3-13
R106 QRE141J-113Y C RESISTOR 11k Ω 1/4W J
R107 QRE141J-912Y C RESISTOR 9.1k Ω 1/4W J
R108 QRE141J-273Y C RESISTOR 27k Ω 1/4W J
R110 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R116 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R121 QRE141J-153Y C RESISTOR 15k
Ω 1/4W J
R201 QRE141J-512Y C RESISTOR 5.1k
Ω 1/4W J
R202 QRE141J-512Y C RESISTOR 5.1k Ω 1/4W J
R204 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R205 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R206 QRE141J-113Y C RESISTOR 11k Ω 1/4W J
R207 QRE141J-912Y C RESISTOR 9.1k Ω 1/4W J
R208 QRE141J-273Y C RESISTOR 27k Ω 1/4W J
R210 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R216 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R221 QRE141J-153Y C RESISTOR 15k Ω 1/4W J
R301 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R302 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R303 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
 R304 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
R305 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R306 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
 R310 QRJ146J-4R7X UNF C RESISTOR 4.7 Ω 1/4W J
R313 QRE141J-2R2Y C RESISTOR 2.2 Ω 1/4W J
R314 QRE141J-153Y C RESISTOR 15k Ω 1/4W J
R315 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R327 QRE141J-474Y C RESISTOR 470k Ω 1/4W J
R335 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R336 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R337 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R338 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R339 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R340 QRE141J-681Y C RESISTOR 680 Ω 1/4W J
R341 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
R342 QRE141J-243Y C RESISTOR 24k Ω 1/4W J
R343 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R344 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R345 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R346 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R347 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
 R353 QRZ9005-100X FUSI RESISTOR 10 Ω
R371 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
R372 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R375 QRE141J-151Y C RESISTOR 150 Ω 1/4W J
R376 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
VR31 QVP0008-203Z TRIM RESISTOR 20k Ω
VR37 QVP0077-103Z TRIM RESISTOR 10k Ω
L303 QQL244K-100Z COIL 10uH K
 Symbol No. Part No. Part Name Description Local
