Speaker assembly and parts list
Speaker (US,UP,UT,UW)
Block No. [M][2][M][M]
Symbol No. Part No. Part Name Description Local
1 UP4-BK-00-01 SARAN BOARD (x2)
2 UP4-MK-00-01 MARK (x2)
3 UP4-WO-00-01 CONE SPEAKER (x2)
4 UP4-ML-00-01 TAPPING SCREW (x8)
5 UP4-JD-00-01 RUBBER MAT (x8)
6 UP4-HT-02-01 RATING LABEL (x2)
Block No.
M
M
M
2
Block No.
M
M
M
2
(US,UP,UT,UW)
1
2
4
3
5
6
