JVC UX-G38B User Manual

3-14
CD loading switch board
Block No. [0][4]
R650 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R651 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R652 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R653 NRSA63J-512X MG RESISTOR 5.1k Ω 1/16W J
R654 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R655 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R656 NRSA63J-113X MG RESISTOR 11k
Ω 1/16W J
R657 NRS181J-220X MG RESISTOR 22 Ω 1/8W J
R658 NRS181J-220X MG RESISTOR 22 Ω 1/8W J
R660 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R668 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R670 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R671 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R672 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L101 QQL232K-100Z COIL 10uH K
CN101 WJP0093-004A-E USB CONNECTOR
CN201 QJK043-050600-E CONNECTOR
CN202 QGF0501F8-15X CONNECTOR FFC/FPC (1-15)
CN203 QGF1040F1-23 CONNECTOR FFC/FPC (1-23)
CN721 QGF1040F1-05 CONNECTOR FFC/FPC (1-5)
S201 QSW1223-001 TACT SW
X101 QAX0724-001Z CRYSTAL 12.000000MHz
X601 QAX0714-001Z C RESONATOR 16.000MHz
 Symbol No. Part No. Part Name Description Local
CN1 QGF1016F9-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1074-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
