JVC TH-D7B

3-23
DVD loading switch board
Block No. [0][7]
R337 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R338 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R339 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R340 NRSA63D-303X MG RESISTOR 30k Ω 1/16W D
R341 NRSA63D-512X MG RESISTOR 5.1k Ω 1/16W D
R342 NRSA63D-222X MG RESISTOR 2.2k
Ω 1/16W D
R345 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R346 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R347 NRSA63J-203X MG RESISTOR 20k Ω 1/16W J
R348 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R351 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R352 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R353 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R354 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R355 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R356 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R357 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R358 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R359 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R360 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R361 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R362 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R364 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R365 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R367 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R369 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R370 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R371 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R372 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R373 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R374 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R375 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R376 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R377 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R380 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R381 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R382 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R383 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R384 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R385 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R386 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R387 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R388 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R389 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R390 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R392 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R458 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R531 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R535 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R541 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R542 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R701 NRSA63J-2R2X MG RESISTOR 2.2
Ω 1/16W J
R714 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R715 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R716 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R718 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R719 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R721 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R722 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R723 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R724 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R725 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R726 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R727 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R728 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R730 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R731 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R732 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R741 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R742 NRSA63J-5R1X MG RESISTOR 5.1 Ω 1/16W J
R811 NRS181J-330X MG RESISTOR 33
Ω 1/8W J
R812 NRS181J-330X MG RESISTOR 33
Ω 1/8W J
R813 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R814 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R819 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R859 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R860 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R861 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R921 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R922 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
CN101 QGF0523F3-24W CONNECTOR FFC/FPC (1-24)
CN201 QGF1037F3-08W CONNECTOR FFC/FPC (1-8)
CN701 QGF1016F8-26W CONNECTOR FFC/FPC (1-26)
CN702 QGF1016C6-18W CONNECTOR FFC/FPC (1-18)
CN801 QGF1016C6-09W CONNECTOR FFC/FPC (1-9)
CN811 QGA2001F6-05X CONNECTOR W-B (1-5)
CN901 QGB2027MC-26X CONNECTOR B-B (1-26)
K101 NQR0502-001X FERRITE BEADS
K351 NQR0502-001X FERRITE BEADS
K352 NQR0502-001X FERRITE BEADS
K353 NQR0502-001X FERRITE BEADS
K354 NQR0022-002X FERRITE BEADS
K355 NQR0022-002X FERRITE BEADS
K360 NQR0360-002X COIL
K361 NQR0360-002X COIL
K362 NQR0360-002X COIL
K363 NQR0360-002X COIL
K364 NQR0360-002X COIL
K365 NQR0360-002X COIL
K366 NQR0360-002X COIL
K367 NQR0360-002X COIL
K370 NQR0360-002X COIL
K501 NQR0502-001X FERRITE BEADS
K701 NQR0022-002X FERRITE BEADS
K702 NQR0022-002X FERRITE BEADS
K703 NQR0022-002X FERRITE BEADS
K704 NQR0022-002X FERRITE BEADS
K705 NQR0022-002X FERRITE BEADS
K706 NQR0022-005X FERRITE BEADS
K707 NQR0022-002X FERRITE BEADS
K708 NQR0022-002X FERRITE BEADS
K709 NQR0022-002X FERRITE BEADS
K710 NQR0022-002X FERRITE BEADS
K711 NQR0022-002X FERRITE BEADS
K720 NQR0022-002X FERRITE BEADS
K721 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K722 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K726 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K811 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K812 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K912 NQR0502-001X FERRITE BEADS
TH301 NAD0025-103X N THERMISTOR 10k Ω
X301 NAX0741-001X CRYSTAL 27.000MHz
X302 NAX0376-002X CRYSTAL
 Symbol No. Part No. Part Name Description Local
CN1 QGF1016F9-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1074-001 DETECT SWITCH
