3-15
Primary board
Block No. [0][3]
 Symbol No. Part No. Part Name Description Local
 IC201 STR-W6765N IC
IC210 KIA431A-T IC
IC211 BD9305AFVM-W REGULATOR IC
IC212 BD9305AFVM-W REGULATOR IC
IC360 LB1641 IC
IC700 GP1UE271XKC1 IC
IC720 PT6315 IC
Q2100 KRC102S-X DIGI TRANSISTOR
Q2103 RSR025P03-X MOSFET
Q2110 KRC102S-X DIGI TRANSISTOR
Q2113 RSR025P03-X MOSFET
Q2121 KTC3265/Y/-X TRANSISTOR UT
Q2125 KTA1505/G/-X CHIP TR.
Q2126 KTC3265/Y/-X TRANSISTOR
Q2127 KRC104S-X TRANSISTOR
Q2131 KTA1504/YG/-X TRANSISTOR
Q2132 KRC104S-X TRANSISTOR
Q2160 KRC102S-X DIGI TRANSISTOR
Q2161 KRA102S-X DIGI TRANSISTOR
Q2303 KRA104S-X DIGI TRANSISTOR
Q2304 KTC3203/OY/-T TRANSISTOR
Q7300 KRC102S-X DIGI TRANSISTOR
Q7301 KRC102S-X DIGI TRANSISTOR
Q9700 KRC102S-X DIGI TRANSISTOR
Q9701 RT1N141C-X DIGI TRANSISTOR UT
 D2001 KBJ4J BRIDGE DIODE
D2002 RG1C-LFA1 SI DIODE
D2003 RG1C-LFA1 SI DIODE
D2004 FR104S-T5 FR DIODE
D2005 FR104S-T5 FR DIODE
D2006 AL01Z-T4 DIODE
D2007 MTZJ11B-T2 Z DIODE
D2008 MA8220/M/-X Z DIODE
D2009 AL01Z-T4 DIODE
D2010 MA8056/M/-X Z DIODE
D2011 MA8075/M/-X Z DIODE
D2012 MA8062/M/-X Z DIODE
D2103 MA22D23-X SB DIODE
D2113 MA22D23-X SB DIODE
D2121 FR104S-T5 FR DIODE
D2125 MA8033-X Z DIODE
D2126 MA111-X SI DIODE
D2131 FR104S-T5 FR DIODE
D2133 MA111-X SI DIODE UT
D2134 MA8024-X Z DIODE
D2135 MA8300/M/-X Z DIODE
D2151 FMX-G22S DIODE
D2160 MA8047/M/-X Z DIODE
D2301 MA8039-X Z DIODE
D2302 MA8043/M/-X Z DIODE
D2500 RL202-B322-1 SI DIODE
D3650 MA8047/M/-X Z DIODE
D3651 1N4003S-T5 SI DIODE UT
D3652 1N4003S-T5 SI DIODE UT
D3653 1N4003S-T5 SI DIODE
D3654 1N4003S-T5 SI DIODE
D3655 RL202-B322-1 SI DIODE
D3658 1N4003S-T5 SI DIODE
D7000 SLI-343U8RC-T LED
D7300 SELT1E54CM-S LED
D7301 SELT1E54CM-S LED
D7302 MA8047/M/-X Z DIODE UT
D8000 STZC6.8N-X USB ESD DIODE
D9703 SLI-343U8RC-T LED
 PC201 PC123Y22FZ PHOTO COUPLER
 PC202 PC123Y22FZ PHOTO COUPLER
 C2001 QFZ9073-154 MM CAPACITOR 0.15uF AC250V M
 C2003 QCZ9134-101 C CAPACITOR 100pF
 C2004 QCZ9134-221 M CAPACITOR 220pF B,E,EN,EV,E
E,A,US,UB,
UW,UX,UG,
UN,UF,UP,U
T
 C2004 QCZ9134-101 C CAPACITOR 100pF UH
 C2007 QFZ9073-683 MM CAPACITOR 0.068uF AC250V M
 C2008 QEZ0881-107 M CAPACITOR 100uF B,E,EN,EV,E
E,A,UB,UF,U
P, U H
C2008 QEZ0884-227 M CAPACITOR 220uF US,UW,UX,
UG,UN,UT
 C2009 QCZ0136-331Z C CAPACITOR 330pF 1kV K
 C2010 QCZ0134-472 C CAPACITOR 4700pF
C2012 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2013 NDC31HJ-221X C CAPACITOR 220pF 50V J
 C2014 QCZ0136-221Z C CAPACITOR 220pF 1kV K
C2015 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2016 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2017 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2018 NDC31HJ-471X C CAPACITOR 470pF 50V J
 C2020 QCZ9134-222 C CAPACITOR 2200pF B,E,EN,EV,E
E,A,US,UB,
UW,UX,UG,
UN,UF,UP,U
T
 C2020 QCZ9134-221 M CAPACITOR 220pF UH
C2100 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C2101 QETN1EM-476Z E CAPACITOR 47uF 25V M
C2102 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2103 NDC31HJ-201X C CAPACITOR 200pF 50V J
C2104 NCB31HK-104X C CAPACITOR 0.1uF 50V K UT
C2105 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2106 NCB31HK-471X C CAPACITOR 470pF 50V K
C2107 NCB31HK-104X C CAPACITOR 0.1uF 50V K B,E,EN,EV,E
E
C2110 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C2111 QETN1EM-476Z E CAPACITOR 47uF 25V M
C2112 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2113 NDC31HJ-201X C CAPACITOR 200pF 50V J
C2114 NCB31HK-104X C CAPACITOR 0.1uF 50V K UT
C2115 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2116 NCB31HK-471X C CAPACITOR 470pF 50V K
C2117 NCB31HK-104X C CAPACITOR 0.1uF 50V K B,E,EN,EV,E
E
C2121 QETN1AM-477Z E CAPACITOR 470uF 10V M
C2125 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2131 QEZ0658-396Z E CAPACITOR 39uF 50V M
C2133 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C2153 QETM1EM-228 E CAPACITOR 2200uF 25V M
C2155 QETN1EM-337Z E CAPACITOR 330uF 25V M
C2156 NCB31HK-104X C CAPACITOR 0.1uF 50V K B,E,EN,EV,E
E
C2157 NCB31HK-104X C CAPACITOR 0.1uF 50V K B,E,EN,EV,E
E
C2160 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C2301 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3650 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3651 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3652 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3653 QETN1VM-107Z E CAPACITOR 100uF 35V M
C3654 QETN1VM-107Z E CAPACITOR 100uF 35V M
C3655 QETN1VM-107Z E CAPACITOR 100uF 35V M
C7000 QERF0JM-107Z E CAPACITOR 100uF 6.3V M
C7201 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7209 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7210 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C7300 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7301 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7302 QER61EM-476Z E CAPACITOR 47uF 25V M UT
C8000 NDC31HJ-150X C CAPACITOR 15pF 50V J
C8001 NDC31HJ-101X C CAPACITOR 100pF 50V J
C8002 NDC31HJ-150X C CAPACITOR 15pF 50V J
C8004 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8100 NDC31HJ-331X C CAPACITOR 330pF 50V J B,E,EN,EV,E
E,UP
C8104 NCB31CK-105X C CAPACITOR 1uF 16V K
C8200 NDC31HJ-331X C CAPACITOR 330pF 50V J B,E,EN,EV,E
E,UP
C8300 NCB31HK-104X C CAPACITOR 0.1uF 50V K
 Symbol No. Part No. Part Name Description Local
