JVC UX-G500VB User Manual

3-14
Power board
Block No. [0][2]
R5411 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R5413 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R5501 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R5502 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5503 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R5504 NRSA63J-752X MG RESISTOR 7.5k
Ω 1/16W J
R5505 NRSA63J-113X MG RESISTOR 11k
Ω 1/16W J
R5506 NRSA63J-220X MG RESISTOR 22
Ω 1/16W J
R5507 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R5508 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5509 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5601 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R5602 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5603 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R5604 NRSA63J-752X MG RESISTOR 7.5k
Ω 1/16W J
R5605 NRSA63J-113X MG RESISTOR 11k
Ω 1/16W J
R5606 NRSA63J-220X MG RESISTOR 22
Ω 1/16W J
R5607 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R5701 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5703 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R5704 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R5705 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R5751 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5801 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R5802 NRSA63J-163X MG RESISTOR 16k
Ω 1/16W J UT
R5901 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R5902 NRSA63J-163X MG RESISTOR 16k
Ω 1/16W J UT
CN302 QGB2510J1-06 CONNECTOR B-B (1-6)
CN303 QGF1208C1-07 CONNECTOR FFC/FPC (1-7)
CN304 QGF1208C1-13 CONNECTOR FFC/FPC (1-13)
CN306 QGF1208F1-15 CONNECTOR FFC/FPC (1-15) B,E,EN,EV,EE,
UP
CN306 QGF1208F1-11 CONNECTOR FFC/FPC (1-11) A,US,UB,UW,
UX,UG,UN,UF,
UT,UH
CN308 QGF1210G1-06 CONNECTOR FFC/FPC (1-6) B,E,EN,EV,EE,
A,US,UB,UW,
UX,UG,UN
CN310 QGF1040C1-31 CONNECTOR FFC/FPC (1-31)
CN312 QGB1214J1-08S CONNECTOR B-B (1-8)
CN510 QGF1040C1-05 CONNECTOR FFC/FPC (1-5)
CN520 QGF1208C1-11 CONNECTOR FFC/FPC (1-11)
EP360 QNZ0136-001Z EARTH PLATE
J401 QNN0779-001 JACK
J402 QNN0557-002 PIN JACK A,US,UB,UW,
UX,UG,UN,UF,
UP,UT,UH
J404 QNZ0775-001 RGB CONNECTOR B,E,EN,EV,EE
J5001 QNN0780-001 PIN JACK
K3501 NQR0627-002X FERRITE 1.5K/
100MHz200mA0
.4R
K5701 QQR0621-001Z FERRITE BEADS
K5801 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
WC400 QZW0112-001 WIRE CLAMP UT
X3001 QAX0711-002Z CRYSTAL 8.000000MHz
 Symbol No. Part No. Part Name Description Local
IC600 R2A15108SP-X IC
Q6001 KRC110S-X DIGI TRANSISTOR
D6402 MC2838-X DIODE
D6601 MC2838-X DIODE
D6602 MA8033-X Z DIODE
C6001 QETN1EM-477Z E CAPACITOR 470uF 25V M
C6002 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6003 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6004 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
C6005 NCB31CK-334X C CAPACITOR 0.33uF 16V K
C6006 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6007 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6008 NCB31CK-104X C CAPACITOR 0.1uF 16V K UT
C6052 QTE1J46-106Z E CAPACITOR 10uF 63V
C6101 NCB21EK-474X C CAPACITOR 0.47uF 25V K
C6102 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6103 NCB31CK-105X C CAPACITOR 1uF 16V K
C6104 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6107 NCB31HK-472X C CAPACITOR 4700pF 50V K UT
C6110 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C6111 NCB21EK-474X C CAPACITOR 0.47uF 25V K
C6112 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6113 NCB31CK-105X C CAPACITOR 1uF 16V K
C6114 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6117 NCB31HK-472X C CAPACITOR 4700pF 50V K UT
C6152 QTE1J46-106Z E CAPACITOR 10uF 63V
C6201 NCB21EK-474X C CAPACITOR 0.47uF 25V K
C6202 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6203 NCB31CK-105X C CAPACITOR 1uF 16V K
C6204 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6207 NCB31HK-472X C CAPACITOR 4700pF 50V K UT
C6210 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C6211 NCB21EK-474X C CAPACITOR 0.47uF 25V K
C6212 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6213 NCB31CK-105X C CAPACITOR 1uF 16V K
C6214 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6217 NCB31HK-472X C CAPACITOR 4700pF 50V K UT
C6401 QEZ0863-106Z M CAPACITOR 10uF
C6511 QEZ0863-106Z M CAPACITOR 10uF
C6601 QETN1HM-105Z E CAPACITOR 1uF 50V M
C6602 QETN1HM-226Z E CAPACITOR 22uF 50V M
C6611 QETN1HM-105Z E CAPACITOR 1uF 50V M
C6613 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R6004 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6005 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R6006 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R6007 NRSA63J-184X MG RESISTOR 180k
Ω 1/16W J
R6051 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R6052 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6101 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R6103 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6111 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R6113 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6151 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R6152 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6201 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R6203 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6211 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R6213 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6401 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R6402 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R6511 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R6512 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R6601 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J UT
R6602 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R6603 NRSA63J-513X MG RESISTOR 51k
Ω 1/16W J
R6604 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R6611 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J UT
R6612 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
L6101 QQLZ043-120 COIL 12uH
L6111 QQLZ043-120 COIL 12uH
L6201 QQLZ043-120 COIL 12uH
L6211 QQLZ043-120 COIL 12uH
L6301 QQR0797-002 COIL UT
L6302 QQR0797-002 COIL UT
CN605 QGF1208C1-11 CONNECTOR FFC/FPC (1-11)
CN640 QGA3901C1-02 CONNECTOR W-B (1-2)
EP600 E409182-001SM GRAND TERMINAL
HS600 GV31137-001A HEAT SINK UT
J6001 QNB0303-001 SPK JACK
K6004 NQR0502-002X FERRITE BEADS UT
SC600 QYSDSG3008ZA TAP SCREW M3 x 8mm UT
 Symbol No. Part No. Part Name Description Local
