UX-M5R
3-6
Item
Parts number Parts name Ar
ea
Electrical parts list (Main board)
Remarks
Block No. 01
A
C315 OW06-50475-00 E.CAPACITOR 4.7MF 50V
C316 OW06-50475-00 E.CAPACITOR 4.7MF 50V
C317 OW05-03104-03T CHIP CAPACITOR 0.1MF 10%
C318 OW05-03104-03T CHIP CAPACITOR 0.1MF 10%
C319 OW06-50105-90 E.CAPACITOR 1MF 50V 10%
C320 OW06-50105-90 E.CAPACITOR 1MF 50V 10%
C321 OW06-50475-00 E.CAPACITOR 4.7MF 50V
C322 OW06-50475-00 E.CAPACITOR 4.7MF 50V
C323 OW05-03103-06T C.CAPACITOR 0.01MF K103
C324 OW05-03103-06T C.CAPACITOR 0.01MF K103
C325 OW06-16227-00 E.CAPACITOR 220MF 16V
C326 OW05-03104-03T CHIP CAPACITOR 0.1MF 10%
C327 OW06-16337-00 E.CAPACITOR 330MF 16V
C328 OW06-16227-00 E.CAPACITOR 220MF 16V
C329 OW05-03223-06T C.CAPACITOR 0.022MF K223
C330 OW06-16476-00 E.CAPACITOR 47MF 16V
C331 OW06-16107-00 E.CAPACITOR 100MF 16V
C332 OW06-25107-00 E.CAPACITOR 100MF 25V
C333 OW05-03104-03T CHIP CAPACITOR 0.1MF 10%
C334 OW06-25228-00 E.CAPACITOR
A
2200MF 25V
C401 OW06-16227-00 E.CAPACITOR 220MF 16V
C402 OW06-16106-02 E.CAPACITOR 10MF 16V
C403 OW06-16226-00 E.CAPACITOR 22MF 16V
C404 OW06-16106-02 E.CAPACITOR 10MF 16V
C405 OW06-16106-02 E.CAPACITOR 10MF 16V
C406 OW05-03101-06T C.CAPACITOR 100PF N101J 500A
C407 OW05-03101-06T C.CAPACITOR 100PF N101J 500A
C408 OW05-03101-06T C.CAPACITOR 100PF N101J 500A
C409 OW05-03101-06T C.CAPACITOR 100PF N101J 500A
C410 OW06-50105-00 E.CAPACITOR 1MF 50V
C411 OW06-50105-00 E.CAPACITOR 1MF 50V
C412 OW05-07101-10A C.CAPACITOR 100PF 10%
C413 OW05-07101-10A C.CAPACITOR 100PF 10%
C414 OW06-16106-00 E.CAPACITOR 10MF 16V
C415 OW06-16106-00 E.CAPACITOR 10MF 16V
C416 OW05-02104-10 M.CAPACITOR 0.1MF 10%
C417 OW05-02104-10 M.CAPACITOR 0.1MF 10%
C418 OW06-35228-00 E.CAPACITOR
A
2200MF 35V
C419 OW06-35228-00 E.CAPACITOR
A
2200MF 35V
C420 OW06-16227-00 E.CAPACITOR 220MF 16V
C421 OW06-25227-00 E.CAPACITOR 220MF 25V 20%
C422 OW06-50225-00 E.CAPACITOR 2.2MF 50V
C423 OW06-50225-00 E.CAPACITOR 2.2MF 50V
C424 OW05-03101-06T C.CAPACITOR 100PF N101J 500A
C425 OW05-03101-06T C.CAPACITOR 100PF N101J 500A
C426 OW05-03101-06T C.CAPACITOR 100PF N101J 500A
C427 OW05-03101-06T C.CAPACITOR 100PF N101J 500A
C432 OW05-03101-06T C.CAPACITOR 100PF N101J 500A
C433 OW05-03101-06T C.CAPACITOR 100PF N101J 500A
C434 OW06-25227-00 E.CAPACITOR 220MF 25V 20%
C435 OW06-35477-00 E.CAPACITOR 470MF 35V
C450 OW05-07223-82A C.CAPACITOR 0.022MF
C451 OW05-00104-00 C.CAPACITOR 0.1MF 10% 50V
C452 OW06-50225-00 E.CAPACITOR 2.2MF 50V
C453 OW06-50225-02 E.CAPACITOR 2.2MF 50V
C454 OW06-25476-00 E.CAPACITOR 47MF 25V
C455 OW05-03223-06T C.CAPACITOR 0.022MF K223
C456 OW06-35477-00 E.CAPACITOR 470MF 35V
C457 OW06-50225-00 E.CAPACITOR 2.2MF 50V
C458 OW06-25476-00 E.CAPACITOR 47MF 25V
C459 OW05-00104-00 C.CAPACITOR 0.1MF 10% 50V
C463 OW05-03102-06T C.CAPACITOR 1000PF K102
C464 OW05-03102-06T C.CAPACITOR 1000PF K102
C470 OW05-03223-06T C.CAPACITOR 0.022MF K223
C471 OW05-03223-06T C.CAPACITOR 0.022MF K223
C472 OW05-03271-03T C.CAPACITOR 270PF N271J 500A
C473 OW05-03271-03T C.CAPACITOR 270PF N271J 500A
C481 OW05-00104-00 C.CAPACITOR 0.1MF 10% 50V
C482 OW05-00104-00 C.CAPACITOR 0.1MF 10% 50V
C483 OW05-00104-00 C.CAPACITOR 0.1MF 10% 50V
C484 OW05-00104-00 C.CAPACITOR 0.1MF 10% 50V
C485 OW05-00104-00 C.CAPACITOR 0.1MF 10% 50V
D101 OW02-04148-00R DIODE IN4148
D102 OW02-04148-00R DIODE IN4148
D103 OW02-04148-00R DIODE IN4148
D104 OW02-04148-00R DIODE IN4148
D105 OW02-00348-00 TUNING DIODE SVC348-S
D106 OW02-00201-00 TUNING DIODE SVC201SPA
D107 OW02-00201-00 TUNING DIODE SVC201SPA
D108 OW02-04148-00R DIODE IN4148
D201 OW02-04148-00R DIODE IN4148
D202 OW02-04148-00R DIODE IN4148
D301 OW02-04148-00R DIODE IN4148
D302 OW02-04148-00R DIODE IN4148
D303 OW02-04148-00R DIODE IN4148
D401 OW02-04148-00R DIODE IN4148
D402 OW02-04148-00R DIODE IN4148
D403 OW02-04148-00R DIODE IN4148
D404 OW02-04148-00R DIODE IN4148
D406 OW02-04148-00R DIODE IN4148
D408 OW02-04148-00R DIODE IN4148
IC101 OW03-02104-01 IC TA2104BN
IC102 OW03-09257-01 IC TC9257F
IC201 OW03-01330-00 IC UPC1330HA
IC202 OW03-07312-00 IC AN7312
IC301 OW03-09422-00 IC TC9422F
IC302 OW03-07812-00 IC
A
NJM7812A
IC401 OW03-04558-03 IC BA4558N
IC402 OW03-01876-00 IC LM1876TF
IC403 OW03-04558-03 IC BA4558N
J456 OW07-25000-60K CARBON RESISTOR 0 1/16 000JTP
L101 OW08-01014-02 IFT 1A1014N
L102 OW08-86436-70 AM ANT COIL OA10-864367
L103 OW09-45045-00 FM COIL D4.5MM 0.8MM
L104 OW09-25050-00W FM COIL D5MM 0.8MM
L105 OW09-70101-00 INDUCTOR 10MH
L106 OW09-70101-00 INDUCTOR 10MH
L201 OW09-40474-00W CHOKE COIL 47MH
L202 OW09-40474-00W CHOKE COIL 47MH
L203 OW08-07163-00 CHOKE COIL 7L1A63N LIK HANG
Q
101 OW01-00945-16 TRANSISTOR 2SC945P
Q
102 OW01-00945-16 TRANSISTOR 2SC945P
Q
103 OW01-00945-16 TRANSISTOR 2SC945P
Q
104 OW01-00945-16 TRANSISTOR 2SC945P
Q
105 OW01-00733-16 TRANSISTOR 2SA733P
Q
106 OW01-00945-16 TRANSISTOR 2SC945P
Q
107 OW01-09018-07 TRANSISTOR 9018G
Q
108 OW01-00945-16 TRANSISTOR 2SC945P
Q
109 OW01-00945-16 TRANSISTOR 2SC945P
Q
110 OW01-00945-16 TRANSISTOR 2SC945P
Q
111 OW01-00945-16 TRANSISTOR 2SC945P
Q
116 OW01-00945-16 TRANSISTOR 2SC945P
Q
201 OW01-08050-04S TRANSISTOR 8050D
Q
202 OW01-00945-16 TRANSISTOR 2SC945P
Q
203 OW01-00945-16 TRANSISTOR 2SC945P
Q
204 OW01-00945-16 TRANSISTOR 2SC945P
Item
Parts number Parts name Ar
ea
Remarks
A
