JVC UX-G38B User Manual

3-10
Input board
Block No. [0][2]
K103 NQR0502-002X FERRITE BEADS
K105 NQR0022-002X FERRITE BEADS
K106 NQR0022-002X FERRITE BEADS
K4351 NRSA63J-0R0X MG RESISTOR
K4602 NRSA63J-0R0X MG RESISTOR
K8101 NQR0389-003X FERRITE BEADS
K8201 NQR0389-003X FERRITE BEADS
K8301 NQR0389-003X FERRITE BEADS
P901 QGA7901C1-02 CONNECTOR
S2501 QSW0825-001Z TACT SW
S2502 QSW0825-001Z TACT SW
S2503 QSW0825-001Z TACT SW
S2504 QSW0825-001Z TACT SW
S2505 QSW0825-001Z TACT SW
S2506 QSW0825-001Z TACT SW
S2507 QSW0825-001Z TACT SW
S2509 QSW0825-001Z TACT SW
S2510 QSW0825-001Z TACT SW
S2511 QSW0825-001Z TACT SW
S2512 QSW0825-001Z TACT SW
W901 QZW0112-001 WIRE CLAMP
 Symbol No. Part No. Part Name Description Local
IC303 LC75345M-X IC
IC372 RT9164A-PG-X IC
IC373 MM1594AF-X IC
IC452 NJM4565M-WE IC
IC452 or LM358DR-X IC
IC501 TPA3100D2PHP-W IC
IC701 MN101E16KAC IC
IC702 BR24L02F-W-X IC(DIGITAL)
IC801 NJM4565M-WE IC
Q3401 KTB772/Y/ TRANSISTOR
Q3402 2SC3928A/QR/-X TRANSISTOR
Q3501 KTA1046/Y/ TRANSISTOR
Q3502 2SC3928A/QR/-X TRANSISTOR
Q3601 2SC5938A/B/-X TRANSISTOR
Q3602 2SC5938A/B/-X TRANSISTOR
Q3701 2SC3576-JVC-T TRANSISTOR
Q3702 RT1P441C-X DIGI TRANSISTOR
Q3710 KTA1267/YG/-T TRANSISTOR
Q3801 KTB772/Y/ TRANSISTOR
Q3802 2SC3928A/QR/-X TRANSISTOR
Q3803 RT1P430C-X TRANSISTOR
Q3804 RT1N141C-X DIGI TRANSISTOR
Q4501 RT1N44HC-X DIGI TRANSISTOR
Q4502 2SA1530A/QR/-X TRANSISTOR
Q4503 RT1N431C-X TRANSISTOR
Q4601 KTC812T-X IC
Q4603 RT1P441C-X DIGI TRANSISTOR
Q4604 KTC812T-X IC
Q4606 RT1P141C-X DIGI TRANSISTOR
Q7001 RT1N430C-X TRANSISTOR
Q7002 RT1N430C-X TRANSISTOR
Q7003 2SA1530A/QR/-X TRANSISTOR
Q8102 KTC812T-X IC
Q8103 KTC812T-X IC
Q8301 RT1P431C-X IC
D3305 MC2838-X DIODE
D3401 1SS133-T2 SI DIODE
D3402 MTZJ6.8B-T2 Z DIODE
D3403 1SS133-T2 SI DIODE
D3501 MTZJ4.3B-T2 Z DIODE
D3502 1SS133-T2 SI DIODE
D3503 1SS133-T2 SI DIODE
D3504 1N4003S-T5 SI DIODE
D3506 1N4003S-T5 SI DIODE
D3507 1N4003S-T5 SI DIODE
 Symbol No. Part No. Part Name Description Local
D3701 MTZJ30C-T2 Z DIODE
D3703 FR104S-T5 FR DIODE
D3704 1SS133-T2 SI DIODE
D3705 MTZJ2.4B-T2 Z DIODE
D3801 MTZJ12B-T2 Z DIODE
D3802 MTZJ3.3B-T2 Z DIODE
D3803 1SS133-T2 SI DIODE
D4501 1SS133-T2 SI DIODE
D5001 MC2838-X DIODE
D5101 MC2838-X DIODE
D5301 MC2838-X DIODE
D7001 1SS133-T2 SI DIODE
D7002 MTZJ3.3B-T2 Z DIODE
D7003 MC2838-X DIODE
C3140 QFVF1HJ-154Z MF CAPACITOR
C3141 QFVF1HJ-154Z MF CAPACITOR
C3142 QFVF1HJ-104Z MF CAPACITOR
C3143 QFVF1HJ-104Z MF CAPACITOR
C3144 QFLC1HJ-272Z M CAPACITOR
C3145 QETN1HM-475Z E CAPACITOR
C3148 QETN1HM-104Z E CAPACITOR
C3149 QTE1J46-106Z E CAPACITOR
C3150 QETN1CM-226Z E CAPACITOR
C3151 NCB31HK-223X C CAPACITOR
C3152 NCB31EK-683X C CAPACITOR
C3153 NCB31EK-683X C CAPACITOR
C3154 QFVF1HJ-474Z MF CAPACITOR
C3155 QETN1HM-475Z E CAPACITOR
C3156 QETN1HM-475Z E CAPACITOR
C3240 QFVF1HJ-154Z MF CAPACITOR
C3241 QFVF1HJ-154Z MF CAPACITOR
C3242 QFVF1HJ-104Z MF CAPACITOR
C3243 QFVF1HJ-104Z MF CAPACITOR
C3244 QFLC1HJ-272Z M CAPACITOR
C3245 QETN1HM-475Z E CAPACITOR
C3248 QETN1HM-104Z E CAPACITOR
C3249 QTE1J46-106Z E CAPACITOR
C3250 QETN1CM-226Z E CAPACITOR
C3251 NCB31HK-223X C CAPACITOR
C3252 NCB31EK-683X C CAPACITOR
C3253 NCB31EK-683X C CAPACITOR
C3254 QFVF1HJ-474Z MF CAPACITOR
C3255 QETN1HM-475Z E CAPACITOR
C3256 QETN1HM-475Z E CAPACITOR
C3311 QETN1HM-105Z E CAPACITOR
C3312 QETN1HM-106Z E CAPACITOR
C3341 QETN1AM-227Z E CAPACITOR
C3342 QETN1AM-227Z E CAPACITOR
C3401 QETN1HM-106Z E CAPACITOR
C3402 NCB31HK-103X C CAPACITOR
C3404 QETN1CM-107Z E CAPACITOR
C3501 QETN1HM-106Z E CAPACITOR
C3502 NCB31HK-103X C CAPACITOR
C3503 QETN1CM-107Z E CAPACITOR
C3511 QETN1CM-477Z E CAPACITOR
C3711 NCB31CK-105X C CAPACITOR
C3712 QETN1CM-107Z E CAPACITOR
C3713 NCB31CK-105X C CAPACITOR
C3714 NCB31CK-105X C CAPACITOR
C3715 QETN1CM-107Z E CAPACITOR
C3716 NCB31HK-471X C CAPACITOR
C3717 NCB31CK-105X C CAPACITOR
C3723 QETN1CM-107Z E CAPACITOR
C3801 QETN0JM-476Z E CAPACITOR
C3802 QETN1CM-107Z E CAPACITOR
C3803 NCB31HK-103X C CAPACITOR
C4501 QETN1HM-106Z E CAPACITOR
C4502 QETN1EM-476Z E CAPACITOR
C4503 QETN1EM-476Z E CAPACITOR
C4510 NCB31CK-224X C CAPACITOR
C4601 NDC31HJ-471X C CAPACITOR
C4602 NDC31HJ-471X C CAPACITOR
C4603 QETN1HM-106Z E CAPACITOR
C4607 NDC31HJ-101X C CAPACITOR
C4608 NDC31HJ-101X C CAPACITOR
C5101 NDC31HJ-331X C CAPACITOR
C5102 NCB21AK-225X C CAPACITOR
 Symbol No. Part No. Part Name Description Local
