JVC UX-P30 Series

26
Specifications
Amplifier
Output Power:
44 W (22 W + 22 W) at 4 Ω (MAX.)
40 W (20 W + 20 W) at 4 Ω (10 % THD)
Audio input sensitivity/Impedance (at 1 kHz)
AUX: 400 mV/48 kΩ
Speakers/Impedance: 4 Ω – 16 Ω
Tuner
FM tuning range: 87.50 MHz – 108.00 MHz
AM (MW) tuning range: 522 kHz – 1 629 kHz
CD player
Dynamic range: 85 dB
Signal-to-noise ratio: 90 dB
Wow and flutter: Immeasurable
Cassette deck
Frequency response
Normal (type I): 50 Hz – 14 000 Hz
Wow and flutter: 0.15 % (WRMS)
Speaker
Speaker units
Woofer: 8 cm cone x 1
Tweeter: 2 cm cone x 1
Impedance: 4 Ω
Dimensions (approx.):
160 mm x 256 mm x 197 mm (W/H/D)
Mass (approx.): 2.1 kg each
Supplied Accessories
See page 6.
General
Power requirement: AC 230 V , 50 Hz
Power consumption: 50 W (at operation)
3.8 W (on standby)
Dimensions (approx.):
505 mm x 256 mm x 294 mm (W/H/D)
Mass (approx.): 8.5 kg
Design and specifications are subject to change without notice.
