SCHEMATIC DIAGRAMS
UX-GD6S,UX-GD6M
Contents
Block diagram
Standard schematic diagrams
Printed circuit boards
2-1
2-2
2-11 to 15
CD-ROM No.SML200506
MICRO COMPONENT SYSTEM
No.MB408SCH
2005/6
COPYRIGHT 2005 Victor Company of Japan, Limited.
(CA-UXGD6S) (SP-UXGD6S)(SP-UXGD6S)
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Area suffix
A ------------------------ Australia
US ------------------------ Singapore
UT ---------------------------- Taiwan
UW ----------- Brazil,Mexico,Peru
UX -------------------- Saudi Arabia
UG --- Turkey,South Africa,Egypt
UN ----------------------------- Asean
Area suffix
UX-GD6S
UX-GD6M
UB ---------------------- Hong Kong
UF ------------------------------ China
UP ----------------------------- Korea
UT ---------------------------- Taiwan
UG --- Turkey,South Africa,Egypt
(CA-UXGD6M) (SP-UXGD6M)(SP-UXGD6M)
UX-GD6S
Speaker Tweeter:
Woofer:
UX-GD6M
4 cm cone x1
13.5 cm cone x1
Tweeter:
Woofer:
4 cm cone x1
12 cm cone x1
SUPER VIDEO
To Next Page
