UX-M5R
3-7
Item
Parts number Parts name Ar
ea
Electrical parts list (Main board)
Remarks
Block No. 01
A
Q
205 OW01-00945-16 TRANSISTOR 2SC945P
Q
206 OW01-08050-04S TRANSISTOR 8050D
Q
207 OW01-00945-16 TRANSISTOR 2SC945P
Q
208 OW01-00945-16 TRANSISTOR 2SC945P
Q
209 OW01-00945-16 TRANSISTOR 2SC945P
Q
210 OW01-00945-16 TRANSISTOR 2SC945P
Q
211 OW01-00733-16 TRANSISTOR 2SA733P
Q
212 OW01-00945-16 TRANSISTOR 2SC945P
Q
213 OW01-00945-16 TRANSISTOR 2SC945P
Q
214 OW01-00945-16 TRANSISTOR 2SC945P
Q
215 OW01-00945-16 TRANSISTOR 2SC945P
Q
301 OW01-00945-16 TRANSISTOR 2SC945P
Q
302 OW01-00945-16 TRANSISTOR 2SC945P
Q
303 OW01-01383-18 TRANSISTOR 2SC1383R
Q
304 OW01-00945-16 TRANSISTOR 2SC945P
Q
305 OW01-01240-00 TRANSISTOR 2SB1240
Q
Q
401 OW01-08050-04S TRANSISTOR 8050D
Q
402 OW01-08050-04S TRANSISTOR 8050D
Q
403 OW01-08050-04S TRANSISTOR 8050D
Q
404 OW01-08050-04S TRANSISTOR 8050D
Q
405 OW01-00733-16 TRANSISTOR 2SA733P
Q
406 OW01-00945-16 TRANSISTOR 2SC945P
Q
407 OW01-00945-16 TRANSISTOR 2SC945P
Q
410 OW01-08050-04S TRANSISTOR 8050D
Q
411 OW01-08550-04B TRANSISTOR 8550D
R101 OW07-15274-50T CARBON RESISTOR 270K 1/8W 5%
R102 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R103 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R104 OW07-25473-60K CARBON RESISTOR 47K 1/16 473JTP
R105 OW07-15473-50T CARBON RESISTOR 47K 1/8W 5%
R106 OW07-25202-60K CARBON RESISTOR 2K 1/16 202JTP
R107 OW07-15220-50T CARBON RESISTOR 22 1/8W 5%
R108 OW07-15101-50T CARBON RESISTOR 100 1/8W 5%
R109 OW07-15203-50T CARBON RESISTOR 20K 1/8W 5%
R110 OW07-25332-60K CARBON RESISTOR 3.3K 1/16 332JTP
R111 OW07-25331-60K CARBON RESISTOR 330 1/8W
R113 OW07-25392-60K CARBON RESISTOR 3.9K 1/16 392JTP
R114 OW07-25183-60K CARBON RESISTOR 18K 1/16 183JTP
R115 OW07-25392-60K CARBON RESISTOR 3.9K 1/16 392JTP
R116 OW07-25183-60K CARBON RESISTOR 18K 1/16 183JTP
R117 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R118 OW07-25102-60K CARBON RESISTOR 1K 1/16 102JTP
R119 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R120 OW07-25223-60K CARBON RESISTOR 22K 1/16 223JTP
R121 OW07-15472-50T CARBON RESISTOR 4.7K 1/8W 5%
R122 OW07-15221-50T CARBON RESISTOR 220 1/8W 5%
R123 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R124 OW07-25102-60K CARBON RESISTOR 1K 1/16 102JTP
R125 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R126 OW07-25820-60K CARBON RESISTOR 82 1/16 820JTP
R127 OW07-25332-60K CARBON RESISTOR 3.3K 1/16 332JTP
R128 OW07-25563-60K CARBON RESISTOR 56K 1/16 563JTP
R129 OW07-25473-60K CARBON RESISTOR 47K 1/16 473JTP
R130 OW07-25102-60K CARBON RESISTOR 1K 1/16 102JTP
R131 OW07-25105-60K CARBON RESISTOR 1M 1/16 105JTP
R132 OW07-15101-50T CARBON RESISTOR 100 1/8W 5%
R133 OW07-15221-50T CARBON RESISTOR 220 1/8W 5%
R134 OW07-25152-60K CARBON RESISTOR 1.5K 1/16 152JTP
R135 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R136 OW07-15221-50T CARBON RESISTOR 220 1/8W 5%
R137 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R138 OW07-25102-60K CARBON RESISTOR 1K 1/16 102JTP
R139 OW07-25152-60K CARBON RESISTOR 1.5K 1/16 152JTP
R140 OW07-25561-60K CARBON RESISTOR 560 1/16 561JTP
R141 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R145 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R146 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R147 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R148 OW07-15102-50T CARBON RESISTOR 1K 1/8W 5%
R149 OW07-15102-50T CARBON RESISTOR 1K 1/8W 5%
R150 OW07-15102-50T CARBON RESISTOR 1K 1/8W 5%
R151 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R160 OW07-25183-60K CARBON RESISTOR 18K 1/16 183JTP
R161 OW07-25183-60K CARBON RESISTOR 18K 1/16 183JTP
R163 OW07-15472-50T CARBON RESISTOR 4.7K 1/8W 5%
R164 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R165 OW07-25102-60K CARBON RESISTOR 1K 1/16 102JTP
R201 OW07-25183-60K CARBON RESISTOR 18K 1/16 183JTP
R202 OW07-25102-60K CARBON RESISTOR 1K 1/16 102JTP
R203 OW07-25333-60K CARBON RESISTOR 33K 1/16 333JTP
R204 OW07-25180-60K CARBON RESISTOR 18 1/16 180JTP
R205 OW07-25333-60K CARBON RESISTOR 33K 1/16 333JTP
R206 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R207 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R208 OW07-25153-60K CARBON RESISTOR 15K 1/16 153JTP
R209 OW07-25684-60K CARBON RESISTOR 680K 1/16 684JTP
R210 OW07-25153-60K CARBON RESISTOR 15K 1/16 153JTP
R211 OW07-25333-60K CARBON RESISTOR 33K 1/16 333JTP
R212 OW07-25823-60K CARBON RESISTOR 82K 1/16 823JTP
R213 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R214 OW07-25473-60K CARBON RESISTOR 47K 1/16 473JTP
R215 OW07-25391-60K CARBON RESISTOR 390 1/16 391JTP
R216 OW07-25683-60K CARBON RESISTOR 68K 1/16 683JTP
R217 OW07-15010-50T CARBON RESISTOR 1 1/8W 5%
R218 OW07-25273-60K CARBON RESISTOR 27K 1/16 273JTP
R219 OW07-25273-60K CARBON RESISTOR 27K 1/16 273JTP
R220 OW07-15102-50T CARBON RESISTOR 1K 1/8W 5%
R221 OW07-25221-60K CARBON RESISTOR 220 1/16 221JTP
R222 OW07-25183-60K CARBON RESISTOR 18K 1/16 183JTP
R223 OW07-25333-60K CARBON RESISTOR 33K 1/16 333JTP
R224 OW07-25331-60K CARBON RESISTOR 330 1/8W
R225 OW07-15101-26T CARBON RESISTOR 100 1/4W 5%
R226 OW07-25102-60K CARBON RESISTOR 1K 1/16 102JTP
R227 OW07-25180-60K CARBON RESISTOR 18 1/16 180JTP
R228 OW07-15472-50T CARBON RESISTOR 4.7K 1/8W 5%
R229 OW07-15153-50T CARBON RESISTOR 15K 1/8W 5%
R231 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R232 OW07-25333-60K CARBON RESISTOR 33K 1/16 333JTP
R233 OW07-15221-26T CARBON RESISTOR 220 1/4W
R234 OW07-25153-60K CARBON RESISTOR 15K 1/16 153JTP
R235 OW07-25102-60K CARBON RESISTOR 1K 1/16 102JTP
R236 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R237 OW07-25823-60K CARBON RESISTOR 82K 1/16 823JTP
R238 OW07-25391-60K CARBON RESISTOR 390 1/16 391JTP
R239 OW07-25683-60K CARBON RESISTOR 68K 1/16 683JTP
R240 OW07-25047-60K CARBON RESISTOR 4.7 1/16 4R7JTP
R241 OW07-25273-60K CARBON RESISTOR 27K 1/16 273JTP
R242 OW07-25100-60K CARBON RESISTOR 10 1/16 100JTP
R243 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R244 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R245 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R246 OW07-25333-60K CARBON RESISTOR 33K 1/16 33JTP
R247 OW07-25103-60K CARBON RESISTOR 10K 1/16 10JTP
R248 OW07-25102-60K CARBON RESISTOR 1K 1/16 102JTP
R249 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R250 OW07-25223-60K CARBON RESISTOR 22K 1/16 223JTP
Item
Parts number Parts name Ar
ea
Remarks
A
