JVC UX-V30 User Manual

UX-V30
3-13
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
BL801 QLL0050-002 LAMP BLUE LAMP
BL802 QLL0050-002 LAMP BLUE LAMP
CN711 QGB1214K1-14S CONNECTOR TO MAIN PWB
CN712 QGB1214K1-20S CONNECTOR TO MAIN PWB
CN721 QGA2001C1-03 3P PLUG ASSY TO CD DOOR SW P
CN722 QGA2001C1-04 4P PLUG ASSY TO ILLUMI PWB
(
R
CN732 QGF1205C1-09 CONNECTOR
CN766 QGF1205C1-13 CONNECTOR TO CD PWB
CN781 QGB1216J1-08S CONNECTOR TO FRONT SW PWB
CN881 QGB1216K1-08S CONNECTOR
C7001 NCS21HJ-180X C CAPACITOR CLOCK
C7002 NCS21HJ-180X C CAPACITOR CLOCK
C7004 NCS21HJ-360X C CAPACITOR MAIN CLOCK SHIF
C7005 NCS21HJ-390X C CAPACITOR MAIN CLOCK SHIF
C7006 NCS21HJ-200X C CAPACITOR MAIN CLOCK
C7007 NCS21HJ-220X C CAPACITOR MAIN CLOCK
C7008 NCB21HK-102X C CAPACITOR
C7009 NCB21HK-102X C CAPACITOR
C7011 EEKC1AM-107ZJC E.CAPACITOR 100MF 20% 10V
C7012 NCB21HK-103X C CAPACITOR
C7013 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C7014 EETC1CM-106ZJC E CAPACITOR 10MF 20% 16V
C7031 EETB0JM-228JC E CAPACITOR BACKUP CAPACITO
C7051 QETN1HM-684Z E CAPACITOR .68MF 20% 50V
C7052 EETC1HM-225ZJC E CAPACITOR 2.2MF 20% 50V
C7081 NCB21CK-104X C.CAPA. C.M AM LCD NOISE
C7601 NCS21HJ-151X C CAPACITOR
C7602 NCS21HJ-151X C CAPACITOR
C7623 NCS21HJ-101X C CAPACITOR
C7624 NCS21HJ-101X C CAPACITOR
C7633 NCB21HK-102X C CAPACITOR
C7641 NCS21HJ-151X C CAPACITOR
C7701 NCS21HJ-151X C CAPACITOR
C7702 NCS21HJ-151X C CAPACITOR
C7704 NCS21HJ-101X C CAPACITOR
C7801 NCB21HK-103X CER.CAPACITOR-M
C7802 NCB21HK-103X C CAPACITOR MICOM NOISE
C7803 NCB21HK-102X C CAPACITOR
C7804 NCB21HK-103X C CAPACITOR
C7809 NCB21HK-102X C CAPACITOR
C7810 NCB21HK-103X C CAPACITOR
C8001 NCB21HK-102X C CAPACITOR
C8002 QEK41CM-476 E.CAPACITOR 47MF 20% 16V
C8003 NCB21HK-103X C CAPACITOR
C8004 NCB21HK-103X C CAPACITOR
C8601 QEKC1AM-107Z E.CAPACITOR 100MF 20% 10V
DI701 QLD0119-001 LCD 44 PIN LCD
D7001 1SS133-T2 SI DIODE US5V
D7011 MTZJ8.2B-T2 DIODE SHORT HOGO
D7012 1SS133-T2 SI DIODE SHORT HOGO
D7013 1SS133-T2 SI DIODE
D7014 MTZJ6.8B-T2 NER DIODE
D7031 1SS133-T2 SI DIODE BACK UP
D7032 1SS133-T2 SI DIODE CLOCK
D7051 1SS133-T2 SI DIODE RESET
D7061 MTZJ5.1C-T2 ZENER DIODE BACK UP CONT.
D7091 1SS133-T2 SI DIODE US5V
D7092 1SS133-T2 SI DIODE 5V-REMCON&STBLE
D8001 1SS133-T2 SI DIODE
D8002 SLR-342VC-T LED
D8003 SLR-342MC-T LED
D8201 SELU1E56BM LED
D8202 SELU1E56BM LED
D8205 MTZJ10C-T2 Z.DIODE I.M
D8206 MTZJ10C-T2 Z.DIODE I.M
D8601 1SS133-T2 SI DIODE
D8602 1SS133-T2 SI DIODE
D8603 1SS133-T2 SI DIODE
IC701 UPD78064GF-172 IC SYSTEM MICOM
IC703 KIA78S06P-T IC US6V REG
IC801 GP1U261X IR DETECT UNIT
K7001 NQR0006-001X FERRITE BEAD ICVSS
K7002 NQR0006-001X FERRITE BEAD AVSS
K7004 NQR0006-001X FERRITE BEAD SW GND
K7005 NQR0006-001X FERRITE BEAD VSS
L7002 QQL231K-100Y INDUCTOR US5V
L7003 QQL231K-470Y INDUCTOR AVDD & VDD
L7005 QQL231K-4R7Y INDUCTOR AVREF
PP701 QZW0038-001 POST PIN
Q
7001 2SC2668/O/-T TRANSISTOR CLOCK SHIFT
Q
7002 2SC2668/O/-T TRANSISTOR CLOCK SHIFT
Q
7031 2SA1037AK/RS/-X TRANSISTOR SW5V
Q
7051 DTC114TKA-X TRANSISTOR RESET SW
Q
7061 2SC2412K/R/-X TRANSISTOR BACKUP CONT
Q
7091 2SC2412K/R/-X TRANSISTOR POUT DRIVER
Q
7601 DTC144TKA-X TRANSISTOR
Q
7602 DTC144TKA-X TRANSISTOR
Q
7603 2SC2412K/R/-X TRANSISTOR
Q
7604 2SA933S/RS/-T TRANSISTOR
Q
8001 DTC114TKA-X TRANSISTOR
Q
8601 DTC144EKA-X TRANSISTOR
Q
8602 2SA1037AK/RS/-X TRANSISTOR
R7005 NRSA02J-822X MG RESISTOR
R7006 NRSA02J-822X MG RESISTOR
R7031 NRSA02J-331X MG RESISTOR
R7032 NRSA02J-103X MG RESISTOR
R7033 NRSA02J-102X MG RESISTOR
R7051 NRSA02J-103X MG RESISTOR
R7052 NRSA02J-103X MG RESISTOR
R7061 NRSA02J-333X MG RESISTOR
R7062 NRSA02J-473X MG RESISTOR
R7063 NRSA02J-104X MG RESISTOR
R7081 NRSA02J-104X MG RESISTOR
R7082 NRSA02J-104X MG RESISTOR
R7083 NRSA02J-104X MG RESISTOR
R7084 NRSA02J-273X MG RESISTOR
R7429 NRSA02J-913X MG RESISTOR
R7430 NRSA02J-102X MG RESISTOR
R7528 NRSA02J-223X MG RESISTOR
R7529 NRSA02J-473X MG RESISTOR
R7530 NRSA02J-103X MG RESISTOR
R7602 NRSA02J-102X MG RESISTOR
R7614 NRSA02J-103X MG RESISTOR
R7619 NRSA02J-122X MG RESISTOR
R7620 NRSA02J-102X MG RESISTOR
R7621 NRSA02J-122X MG RESISTOR
R7622 NRSA02J-102X MG RESISTOR
R7625 NRSA02J-823X MG RESISTOR
R7628 NRSA02J-823X MG RESISTOR
R7629 NRSA02J-103X MG RESISTOR
R7630 NRSA02J-563X MG RESISTOR
R7631 NRSA02J-104X MG RESISTOR
R7632 NRSA02J-103X MG RESISTOR
R7633 NRSA02J-103X MG RESISTOR
R7634 NRSA02J-103X MG RESISTOR
R7635 NRSA02J-104X MG RESISTOR
(Micon board & regurator)
Item
Parts number Parts name Area
Remarks
A
