67
䡵 Setting
1
Select [AUTO PAN SET..] and press the [SET] button
● Check that the cursor is at [AUTO PAN SET..] and
press the [SET] button
● The [AUTO PAN SET] screen is displayed.
2 Set [AUTO PAN MODE] and [AUTO PAN SPEED]
● Set Auto Pan operation in the [AUTO PAN MODE] item.
[Setting value: RETURN, RIGHT, LEFT]
● Set Auto Pan rotation speed in the [AUTO PAN
SPEED] item.
[Setting value: LOW, NORMAL, HIGH]
3 Move the cursor (Z) to the [A.PAN POS.SET..]
item and press the Set button (only during
Shuttle)
The Auto Pan Position Setting screen appears.
4 Align the field angle of the start position (only
during Shuttle)
● Use the [PAN/TILT] lever and [FOCUS (NEAR) (FAR)],
[ZOOM（WIDE）（TELE)] buttons to align the screen.
● Lens operations such as focus cannot be performed at
the End Position Setting screen.
● A[START]POS.SET → B appears at the bottom left of
the setting screen.
5 Press the [SET] button (only during ARETURNB)
The start position switches to the end position.
6 Set the end position (only during Shuttle)
● Set the return position with the [PAN/TILT] lever.
● A← [END]POS.SETB appears at the bottom right of the
setting screen.
● Vertical direction and lens operations such as focus
and zoom cannot be performed at the End Position
Setting screen.
7 Press the [MENU] button
● The new auto pan position is saved and the top menu
([AUTO PAN SET] screen) is displayed.
Memo :
● Focus operation cannot be performed at the end position.
● The correct setting data is not written if the [SET] or
[MENU] button is pressed when the camera is moving.
Always check that the camera has stopped before
pressing the buttons.
● The Manual Pan Limit mode is OFF temporarily when this
menu is displayed. After the menu is completed, you can
set Manual Pan Limit without affecting the movement.
AUTO PAN/PATROL/TRACE
<
MENU
>
RETURN
<
SET
>
SUB MENU
AUTO PAN SET..
AUTO PATROL SET..
AUTO TRACE SET..
A. PAN/TRACE VIDEO..
RM. A. PAN KEY A. PAN
RM. A. PATROL KEY A. PATROL
AUTO PAN SET
AUTO PAN MODE RETURN
AUTO PAN SPEED NORMAL
A PAN POS SET..
<MENU>RETURN
[AU TO PA N / PATRO L/ T R AC E] s c r e e n
[AUTO PAN SET] screen
AUTO PAN POSITION SET
<MENU>RETURN <SET>L/R
[START] POS. SET
<SET>INVALID
DURING PAN MOVEMENT
[AUTO PAN POSITION SET] screen
(Start position)
● To operate Auto Pan in the camera, press the [AUTO
PAN] button of RM-P2580.
● For details, refer to the RM-P2580 Instruction Manual.
AUTO PAN POSITION SET
<MENU>RETURN <SET>L/R
<SET>INVALID
DURING PAN MOVEMENT
[END] POS.SET
[AUTO PAN POSITION SET] screen
(End position)
AUTO PAN POSITION SET
<MENU>RETURN <SET>L/R
<SET>INVALID
DURING PAN MOVEMENT
[END] POS.SET
To Next Page
