References
61
%
Center unit (XV-THM65/XV-THM55/XV-THM45)
Audio section
Total Harmonic Distortion 0.02 %
NOTE: This value is measured at System cord CONNECTOR for
reference.
Audio input sensitivity/Impedance (at 1 kHz)
Analog input:
AUDIO IN (VCR): 290 mV/47 kC
Digital input*:
DIGITAL IN (DBS): –21 dBm to –15 dBm
(OPTICAL) (660 nm E30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz)
Digital output (XV-THM65 only):
DIGITAL OUT –21 dBm to –15 dBm
(OPTICAL) (660 nm E30 nm)
Video section
Color System: NTSC
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video output level
Composite: 1.0 V(p-p)/75 C
S-video-Y: 1.0 V(p-p)/75 C
S-video-C: 0.286 V(p-p)/75 C
Component-Y: 1.0 V(p-p)/75 C
Component-P
B
/P
R
: 0.7 V(p-p)/75 C
Video input sensitivity/Impedance (VCR IN)
Composite: 1.0 V(p-p)/75 C
S-video-Y: 1.0 V(p-p)/75 C
S-video-C: 0.286 V(p-p)/75 C
Tuner section
Tuning Range
FM: 87.5 MHz to 108.0 MHz
AM: 530 kHz to 1 710 kHz
General
Power Requirements: AC 120 V Ó, 60 Hz
Power Consumption: 20 W (at operation)
1.0 W (in standby mode)
Dimensions (W M H M D):400 mm M 85 mm M 386 mm
(15-3/4 inches M 3-3/8 inches M 15-
1/14 inches)
Mass: 4.6 kg (10.2 lbs)
%
Subwoofer (SP-PWM65)
Amplifier section
Front/Center/Surround: 100 W per channel, RMS at 4 C at
1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 120 W, RMS at 4 C at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 20 cm (8 inches) Bass-reflex,
Magnetically Shielded
Frequency Range: 25 Hz to 200 Hz
General
Power Requirements: AC 120 V Ó, 60 Hz
Power Consumption: 150 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):235 mm M 355 mm M 492 mm
(9-5/16 inches M 14 inches M 19-3/8
inches)
Mass: 13.0 kg (28.7 lbs)
%
Subwoofer (SP-PWM55)
Amplifier section
Front/Center/Surround: 100 W per channel, RMS at 4 C at
1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 120 W, RMS at 4 C at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 16 cm (6-5/16 inches) Bass-reflex,
Magnetically Shielded
Frequency Range: 30 Hz to 200 Hz
General
Power Requirements: AC 120 V Ó, 60 Hz
Power Consumption: 150 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):216 mm M 353 mm M 485 mm
(8-9/16 inches M 13-15/16 inches M
19-1/8 inches)
Mass: 12.0 kg (26.5 lbs)
%
Subwoofer (SP-PWM45)
Amplifier section
Front/Center/Surround: 80 W per channel, RMS at 6 C
(Center/Surround)/120 W per channel,
RMS at 4 C (Front)
at 1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 120 W, RMS at 4 C at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 16 cm (6-5/16 inches) Bass-reflex,
Magnetically Shielded
Frequency Range: 30 Hz to 200 Hz
General
Power Requirements: AC 120 V Ó, 60 Hz
Power Consumption: 140 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):216 mm M 353 mm M 485 mm
(8-9/16 inches M 13-15/16 inches M
19-1/8 inches)
Mass: 12.0 kg (26.5 lbs)
Specifications
TH-M65-55-45[J]-11Spec.fm Page 61 Monday, March 24, 2003 4:10 PM
