNECTOR B-B (1-26)
J1001 NNZ0161-002 CONNECTOR
J1002 NNZ0161-002 CONNECTOR
K1001 NQR0502-001X FERRITE BEADS
K1002 NQR0502-001X FERRITE BEADS
K1003 NQR0502-001X FERRITE BEADS
K1004 NQR0502-001X FERRITE BEADS
K1005 NQR0502-001X FERRITE BEADS
K1006 NQR0502-001X FERRITE BEADS
K1007 NQR0502-001X FERRITE BEADS
K1008 NQR0502-001X FERRITE BEADS
K1009 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K1010 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K1011 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
VA1 NAF0024-001X ESD SUPPRESSOR V
VA2 NAF0024-001X ESD SUPPRESSOR V
VA3 NAF0024-001X ESD SUPPRESSOR V
VA4 NAF0024-001X ESD SUPPRESSOR V
VA5 NAF0024-001X ESD SUPPRESSOR V
VA6 NAF0024-001X ESD SUPPRESSOR V
VA7 NAF0024-001X ESD SUPPRESSOR V
 Symbol No. Part No. Part Name Description Local
VA8 NAF0024-001X ESD SUPPRESSOR V
VA9 NAF0018-800X VARISTOR 80V
VA10 NAF0018-800X VARISTOR 80V
VA11 NAF0018-800X VARISTOR 80V
VA23 NAF0024-001X ESD SUPPRESSOR V
VA24 NAF0024-001X ESD SUPPRESSOR V
VA25 NAF0024-001X ESD SUPPRESSOR V
VA26 NAF0024-001X ESD SUPPRESSOR V
VA27 NAF0024-001X ESD SUPPRESSOR V
VA28 NAF0024-001X ESD SUPPRESSOR V
VA29 NAF0024-001X ESD SUPPRESSOR V
VA30 NAF0024-001X ESD SUPPRESSOR V
VA31 NAF0018-800X VARISTOR 80V
VA32 NAF0018-800X VARISTOR 80V
VA33 NAF0018-800X VARISTOR 80V
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0018MA IC
IC302 MM1701CH-X IC
IC303 XC2164A51FM-X IC
IC305 MM1563DF-X IC
IC453 S-80830CNNB-G-W IC
IC505 K4S641632K-UC75 IC
IC505 or K4S641632H-UC75 IC
IC509 ------------ IC(MICRO C ROM)
IC510 BR24L32F-W-X IC(DIGITAL)
IC512 TC74LCX373FT-X IC(DIGITAL)
IC513 TC74LCX373FT-X IC(DIGITAL)
IC701 AK4387ET-X IC
IC702 AK4387ET-X IC
IC703 AK4387ET-X IC
IC704 AK5358ET-X IC
IC704 or AK5358AET-X IC
IC705 MM1615AN-X IC
IC801 MM1565AF-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q801 KRA104S-X DIGI TRANSISTOR
Q801 or UN2113-X TRANSISTOR
C101 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C106 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C107 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C108 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C201 NDC31HJ-221X C CAPACITOR 220pF 50V J
C202 NDC31HJ-221X C CAPACITOR 220pF 50V J
C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 NCB31HK-271X C CAPACITOR 270pF 50V K
C206 NDC31HJ-151X C CAPACITOR 150pF 50V J
C210 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C261 NCB31HK-223X C CAPACITOR 0.022uF 50V K
 Symbol No. Part No. Part Name Description Local
