1-8 (No.MB248)
3.1.3 Removing the rear cover
(See Fig.3 and 4)
(1) Remove the seven screws C that retain the rear cover from
the back of the body.
(2) Remove the eight screws D that retain the rear cover from
the two sides of the body.
(3) Remove the rear cover from the body by pulling it toward
the back.
Caution:
The FM terminal wire (inside) must be pulled out, while remov-
ing the rear cover.
Fig.3
Fig.4
Rear cove
C
C
C
D
D
D
To Next Page
