JVC UX-H30 User Manual

3-12
Cassette switch board
Block No. [0][3][0][0]
Head amplifier board
Block No. [0][4][0][0]
R7505 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R7507 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7508 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7509 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R7510 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R7511 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R7512 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R7513 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R7514 NRSA63J-363X MG RESISTOR 36k Ω 1/16W J
L1 QQR0796-003 COIL BLOCK
L3 QQL231K-4R7Y COIL 4.7uH K
L7001 QQL231K-100Y COIL 10uH K
L7002 QQL231K-470Y COIL 47uH K
L7003 QQL231K-4R7Y COIL 4.7uH K
T1 QQR0793-001 IFT
BL701 QLL0147-001 LAMP
BL702 QLL0147-001 LAMP
CF1 QAX0677-001Z C FILTER 10.700MHz
CF2 QAX0677-001Z C FILTER 10.700MHz
CF3 QAX0610-001Z C DISCRIMINATOR 10.700MHz
CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN711 QGB1214K1-20S CONNECTOR B-B (1-20)
CN712 QGF1205F1-14 CONNECTOR FFC/FPC (1-14)
CN713 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN714 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN716 QGF1205C1-04 CONNECTOR FFC/FPC (1-4)
CN717 QGF1205F1-04 CONNECTOR FFC/FPC (1-4)
DI701 QLD0260-001 LCD MODULE
EP740 E409182-001SM GRAND TERMINAL
FW701 QUM022-12Z3Z3 FLAT WIRE
J1 QNB0153-001 ANT TERMINAL
K7002 QQR0621-001Z COIL
K7003 QQR0621-001Z COIL
PP701 QZW0038-001 WIRE CLAMP
S7500 QSW0651-001Z TACT SW
S7501 QSW0651-001Z TACT SW
S7502 QSW0651-001Z TACT SW
S7503 QSW0651-001Z TACT SW
S7504 QSW0651-001Z TACT SW
S7505 QSW0651-001Z TACT SW
S7506 QSW0651-001Z TACT SW
S7507 QSW0651-001Z TACT SW
S7508 QSW0651-001Z TACT SW
S7509 QSW0651-001Z TACT SW
S7510 QSW0651-001Z TACT SW
S7511 QSW0651-001Z TACT SW
S7512 QSW0651-001Z TACT SW
S7550 QSW0122-001 PUSH SWITCH
TU1 QAU0161-001 FRONT END
X1 QAX0402-001 CRYSTAL 75.0kHz
X7001 QAX0711-002Z CRYSTAL 8.000000MHz
 Symbol No. Part No. Part Name Description Local
IC1 SG-105F3-BB,C PHOTO SENSER
IC32 HA12238F IC R/P Equalizer
IC33 CD4094BC IC
Serial to parallel
port extension
L301 QQR1118-002 OSC COIL(BIAS)
CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN31 QGF1205F1-06 CONNECTOR FFC/FPC (1-6)
CN32 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN33 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN34 QGF1201F3-10 CONNECTOR FFC/FPC (1-10)
FW100 QUM024-07A2Z3 PARA RIBON WIRE
H32 GV40397-002A IC HOLDER
P1 QNZ0104-001 POST PIN
 Symbol No. Part No. Part Name Description Local
SW1 QSW0832-001 CASS.SWITCH
SW2 QSW0832-001 CASS.SWITCH
SW5 QSW0832-001 CASS.SWITCH
SW6 QSW0859-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
Q302 2SC2001/K/-T TRANSISTOR
Q305 2SC2001/K/-T TRANSISTOR
Q342 KRA111M-T DIGI TRANSISTOR
Q343 2SC3576-JVC-T TRANSISTOR
Q344 2SC3576-JVC-T TRANSISTOR
Q345 2SC3576-JVC-T TRANSISTOR
Q346 2SC3576-JVC-T TRANSISTOR
Q347 KRC107M-T DIGI TRANSISTOR
Q371 KTA1271/OY/-T TRANSISTOR
Q372 KRC107M-T DIGI TRANSISTOR
Q375 2SB562/C/-T TRANSISTOR
Q376 KTC3199/GL/-T TRANSISTOR
D1 1SR139-400-T2 SI DIODE
D340 MTZJ5.1B-T2 Z DIODE
D375 MTZJ5.1B-T2 Z DIODE
C101 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C102 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C103 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C104 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C105 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C106 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C107 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C109 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C110 QDYB1CM-682Y C CAPACITOR 6800pF 16V M
C113 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C120 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C121 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C201 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C202 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C203 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C204 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C205 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C206 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C207 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C209 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C210 QDYB1CM-682Y C CAPACITOR 6800pF 16V M
C213 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C220 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C221 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C300 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C301 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C304 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C306 FQETJ1AM-227Z E CAPACITOR
C307 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C308 QDXB1CM-152Y C CAPACITOR 1500pF 16V M
C310 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C313 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C314 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C316 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C319 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C331 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C340 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C341 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C342 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C371 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C374 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C376 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
R101 QRE141J-512Y C RESISTOR 5.1k Ω 1/4W J
R102 QRE141J-512Y C RESISTOR 5.1k Ω 1/4W J
R104 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R105 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
