UX-V30
3-12
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
R9004 QRE141J-471Y C RESISTOR 470 5% 1/4W
R9005 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R9006 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R9007 QRE141J-681Y C RESISTOR 680 5% 1/4W
R9008 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R9009 QRZ9005-680X F.RES I/M
A
68 1/0W
R9010 QRZ9005-680X F.RES I/M
A
68 1/0W
R9011 QRZ9005-680X F.RES I/M
A
68 1/0W
R9012 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R9013 QRE141J-471Y C RESISTOR 470 5% 1/4W
R9014 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R9015 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R9016 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R9017 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R9018 QRE141J-391Y C RESISTOR 390 5% 1/4W
R9019 QRZ9005-680X F.RES I/M
A
68 1/0W
R9102 QRZ9006-5R6X F.RES I/M 5.6 1/0W
R9201 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R9202 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R9203 QRE141J-820Y C RESISTOR 82 5% 1/4W
R9301 QUY150-050Y C RESISTOR 4.7K 5% 1/4W
R9302 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R9303 QRE141J-101Y C RESISTOR 1.0K 5% 1/4W
R9304 QRE141J-390Y C RESISTOR 39 5% 1/4W
R9403 QRE141J-100Y C RESISTOR 10 5% 1/4W
R9404 QRE141J-6R8Y C RESISTOR 6.8 5% 1/4W
R9405 QRE141J-391Y C RESISTOR 390 5% 1/4W
R9501 QRE141J-471Y C RESISTOR 470 5% 1/4W
R9502 QRE141J-620Y C RESISTOR 62 5% 1/4W
R9503 QRE141J-620Y C RESISTOR 62 5% 1/4W
R9504 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R9600 QRZ9005-100X F.RES I/M 10 1/0W
R9601 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R9602 QRE141J-224Y C RESISTOR 220K 5% 1/4W
S 901 QSW0740-001 VOLTAGE SWITCH
A
W 300 QJK015-031102 WIRE SECONDARY
W 301 QJK017-051400 WIRE
W 901 WJK0070-001A WIRE
A
Z 901 QNG0020-001Z FUSE CLIP
A
Z 902 QNG0020-001Z FUSE CLIP
A
Z 903 QNG0020-001Z FUSE CLIP
A
Z 904 QNG0020-001Z FUSE CLIP
A
(Main board)
