75
䡵 Setting
1
Place a white object at the center of the screen, under
the same lighting condition as the object to be shot
and zoom in to fill the screen with white.
2 Set [W.BALANCE] to AAWCB
● Shift up and down the [PAN/TILT] lever and move the
cursor (Z) to the [W.BALANCE] item.
● Shift the [PAN/TILT] lever (left/right) to set to AAWCB.
● A<SET>AWC EXECB appears on the screen.
3 Press the [SET] button (Start adjustment)
● AAWC OPERATIONB appears at the bottom left of the
screen when the Auto White Balance Adjustment
function is operating.
● When the appropriate white balance is acquired, AAWC
OKB is displayed.
䡵 Error Display
When auto white balance adjustment is not successful, the
following messages will be displayed.
Memo :
● [W.BALANCE] will be displayed as A- - -B and settings is
unavailable during B&W mode.
Message Cause
AWC ERROR:NG Displayed when there is little white
color in the object or when color
temperature is not appropriate.
Shoot a white object to fill the
screen thoroughly and adjust the
white balance again.
AWC ERROR:LOW
LIGHT
Displayed when illumination is too
dark. Brighten the illumination and
perform procedures again to
achieve white balance.
AWC ERROR:HIGH
LIGHT
Displayed when illumination is too
bright. Reduce the illumination
and perform procedures again to
achieve white balance.
<
MENU
>
RETURN
<
SET
>
AWC EXEC
POS.FUNCTION SET HOME
POSITION TITLE..
IRIS MODE AUTO
ExDR MODE OFF
ExDR LEVEL ---
BLC MODE OFF
W. BALANCE AWC
R GAIN 76
B GAIN 71
[POS.FUNCTION SET HOME]
screen
