UX-V30
3-11
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
D9504 MTZJ9.1C-T2 Z DIODE I/M
D9600 MTZJ27B-T2 Z. DIODE I/M
EP901 QNZ0136-001Z EARTH PLATE
EP902 QNZ0136-001Z EARTH PLATE
FW900 QUM154-11Z4Z4 FLAT WIRE
IC300 LA4628 IC
A
IC301 BA15218N IC
IC302 LC75342 IC
IC303 LB1641 IC
J 300 QNB0090-001 SPK TERMINAL
J 301 QNN0018-001 PIN JACK
J 302 QNS0030-001 JACK
J 303 GP1FA550TZ OPT TRANSMITTER
J 901 QNC0006-001 AC SOCKET
A
K3800 QUY150-050Y BUS WIRE
K9100 QUY150-050Y FERRITE BEADS
K9401 QUY150-050Y BUS WIRE
L 901 QQR1145-001 LINE FILTER
A
EMC FILTER
L9401 QUY150-050Y INDUCTOR
PP900 QZW0038-001 WIRE CLAMP
Q
1150 2SC3576-JVC-T TRANSISTOR
Q
1400 KTC3199/GL/-T TRANSISTOR
Q
1700 2SC3576-JVC-T TRANSISTOR I/M
Q
1800 KTC3199/GL/-T TRANSISTOR
Q
2150 2SC3576-JVC-T TRANSISTOR
Q
2400 KTC3199/GL/-T TRANSISTOR
Q
2700 2SC3576-JVC-T TRANSISTOR I/M
Q
2800 KTC3199/GL/-T TRANSISTOR
Q
3150 KRA101M-T TR I/M
Q
3700 KTC3199/GL/-T TRANSISTOR
Q
3800 KRA101M-T TR I/M
Q
9001 KTA1046/Y/ TRANSISTOR *
A
Q
9002 KTC3199/GL/-T TRANSISTOR
Q
9003 KTA1267/YG/-T TRANSISTOR
Q
9004 KRC114M-T TR I.M *
Q
9005 DTA144TS-T D.TRANSISTOR
Q
9006 KTC3199/GL/-T TRANSISTOR
Q
9007 KTC3199/GL/-T TRANSISTOR
Q
9201 KTB772/Y/ TRANSISTOR
Q
9202 KTC3199/GL/-T TRANSISTOR
Q
9301 KTA1267/YG/-T TRANSISTOR
Q
9302 KTC3199/GL/-T TRANSISTOR
Q
9402 KTC3199/GL/-T TRANSISTOR
Q
9403 DTC114YS-T TR I.M
Q
9501 2SD2144S/VW/-T TRANSISTOR
Q
9600 2SC2001/K/-T TRANSISTOR
R 901 QRZ9044-335 COMP.RESISTOR 3.3M 1/0W
R 906 QRZ9006-4R7X F RESISTOR 4.7 1/0W
R1100 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R1101 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R1102 QRE141J-471Y C RESISTOR 470 5% 1/4W
R1150 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1151 QRE141J-562Y C RESISTOR 4.7K 5% 1/4W
R1200 QRE141J-151Y C RESISTOR 150 5% 1/4W
R1300 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R1301 QRE141J-202Y C RESISTOR 1.8K 5% 1/4W
R1302 QRE141J-222Y C RESISTOR 2.0K 5% 1/4W
R1303 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1304 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1305 QRE141J-682Y C RESISTOR 3.0K 5% 1/4W
R1306 QRE141J-512Y C RESISTOR 5.1K 5% 1/4W
R1307 QRE141J-182Y C RESISTOR 3.6K 5% 1/4W
R1400 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1401 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1402 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1501 QRE141J-512Y C RESISTOR 5.1K 5% 1/4W
R1503 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R1504 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R1505 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R1600 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R1601 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R1700 QRE141J-221Y C RESISTOR 220 5% 1/4W
R1701 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R1702 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1800 QRE141J-912Y C RESISTOR 9.1K 5% 1/4W
R1801 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R1802 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R1803 QRE141J-622Y C RESISTOR 6.2K 5% 1/4W
R2100 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R2101 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R2102 QRE141J-471Y C RESISTOR 470 5% 1/4W
R2150 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R2151 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R2200 QRE141J-151Y C RESISTOR 150 5% 1/4W
R2300 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R2301 QRE141J-202Y C RESISTOR 1.8K 5% 1/4W
R2302 QRE141J-222Y C RESISTOR 2.0K 5% 1/4W
R2303 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R2304 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R2305 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R2306 QRE141J-512Y C RESISTOR 4.7K 5% 1/4W
R2307 QRE141J-182Y C RESISTOR 3.6K 5% 1/4W
R2400 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R2401 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R2402 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R2501 QRE141J-512Y C RESISTOR 5.1K 5% 1/4W
R2503 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R2504 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R2505 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R2508 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R2600 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R2601 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R2700 QRE141J-221Y C RESISTOR 220 5% 1/4W
R2701 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R2702 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R2800 QRE141J-912Y C RESISTOR 9.1K 5% 1/4W
R2801 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R2802 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R2803 QRE141J-622Y C RESISTOR 6.2K 5% 1/4W
R3100 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R3300 QRE141J-101Y C RESISTOR 100 5% 1/4W
R3301 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R3400 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R3401 QRE141J-682Y C RESISTOR 4.7K 5% 1/4W
R3402 QRE141J-124Y C RESISTOR 120K 5% 1/4W
R3403 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R3404 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R3405 QRE141J-513Y C RESISTOR 51K 5% 1/4W
R3500 QRE141J-101Y C RESISTOR 100 5% 1/4W
R3501 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R3502 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R3503 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R3700 QUY150-050Y C RESISTOR 10K 5% 1/4W
R9001 QRE141J-1R2Y C RESISTOR 1.0 5% 1/4W
R9002 QRE141J-1R2Y C RESISTOR 1.2 5% 1/4W
R9003 QRE141J-1R2Y C RESISTOR 1.0 5% 1/4W
(Main board)
Item
Parts number Parts name Area
Remarks
A
