3-14
CD servo board
Block No. [0][3]
R957 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R958 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R990 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R991 NRS144J-181X MG RESISTOR 180
Ω
1/4W J A,US,
UB,U
W,UP
R991 NRS144J-221X MG RESISTOR 220
Ω
1/4W J UT
L901 QQR1786-001 LINE FILTER
L952 QQL50AK-221Z COIL 220uH K
L954 QQL31AK-220Z COIL 22uH K
T901 QQS0397-001 SW TRANSF
CN901 QJK005-070502-E SIN CR C-B WIRE
CP901 ICP-N10-T IC PROTECTOR 400mA
CP901 or QMFZ050-1R5X-E FUSE 1.5A 125V
CP902 ICP-N20-T IC PROTECTOR 800mA
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
HS901 GN40147-001A HEAT SINK
P901 QGA7901C1-02 CONNECTOR W-B (1-2)
Symbol No.
Part No. Part Name Description Local
IC101 MN103SFB5KWD3 IC
IC102 MM1565AF-X IC
IC601 LA6242H-X IC
IC602 MN6627945EE IC
IC605 TC74LCX257FTF-X IC
IC721 LB1641 IC
Q101 RT1P441C-X DIGI TRANSISTOR
Q601 2SA1705/ST/-T TRANSISTOR
Q602 2SA1530A/QR/-X TRANSISTOR
D605 MC2836-X DIODE
D7201 UDZW4.3B-X DIODE
C101 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 QERF1HM-106Z E CAPACITOR 10uF 50V M
C106 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C107 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C108 NCB31HK-471X C CAPACITOR 470pF 50V K
C109 QERF1AM-227Z E CAPACITOR 220uF 10V M
C110 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C121 NDC31HJ-180X C CAPACITOR 18pF 50V J
C122 NDC31HJ-180X C CAPACITOR 18pF 50V J
C602 NCB31HK-561X C CAPACITOR 560pF 50V K
C603 NCB31HK-332X C CAPACITOR 3300pF 50V K
C604 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C605 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C606 NDC31HJ-271X C CAPACITOR 270pF 50V J
C607 NCB31HK-822X C CAPACITOR 8200pF 50V K
C608 NCB31HK-822X C CAPACITOR 8200pF 50V K
C609 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C610 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C611 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C612 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C613 NCB31HK-332X C CAPACITOR 3300pF 50V K
C614 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C615 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C616 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C617 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C618 NCB31HK-681X C CAPACITOR 680pF 50V K
C619 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C620 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C621 NCB31HK-102X C CAPACITOR 1000pF 50V K
C622 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C623 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
Symbol No.
Part No. Part Name Description Local
C624 QERF1AM-227Z E CAPACITOR 220uF 10V M
C625 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C626 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C627 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C628 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C629 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C630 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C631 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C632 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z
C633 NCB31HK-102X C CAPACITOR 1000pF 50V K
C635 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C636 NCB31HK-222X C CAPACITOR 2200pF 50V K
C637 NCB31HK-222X C CAPACITOR 2200pF 50V K
C638 NCB31HK-122X C CAPACITOR 1200pF 50V K
C639 NCB31HK-182X C CAPACITOR 1800pF 50V K
C640 NCB31EK-682X C CAPACITOR 6800pF 25V K
C641 NCB31HK-222X C CAPACITOR 2200pF 50V K
C642 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C643 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C644 QERF1AM-227Z E CAPACITOR 220uF 10V M
C645 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C646 NDC31HJ-680X C CAPACITOR 68pF 50V J
C647 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C648 QERF1AM-227Z E CAPACITOR 220uF 10V M
C649 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C650 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C651 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C652 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C653 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C654 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C655 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C660 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C661 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C662 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7201 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7202 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C7203 QERF1CM-476Z E CAPACITOR 47uF 16V M
R101 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R102 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R103 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R104 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R105 NRSA63J-200X MG RESISTOR 20
Ω
1/16W J
R106 NRSA63J-200X MG RESISTOR 20
Ω
1/16W J
R107 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R108 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R112 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R601 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R604 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R605 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R606 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R607 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R608 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R609 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R610 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R611 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R612 NRS181J-4R7X MG RESISTOR 4.7
Ω
1/8W J
R614 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R615 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R617 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R618 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R619 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R620 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R622 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R623 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R624 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R625 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R629 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R630 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R631 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R632 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R633 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R634 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R636 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R637 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R640 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R641 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R642 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
