JVC UX-P400 Service Manual

3-11
Electrical parts list
Main board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
IC200 LC75342M-X IC
IC202 JCV8011-X IC
IC240 KIA7810API IC
IC241 PQ033RD01SZ IC
IC701 MN101C49GFL2 MASK ROM
IC703 BD4740G-W IC
IC705 KIA78S06P-T IC
Q2200 2SC3576-JVC-T TRANSISTOR
Q2220 2SD601A/R/-X TRANSISTOR
Q2221 UN2111-X TRANSISTOR
Q2410 KTC2026/Y/ TRANSISTOR
Q7001 UN2214-X TRANSISTOR
Q7002 UN2215-X TRANSISTOR
Q7146 UN2215-X TRANSISTOR
Q7154 2SD601A/R/-X TRANSISTOR
Q7158 2SD601A/R/-X TRANSISTOR
Q7161 UN2211-X TRANSISTOR
Q7162 UN2211-X TRANSISTOR
Q7246 UN2211-X TRANSISTOR
Q7300 2SB709A/RS/-X TRANSISTOR
Q7301 UN2215-X TRANSISTOR
Q7302 KRC110M-T TRANSISTOR
Q7320 2SB709A/RS/-X TRANSISTOR
Q7321 UN2215-X TRANSISTOR
Q7340 2SD601A/R/-X TRANSISTOR
Q7360 2SB709A/RS/-X TRANSISTOR
Q7361 UN2215-X TRANSISTOR
D2400 MTZJ11C-T2 Z DIODE
D2401 1SS133-T2 DIODE
D2402 1N4003S-T5 SI DIODE
D2403 1N4003S-T5 SI DIODE
D2410 MTZJ3.9B-T2 Z DIODE
D2411 1SS133-T2 DIODE
D2413 MTZJ6.8C-T2 Z DIODE
D7001 1SS133-T2 DIODE
D7002 1SS133-T2 DIODE
D7003 MTZJ5.1A-T2 Z DIODE
D7062 1SS133-T2 DIODE
D7161 1SS133-T2 DIODE
D7300 1SS133-T2 DIODE
D7301 1SS133-T2 DIODE
D7320 1SS133-T2 DIODE
D7340 1N4003S-T5 SI DIODE
D7341 1SS133-T2 DIODE
D7350 MTZJ6.2C-T2 Z DIODE
D7351 1SS133-T2 DIODE
D7352 1SS133-T2 DIODE
D7353 1SS133-T2 DIODE
D7354 1SS133-T2 DIODE
C2000 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C2001 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2002 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2003 QTE1H28-106Z E CAPACITOR 10uF 50V
C2004 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2006 QTE1E28-106Z E CAPACITOR 10uF 25V
C2007 QTE1E28-106Z E CAPACITOR 10uF 25V
C2008 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2009 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2010 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2016 QTE1H28-105Z E CAPACITOR 1uF 50V
C2021 QTE1H28-106Z E CAPACITOR 10uF 50V
C2023 QTE1H28-106Z E CAPACITOR 10uF 50V
C2032 QFLC1HJ-222Z M CAPACITOR 2200pF 50V J
C2080 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C2081 QDXB1CM-332Y C CAPACITOR 3300pF 16V M
C2100 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C2101 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2102 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2103 QTE1H28-106Z E CAPACITOR 10uF 50V
C2104 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2106 QTE1E28-106Z E CAPACITOR 10uF 25V
C2107 QTE1E28-106Z E CAPACITOR 10uF 25V
C2108 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2109 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2110 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2116 QTE1H28-105Z E CAPACITOR 1uF 50V
C2121 QTE1H28-106Z E CAPACITOR 10uF 50V
C2122 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2123 QTE1H28-106Z E CAPACITOR 10uF 50V
C2132 QFLC1HJ-222Z M CAPACITOR 2200pF 50V J
C2180 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C2181 QDXB1CM-332Y C CAPACITOR 3300pF 16V M
C2200 QTE1C06-107Z E CAPACITOR 100uF 16V
C2201 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2202 QTE1C06-107Z E CAPACITOR 100uF 16V
C2203 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C2204 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2220 QTE1C06-476Z E CAPACITOR 47uF 16V
C2221 QETN1CM-476Z E CAPACITOR 47uF 16V M
C2222 QFLC1HJ-273Z M CAPACITOR 0.027uF 50V J
C2223 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2224 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2225 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2226 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2227 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2228 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2229 QETN1HM-224Z E CAPACITOR 0.22uF 50V M
C2230 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2231 QETN1HM-684Z E CAPACITOR 0.68uF 50V M
C2232 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2233 QETN1CM-476Z E CAPACITOR 47uF 16V M
C2274 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2280 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C2282 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C2400 QETN1EM-477Z E CAPACITOR 470uF 25V M
C2401 QETN1CM-227Z E CAPACITOR 220uF 16V M
C2410 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2411 QETN1CM-227Z E CAPACITOR 220uF 16V M
C2412 QETN1EM-107Z E CAPACITOR 100uF 25V M
C2413 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2414 QETN1EM-107Z E CAPACITOR 100uF 25V M
C7001 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7002 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7004 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C7005 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C7006 NCB31HK-102X C CAPACITOR 1000pF 50V K
C7007 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7008 QETN1CM-227Z E CAPACITOR 220uF 16V M
C7009 QETN0JM-228Z E CAPACITOR 2200uF 6.3V M
C7103 NCB31HK-102X C CAPACITOR 1000pF 50V K
C7112 NCS31HJ-330X C CAPACITOR 33pF 50V J
C7113 NCS31HJ-330X C CAPACITOR 33pF 50V J
C7180 QCBB1HK-151Y C CAPACITOR 150pF 50V K
C7181 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C7182 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C7320 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7340 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7350 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C7351 QETN1CM-476Z E CAPACITOR 47uF 16V M
C7352 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7353 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7367 QETN1CM-476Z E CAPACITOR 47uF 16V M
C7371 QCBB1HK-561Y C CAPACITOR 560pF 50V K
C7372 QCBB1HK-561Y C CAPACITOR 560pF 50V K
R2000 QRE141J-303Y C RESISTOR 30k Ω 1/4W J
R2001 QRE141J-303Y C RESISTOR 30k
Ω 1/4W J
R2002 QRE141J-912Y C RESISTOR 9.1k
Ω 1/4W J
R2003 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R2004 NRSA63J-622X MG RESISTOR 6.2k
Ω 1/16W J
R2006 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R2007 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R2008 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
