1-2 (No.MB262)
SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier section Output Power 40 W (20 W + 20 W) at 4 Ω (10% THD)
Speakers/Impedance 4 Ω - 16 Ω
Audio Input AUX 400 mV/50 kΩ
Tuner section FM tuning range 87.50 MHz - 108.00 MHz
AM (MW) tuning range 531 kHz - 1 710 kHz (at 9 kHz intervals)
530 kHz - 1 710 kHz (at 10 kHz intervals)
CD player section Dynamic range 88 dB
Signal-to-noise ratio 93 dB
Wow and flutter Immeasurable
Cassette deck section Frequency response Normal (type I):50 Hz - 14 000 Hz
Wow and flutter 0.15% (WRMS)
Speakers Speaker units 10 cm cone × 1
Impedance 4 Ω
Dimensions (approx.) 145 mm × 230 mm × 191 mm (W/H/D)
Mass (approx.) 1.8 kg each
General Power requirement AC 110 V/AC 127 V/AC 220 V/AC 230 V - AC 240 V
(adjustable with the voltage selector), 50 Hz/60 Hz
Power consumption 50 W (at operation)
4.4 W (on standby)
Dimensions (approx.) 170 mm × 230 mm × 311 mm (W/H/D)
Mass (approx.) 4.5 kg
