(No.MB674<Rev.003>)1-3
UX-G500VUS/UB/UN/UG/UX/A/UH/UW/UF/UP/UT
Design and specifications are subject to change without notice.
Amplifier section-CA-UXG500V
Output power 60 W (30 W + 30 W) at 4 Ω (10% THD)
Audio input AUDIO IN: Stereo min. (Ø 3.5 mm) 500 mV/50 kΩ (at “IN_LVL1”)
250 mV/50 kΩ (at ”IN_LVL2”)
125 mV/50 kΩ (at ”IN_LVL3”)
Audio output SUBWOOFER OUT 500 mV/10 kΩ
Digital output OPTICAL DIGITAL OUT -21 dBm to -15 dBm (660 nm ±30 nm)
Digital input USB MEMORY
Video out Color system NTSC/PAL (interlaced/progressive)
Composite video 1 V(p-p)/75 Ω
S-VIDEO Y (luminance) 1 V(p-p)/75 Ω
C
(chrominance burst)
PAL: 0.3 V(p-p)/75 Ω
NTSC: 0.286 V(p-p)/75 Ω
VIDEO OUT
(COMPONENT)
(Y) 1 V(p-p)/75 Ω
(PB/PR) 0.7 V(p-p)/75 Ω
Speaker impedance 4 Ω - 16 Ω
Tuner section
FM tuning range 87.50 MHz - 108.00 MHz
AM (MW)
tuning range
For Saudi Arabia 531 kHz - 1 602 kHz (at 9 kHz intervals)
530 kHz - 1 600 kHz (at 10 kHz intervals)
For other countries 531 kHz - 1 710 kHz (at 9 kHz intervals)
530 kHz - 1 710 kHz (at 10 kHz intervals)
Disc player section
Region codes Middle East 2
South East Asia, Hong Kong region: 3
Central and South America, Australia: 4
Playable disc DVD Video/CD/VCD/SVCD
CD-R/CD-RW(CD/SVCD/VCD/MP3/WMA/WAV/JPEG/MPEG-1/MPEG-2/DivX format)
DVD-R/-RW(DVD-VR/DVD Video/MP3/WMA/WAV/JPEG/MPEG-1/MPEG-2/DivX format)
+R/+RW(DVD Video/MP3/WMA/WAV/JPEG/MPEG-1/MPEG-2/DivX format)
Dynamic range 80 dB
Horizontal resolution 500 lines
Wow and flutter Immeasurable
USB section
Playable files MP3/WMA/WAV/JPEG/MPEG-1/MPEG-2/DivX format
USB specification Compatible with USB 2.0 Full Speed
Compatible device Mass storage class
Compatible system FAT16, FAT32
Bus power supply DC 5 V=500 mA
General
Power requirements AC 110 V - 240 V , 50/60 Hz
For Australia AC 240 V~ , 50 Hz
For Hong Kong region and Thailand AC 220 V~ , 50 Hz
Power consumption 35 W (at operation)
8 W (at standby)
1 W or less (at ECO mode)
Dimensions (approx.) 175 mm × 251 mm × 247 mm (W/H/D)
Mass (approx.) 2.6 kg
Speakers-SP-UXG500V
Speaker units Tweeter 1.5 cm dome x 1
Woofer 10 cm cone x 1
Impedance 4 Ω
Dimensions (approx.) 160 mm × 250 mm × 169 mm (W/H/D)
Mass (approx.) 1.8 kg each
