JVC TH-M603 Service Manual

1-2 (No.MB184)
SPECIFICATION
Center unit (XV-THM606/XV-THM603/XV-THM505/XV-THM501/ XV-THM303/XV-THM301)
*1: Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency - 32 kHz, 44.1 kHz, 48 kHz)
Subwoofer (SP-PWM603/SP-PWM303/SP-PWM301)
*3: For SP-PWM301
Front speakers (SP-THM303F)
Surround speakers (SP-THM303S)
Center Speaker (SP-THM303C)
Designs & specifications are subject to change without notice.
Audio section Total Harmonic Distortion 0.02%
NOTE This value is measured at System cord CONNECTOR for reference.
Digital input *1 DIGITAL IN (DBS) (OPTICAL):
-21 dBm to -15 dBm (660 nm E30 nm)
Video section
Video System NTSC
Horizontal Resolution 500 lines
Signal-to-Noise Ratio 64 dB
Video output level Composite:1.0 V(p-p)/75Ω
S-video-Y:1.0 V(p-p)/75Ω
S-video-C:0.286 V(p-p)/75Ω
Component-Y:1.0 V(p-p)/75Ω
Component-PB/PR:0.7 V(p-p)/75Ω
Video input sensitivity/Impedance
(VCR IN)
Composite:1.0 V(p-p)/75Ω
S-video-Y:1.0 V(p-p)/75Ω
S-video-C:0.286 V(p-p)/75Ω
Tuner section Tuning Range FM:87.5 MHz to 108.0 MHz
AM:530 kHz to 1 710 kHz
Power Requirements AC 120 V, 60 Hz
General Power Consumption 18 W (at operation) 2.0 W (in standby mode)
Dimensions (W × H × D) 400 mm × 85 mm × 380 mm (15-3/4 inches × 3-3/8 inches × 15 inches)
Mass 4.3 kg (9.5 lbs)
Amplifier section Front/Center/Surround 115 W (100 W *3) per channel, RMS at 4 Ω (Center/Surround)/ 125 W (115 W *3) per channel,
RMS at 4 Ω (Front) at 1 kHz, with 10 % total harmonic distortion.
Subwoofer 125 W (120 W *3), RMS at 4 Ω at 100 Hz, with 10 % total harmonic distortion.
Speaker section Speaker unit 16 cm (6-5/16 inches) Bass-reflex, Magnetically Shielded
Frequency Range 30 Hz to 200 Hz
General Power Requirements AC 120 V, 60 Hz
Power Consumption 125 W (at operation) 0 W (in standby mode)
Dimensions (W × H × D) 168.5 mm × 412 mm × 444 mm (6-11/16 inches × 16-1/4 inches × 17-1/2 inches)
Mass 12.0 kg (26.5 lbs)
Speakers 8.0 cm (3-3/16 inches) Bass-reflex, Magnetically Shielded
Power Handling Capacity 140 W
Impedance 4Ω
Frequency Range 90 Hz to 20 kHz
Dimensions (W × H × D) 106 mm × 119.5 mm × 102 mm (4-3/16 inches × 4-3/4 inches × 4-1/16 inches)
Mass 0.69 kg (1.6 lbs)
Speakers 8.0 cm (3-3/16 inches) Bass-reflex, Magnetically Shielded
Power Handling Capacity 140 W
Impedance 4Ω
Frequency Range 80 Hz to 20 kHz
Dimensions (W × H × D) 111.5 mm × 139 mm × 106.5 mm (4-7/16 inches × 5-1/2 inches × 4-1/4 inches)
Mass 0.63 kg (1.4 lbs)
Speakers 8.0 cm (3-3/16 inches) Bass-reflex, Magnetically Shielded
Power Handling Capacity 140 W
Impedance 4Ω
Frequency Range 90 Hz to 20 kHz
Dimensions (W × H × D) 106 mm × 119.5 mm × 102 mm (4-3/16 inches × 4-3/4 inches × 4-1/16 inches)
Mass 0.69 kg (1.6 lbs)
