7 Center unit
(XV-THM606/XV-THM603/XV-THM505/XV-THM501/
XV-THM303/XV-THM301)
Audio section
Total Harmonic Distortion 0.02 %
NOTE: This value is measured at System cord CONNECTOR for
reference.
Digital input*
1
:
DIGITAL IN (DBS): –21 dBm to –15 dBm
(OPTICAL) (660 nm E30 nm)
*
1
Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz)
Video section
Video System: NTSC
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video output level
Composite: 1.0 V(p-p)/75 C
S-video-Y: 1.0 V(p-p)/75 C
S-video-C: 0.286 V(p-p)/75 C
Component-Y: 1.0 V(p-p)/75 C
Component-P
B/PR: 0.7 V(p-p)/75 C
Video input sensitivity/Impedance (VCR IN)
Composite: 1.0 V(p-p)/75 C
S-video-Y: 1.0 V(p-p)/75 C
S-video-C: 0.286 V(p-p)/75 C
Tuner section
Tuning Range
FM: 87.5 MHz to 108.0 MHz
AM: 530 kHz to 1 710 kHz
General
Power Requirements: AC 120 V l, 60 Hz
Power Consumption: 18 W (at operation)
2.0 W (in standby mode)
Dimensions (W M H M D):
400 mm M 85 mm M 380 mm
(15-3/4 inches M 3-3/8 inches M 15
inches)
Mass: 4.3 kg (9.5 lbs)
7 Subwoofer (SP-PWM606)
Amplifier section
Front/Center/Surround: 140 W per channel, RMS at 4 C at
1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 300 W, RMS at 4 C at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 25 cm (9-7/8 inches) Bass-reflex,
Magnetically Shielded
Frequency Range: 25 Hz to 200 Hz
General
Power Requirements: AC 120 V l, 60 Hz
Power Consumption: 155 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
255 mm M 480 mm M 445 mm
(10-1/16 inches M 18-15/16 inches M
17-9/16 inches)
Mass: 13.0 kg (28.7 lbs)
7 Subwoofer (SP-PWM505/SP-PWM501)
Amplifier section
Front/Center/Surround: 140 W (80 W*
2
) per channel, RMS at
4 C (Center/Surround)/ 140 W
(120 W*
2
) per channel, RMS at 4 C
(Front)
at 1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 300 W, RMS at 4 C at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 25 cm (9-7/8 inches) Bass-reflex,
Magnetically Shielded
Frequency Range: 20 Hz to 200 Hz
General
Power Requirements: AC 120 V l, 60 Hz
Power Consumption: 155 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
256 mm M 482 mm M 460 mm
(10-1/8 inches M 19 inches M
18-1/8 inches)
Mass: 18.5 kg (41 lbs)
*
2
For SP-PWM501
7 Subwoofer
(SP-PWM603/SP-PWM303/SP-PWM301)
Amplifier section
Front/Center/Surround: 115 W (100 W*
3
) per channel, RMS at
4 C (Center/Surround)/ 125 W
(115 W*
3
) per channel, RMS at 4 C
(Front)
at 1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 125 W (120 W*
3
), RMS at 4 C at
100 Hz, with 10 % total harmonic
distortion.
Speaker section
Speaker unit: 16 cm (6-5/16 inches) Bass-reflex,
Magnetically Shielded
Frequency Range: 30 Hz to 200 Hz
General
Power Requirements: AC 120 V l, 60 Hz
Power Consumption: 125 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
168.5 mm M 412 mm M 444 mm
(6-11/16 inches M 16-1/4 inches M
17-1/2 inches)
Mass: 12.0 kg (26.5 lbs)
*
3
For SP-PWM301
