JVC ux-ep100a - Power Board

3-13
Power board
Block No. [0][2]
R9703 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J A
R9704 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J A
R9705 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J A
R9801 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J A
R9802 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J A
R9803 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J A
R9804 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J A
R9805 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J A
R9810 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J A
R9912 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J A
R9913 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J A
L3801 QQL231K-221Y COIL 220uH K
L5101 QQL89AM-220 COIL 22uH M
L5102 QQL89AM-220 COIL 22uH M
L5103 QQR0797-002 COIL
L5201 QQL89AM-220 COIL 22uH M
L5202 QQL89AM-220 COIL 22uH M
L5203 QQR0797-002 COIL
L7001 QQL231K-100Y COIL 10uH K
L7003 QQL231K-4R7Y INDUCTOR 4.7uH K
L7004 QQL231K-100Y COIL 10uH K
CN103 QNZ0851-001 USB CONNECTOR
CN103 or QNZ0926-001 USB CONNECTOR
CN104 QGA2001C1-05 CONNECTOR W-B (1-5)
CN221 QGF1045F2-11X CONNECTOR FFC/FPC (1-11)
CN373 QGA2501C1-07 CONNECTOR W-B (1-7)
CN431 QGF1044F2-13X CONNECTOR FFC/FPC (1-13)
CN432 QGF1040C1-13 CONNECTOR FFC/FPC (1-13)
CN471 QNZ0915-002 SEMENS CONNECT A
CN701 QGF1040C1-11 CONNECTOR FFC/FPC (1-11)
CN708 QGA2001C1-05 CONNECTOR W-B (1-5)
CN709 QGF1040C1-23 CONNECTOR FFC/FPC (1-23)
CN801 QGB2510J1-04 CONNECTOR B-B (1-4)
CN802 QGB2510K2-04 CONNECTOR B-B (1-4)
CN911 QGF1208C1-11 CONNECTOR FFC/FPC (1-11) A,US,UB,
UW,UT
CN911 QGF1208C1-15 CONNECTOR FFC/FPC (1-15) UP
DI221 QLF0186-002 FL TUBE
DI221 or QLF0190-001 FL TUBE
J4351 QNS0188-001 JACK
J4352 QNS0188-001 JACK
J5001 QNB0311-001 SPK TERMINAL
J8001 QNS0188-001 JACK
K102 NQR0627-002X FERRITE
K103 NQR0627-002X FERRITE
K105 NQR0022-002X FERRITE BEADS
K106 NQR0022-002X FERRITE BEADS
K901 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K4351 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K4602 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K4703 NQR0502-002X FERRITE BEADS A
K4704 NQR0389-003X FERRITE BEADS A
K4705 NQR0389-003X FERRITE BEADS A
K4706 NQR0389-003X FERRITE BEADS A
K4710 NQR0389-003X FERRITE BEADS A
K4711 NQR0389-003X FERRITE BEADS A
K5101 NQR0413-002X FERRITE BEADS
K5102 NQR0413-002X FERRITE BEADS
K5103 NQR0413-002X FERRITE BEADS
K5104 NQR0413-002X FERRITE BEADS
K5201 NQR0413-002X FERRITE BEADS
K5202 NQR0413-002X FERRITE BEADS
K5203 NQR0413-002X FERRITE BEADS
K5204 NQR0413-002X FERRITE BEADS
K7001 NQR0389-003X FERRITE BEADS
K7002 NQR0389-003X FERRITE BEADS
K8101 NQR0389-003X FERRITE BEADS
K8201 NQR0389-003X FERRITE BEADS
K8301 NQR0389-003X FERRITE BEADS
K9700 NQR0389-003X FERRITE BEADS A
K9701 NQR0389-003X FERRITE BEADS A
K9702 NQR0389-003X FERRITE BEADS A
R7085 NRSA63J-133X MG RESISTOR 13k Ω 1/16W J UW
S2501 NSW0306-001X TACT SWITCH
S2502 QSW1120-001Z PUSH SW
S2503 QSW1120-001Z PUSH SW
 Symbol No. Part No. Part Name Description Local
S2504 QSW1120-001Z PUSH SW
S2505 NSW0306-001X TACT SWITCH
S2506 QSW1120-001Z PUSH SW
S2507 QSW1120-001Z PUSH SW
S2508 QSW1120-001Z PUSH SW
X7001 QAX0902-001 CRYSTAL
X7001 or QAX0902-002 CRYSTAL
X7001 or QAX0902-003 CRYSTAL
X7001 or QAX0902-004 CRYSTAL
 Symbol No. Part No. Part Name Description Local
 IC901 MIP4170MDSLJ SW-IC
IC902 KIA431A-T IC
IC903 PQ1CG21H2FZ IC Regulator
 D901 KBJ4J BRIDGE DIODE
 D902 SF27-B351C FR DIODE
 D903 SF27-B351C FR DIODE
 D904 FR104-A124-T5 FR DIODE
D905 RB520S-30-X SB DIODE
D952 EC30HA04-X SB DIODE
 D954 MBR10100 SB DIODE
D955 UDZW6.8B-X Z DIODE
 D956 FR104S-T5 FR DIODE
 D957 FR104S-T5 FR DIODE
 PC901 PC123Y22FZ PHOTO COUPLER
 C902 QFZ9073-154 MM CAPACITOR 0.15uF AC250V M
 C903 QCZ9079-222 C CAPACITOR 2200pF AC250V M
 C905 QFZ9073-683 MM CAPACITOR 0.068uF AC250V M
 C907 QEZ0858-826 E CAPACITOR 82uF
 C908 QCZ0131-331 C CAPACITOR 330pF 2kV K
 C909 QCZ0131-472 C CAPACITOR 4700pF 2kV K
C910 QEZ0658-107Z E CAPACITOR 100uF
C911 QCZ0403-221 C CAPACITOR 220pF 2kV K
C912 NCJ31HK-104X-A C CAPACITOR 0.1uF 50V K
C912 or NCB31HK-104X C CAPACITOR 0.1uF 50V K
C913 NCJ31HK-104X-A C CAPACITOR 0.1uF 50V K
C913 or NCB31HK-104X C CAPACITOR 0.1uF 50V K
C914 NDC31HJ-120X C CAPACITOR 12pF 50V J
C915 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C916 NDC31HJ-331X C CAPACITOR 330pF 50V J
C917 NCJ31HK-104X-A C CAPACITOR 0.1uF 50V K
C917 or NCB31HK-104X C CAPACITOR 0.1uF 50V K
 C918 QCZ9079-102 C CAPACITOR 1000pF AC250V M
C951 QEZ0658-396Z E CAPACITOR 39uF 50V M
C953 QETN1CM-227Z E CAPACITOR 220uF 16V M
C954 QEZ0654-108Z E CAPACITOR 1000uF 10V M
C955 QEZ0654-107Z E CAPACITOR 100uF
C956 NCJ31HK-104X-A C CAPACITOR 0.1uF 50V K
C956 or NCB31HK-104X C CAPACITOR 0.1uF 50V K
C957 QEZ0655-108Z E CAPACITOR 1000uF
C958 QETN1CM-227Z E CAPACITOR 220uF 16V M
C960 NCB31CK-105X C CAPACITOR 1uF 16V K
C961 QEZ0655-108Z E CAPACITOR 1000uF
C970 NCB31HK-222X C CAPACITOR 2200pF 50V K
 R901 QRZ9037-335 COMP RESISTOR 3.3M Ω 1/2W K
 R903 QRL02DJ-223X OMF RESISTOR 22k Ω 2W J
R904 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R905 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R908 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R909 NRSA63J-432X MG RESISTOR 4.3k
Ω 1/16W J
R911 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R951 NRSA63J-752X MG RESISTOR 7.5k
Ω 1/16W J
R952 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R953 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R954 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R955 NRSA63J-202X MG RESISTOR 2k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
