Item
Parts number Parts name Ar
ea
Electrical parts list (Main board)
Remarks
Block No. 01
A
R251 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R252 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R255 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R256 OW07-25473-60K CARBON RESISTOR 47K 1/16 473JTP
R257 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R258 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R301 OW07-15680-50T CARBON RESISTOR 68 1/8W 5%
R302 OW07-25471-60K CARBON RESISTOR 470 1/16 471JTP
R303 OW07-25394-60K CARBON RESISTOR 390K 1/16 394JTP
R304 OW07-25681-60K CARBON RESISTOR 680 1/16 681JTP
R307 OW07-25471-60K CARBON RESISTOR 470 1/16 471JTP
R308 OW07-25394-60K CARBON RESISTOR 390K 1/16 384JTP
R309 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R310 OW07-25681-60K CARBON RESISTOR 680 1/16 681JTP
R312 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R313 OW07-25471-60K CARBON RESISTOR 470 1/16 471JTP
R314 OW07-15100-26T CARBON RESISTOR 10 1/4W 5%
R315 OW07-15561-50T CARBON RESISTOR 560 1/8W 5%
R316 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R317 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R318 OW07-25473-60K CARBON RESISTOR 47K 1/16 473JTP
R319 OW07-25102-60K CARBON RESISTOR 1K 1/16 102JTP
R351 OW07-25473-60K CARBON RESISTOR 47K 1/16 473JTP
R352 OW07-25473-60K CARBON RESISTOR 47K 1/16 473JTP
R353 OW07-25822-60K CARBON RESISTOR 8.2K 1/16 822JTP
R354 OW07-25822-60K CARBON RESISTOR 8.2K 1/16 822JTP
R401 OW07-15682-26T CARBON RESISTOR 6.8K 1/4W 5%
R402 OW07-25153-60K CARBON RESISTOR 15K 1/16 153JTP
R403 OW07-25223-60K CARBON RESISTOR 22K 1/16 223JTP
R404 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R405 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R406 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R407 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R408 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R409 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R410 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R411 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R412 OW07-25223-60K CARBON RESISTOR 22K 1/16 223JTP
R413 OW07-25223-60K CARBON RESISTOR 22K 1/16 223JTP
R414 OW07-25563-60K CARBON RESISTOR 56K 1/16 563JTP
R415 OW07-25563-60K CARBON RESISTOR 56K 1/16 563JTP
R416 OW07-15102-26T CARBON RESISTOR 1K 1/4W 5%
R417 OW07-15102-26T CARBON RESISTOR 1K 1/4W 5%
R418 OW07-15563-50T CARBON RESISTOR 56K 1/8W 5%
R419 OW07-15563-50T CARBON RESISTOR 56K 1/8W 5%
R420 OW07-15223-00 CARBON RESISTOR 22K 1/4W 5%
R421 OW07-15223-00 CARBON RESISTOR 22K 1/4W 5%
R422 OW07-15102-26T CARBON RESISTOR 1K 1/4W 5%
R423 OW07-15102-26T CARBON RESISTOR 1K 1/4W 5%
R424 OW07-05047-10 CARBON RESISTOR 4.7 1/2W
R425 OW07-05047-10 CARBON RESISTOR 4.7 1/2W
R426 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R428 OW07-15682-26T CARBON RESISTOR 6.8K 1/4W 5%
R429 OW07-25223-60K CARBON RESISTOR 22K 1/16 223JTP
R430 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R431 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R432 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R433 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R434 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R435 OW07-25472-60K CARBON RESISTOR 4.7K 1/16 472JTP
R436 OW07-25473-60K CARBON RESISTOR 47K 1/16 473JTP
R437 OW07-25473-60K CARBON RESISTOR 47K 1/16 473JTP
R438 OW07-25223-60K CARBON RESISTOR 22K 1/16 223JTP
R439 OW07-25223-60K CARBON RESISTOR 22K 1/16 223JTP
R440 OW07-25152-60K CARBON RESISTOR 1.5K 1/16 152JTP
R441 OW07-25152-60K CARBON RESISTOR 1.5K 1/16 152JTP
R442 OW07-25221-60K CARBON RESISTOR 220 1/16 221JTP
R443 OW07-25221-60K CARBON RESISTOR 220 1/16 221JTP
R446 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R447 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R448 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R449 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R450 OW07-15104-50T CARBON RESISTOR 100K 1/8W 5%
R451 OW07-15103-50T CARBON RESISTOR 10K 1/8W 5%
R458 OW07-15181-01T CARBON RESISTOR 180 1/4W 5%
R459 OW07-25122-60K CARBON RESISTOR 1.2K 1/16 122JTP
R463 OW07-15181-01T CARBON RESISTOR 180 1/4W 5%
R464 OW07-25122-60K CARBON RESISTOR 1.2K 1/16 122JTP
R482 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R483 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R484 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
R485 OW07-25104-60K CARBON RESISTOR 100K 1/16 104JTP
R486 OW07-25103-60K CARBON RESISTOR 10K 1/16 103JTP
TC101 OW05-08100-03 TRIM CAPACITOR 10PF 3PIN
TC102 OW05-08100-03 TRIM CAPACITOR 10PF 3PIN
T101 OW08-00332-24C IFT YEL 10MM 810017 COILS
X101 OW04-07200-05 CRYSTAL 7.2MHZ HC-49U 30PPM
Z101 OW02-50100-00 ZENER DIODE 10V 0.5W
Z301 OW02-50091-00 ZENER DIODE 9.1V 0.5W
Z401 OW02-50180-00 ZENER DIODE
A
18V 0.5W
Z402 OW02-50180-00 ZENER DIODE
A
18V 0.5W
Item
Parts number Parts name Ar
ea
Remarks
A
