JVC UX-P400

3-8
CD mechanism
Block No. [M][B][M][M]
 Symbol No. Part No. Part Name Description Local
1 LE10283-014A LOADER SUB ASSY
2 QAR0197-001 MOTOR
3 LV42087-002A MOTOR PULLEY
4 QYSPSPU1730Z SCREW M1.7 x 3mm(x2)
5 LE40897-001A BELT
6 LV34586-001A CD CLAMPER
7 LV42930-003A P.C.MAGNET
8 LE40899-001A YOKE
9 LV41741-001A SPECIAL SCREW
10 OPTIMA-725B2 CD PICK UP
11 LV34564-001A RACK ARM
12 QYSPSPT1720M SCREW M1.7 x 2mm(x2)
13 LV31744-001A P.S.SPRING
14 QYSPSGT1425M TAP SCREW 1.4mm x 2.5mm
15 LV10855-001A TM CHASSIS
16 LV43468-001A T.T ASSY
17 QAR0302-001 SPINDLE MOTOR
18 VKZ4743-001 SPECIAL SCREW (x2)
19 LV40157-001A SCREW SHAFT
20 LV43651-001A SS GEAR
21 LV43650-001A F MOTOR GEAR
22 QAR0303-001 FEED MOTOR
23 QYSPSPT2030M SCREW M2 x 3mm
24 LV34565-002A F MIDDLE GEAR
25 LV34563-001A SHAFT HOLDER
26 QYSPSFT1740Z TAP SCREW M1.7 x 4mm
27 QUQ105-1506BB FFC
28 LV43805-001A FFC
29 LE40900-003A INSULATOR (x2)
30 LE40900-004A INSULATOR (x2)
31 LE40901-001A SPECIAL SCREW (x4)
32 QYSBSF2006Z TAP SCREW M2 x 6mm(x2)
33 VYSH101-034 SPACER
34 LV30225-096A SPACER
35 LV30225-073A SPACER
36 LV43828-001A SPACER
