JVC THM42 Service Manual

3-9
DVD changer mechanism
Block No. [M][K][M][M]
 Symbol No. Part No. Part Name Description Local
1 LV10743-003A CHASSIS ASSY
2 LV43278-001A SENSOR SPRING
3 LV33961-001A SENSOR SLIDER
4 LV33962-001A SENSOR BRACKET
5 QYSDST2605Z SCREW 2.6mm x 5mm(x2)
6 QVY0027-B14 S V RESISTOR
7 QYSDST2004Z SCREW 2mm x 4mm
8 QAR0164-001 MOTOR (x2)
9 LV42340-001A MOTOR PULLEY (x2)
10 LV41431-001A BELT (x2)
11 QYSPSPU1725N SCREW 1.7mm x 2.5mm(x4)
12 LV10744-002A RACK HOLDER
13 LV21406-002A LOADING RACK
14 LV43279-001A LIFT ARM ASSY
15 LV33963-001A HOOK
16 LV33964-001A HOOK STOPPER
17 QYSDST2605Z SCREW 2.6mm x 5mm(x3)
18 LV33965-005A LIFTER ASSY
19 LV21408-002A RAIL(R)
20 LV21409-002A RAIL(L)
21 LV43285-001A ROD (L)
22 LV21520-002A SIDE(R) ASSY
23 LV33974-001A SELECT LEVER
24 LV33975-001A GEAR COVER
25 LV33976-001A ELEVATOR CAM
26 LV43287-001A ELEVATOR SPRING
27 LV33977-002A CLICK SPRING
28 QYSDST2605Z SCREW 2.6mm x 5mm(x3)
29 QYSDSF2608Z SCREW 2.6mm x 8mm
30 LV10749-001A SIDE(L)
31 LV33980-001A OPEN DET.LEVER
32 QYSDST2605Z SCREW 2.6mm x 5mm(x2)
33 LV10746-002A TRAY ASSY (x5)
34 LV10750-002A TOP COVER
35 LV43289-001A ROD (x2)
36 QYSDSF2608Z SCREW 2.6mm x 8mm(x2)
37 QYSDST2605Z SCREW 2.6mm x 5mm(x2)
38 QYSDSF2608Z SCREW 2.6mm x 8mm
39 QYSDST2605Z SCREW 2.6mm x 5mm
40 QYSDST2004Z SCREW 2mm x 4mm
41 WJM0330-001A E-SI C WIRE C-F
42 WJM0331-001A E-SI C WIRE C-F
43 QUQ110-1521BF FFC WIRE
44 VYSA1R4-056 SPACER
45 LV32417-001A CLAMPER
46 LV42930-003A P.C.MAGNET
47 LV33992-001A DVD YOKE
48 LV41741-001A SPECIAL SCREW
49 LV41659-002A INSULATOR (x4)
50 LV43245-001A SPECIAL SCREW (x4)
51 LV10753-001A DVD TM BASE
52 QYSDST2605Z SCREW 2.6mm x 5mm(x3)
53 LV21414-001A DVD MOD BKT.
54 QYSDST2605Z SCREW 2.6mm x 5mm
55 QYSDST2605Z SCREW 2.6mm x 5mm(x2)
56 VYSA1R4-057 SPACER (x3)
57 LV10751-001A TM CHASSIS
58 LV10752-001A SF MOTOR BASE
59 QAR0270-001 SPINDLE MOTOR
60 LV43461-001A SPECIAL SCREW (x3)
61 QAR0251-002 MOTOR
62 VKS5557-001 F.M. GEAR
63 QUB549-08A1A1 SIN TWIST WIRE
64 QUB544-08A1A1 SIN TWIST WIRE
65 QYSPSPT2030M SCREW M2 x 3mm
66 LV33985-001A MIDDLE GEAR
67 LV33989-001A S.SHAFT HOLDER
68 QYSDST2008Z TAP SCREW M2 x 8mm(x3)
69 LV33990-001A G.SHAFT HOLDER
70 QYSDST2008Z TAP SCREW M2 x 8mm
71 LV43291-002A GUIDE SHAFT
72 LV33991-001A ADJUST SPRING
73 QYSPST2008Z TAP SCREW M2 x 8mm
74 QAL0478-001 PICK UP
75 LV33983-001A PS SPRING
76 QYSPSFT1730Z TAP SCREW M1.7 x 3mm
77 LV33984-001A RACK ARM
78 QYSPSFT1730Z TAP SCREW M1.7 x 3mm(x2)
79 LV33986-001A S.SHAFT GEAR
80 LV43293-001A SCREW SHAFT
81 LV43290-001A S.SHAFT COLLOR
82 LV33987-001A GEAR HOLDER
83 QYSPSFT2040Z TAP SCREW M2 x 4mm
84 LV33988-001A SS ADJ SPRING
85 QYSDST2008Z TAP SCREW M2 x 8mm
86 LVB30013-001A FPC
87 LV43292-002A ADJUST SCREW (x3)
 Symbol No. Part No. Part Name Description Local
