3-7
CD loading mechanism
Block No. [M][D][M][M]
Symbol No.
Part No. Part Name Description Local
1 VYH1238-001 LOADING BASE
2 MMN-6F1LB8K MOTOR
3 QGF1201F3-05 CONNECTOR FFC/FPC (1-5)
4 QSW0472-001 SWITCH
5 QYSPSPT2640Z SCREW 2.6mm x 4mm(x2)
6 E75984-221SS MOTOR PULLEY
7 E75950-002 C.D BELT
8 E75985-221SS C.D GEAR (1)
9 E75986-221SS C.D GEAR (2)
10 E75987-221SS C.D GEAR (3)
11 E307162-331SS LEVER
12 E307252-331SS CAM PLATE
13 E65923-003 TAPPING SCREW (x3)
14 VYH7787-001 SPRING
15 QYSBSF3008Z SCREW 3mm x 8mm
16 E307179-222SM E.BASE ASSY
17 E60912-005SS SPEED NUT
18 VMW1329-102 P W BOARD (1/5)
