UX-V30
3-14
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
R7639 NRSA02J-222X MG RESISTOR
R7641 NRSA02J-102X MG RESISTOR
R7642 NRSA02J-102X MG RESISTOR
R7647 NRSA02J-104X MG RESISTOR
R7648 NRSA02J-394X MG RESISTOR
R7649 NRSA02J-823X MG RESISTOR
R7651 NRSA02J-473X MG RESISTOR
R7652 NRSA02J-473X MG RESISTOR
R7653 NRSA02J-394X MG RESISTOR
R7654 NRSA02J-182X MG RESISTOR
R7655 NRSA02J-102X MG RESISTOR
R7701 NRSA02J-102X MG RESISTOR
R7702 NRSA02J-102X MG RESISTOR
R7703 NRSA02J-102X MG RESISTOR
R7704 NRSA02J-103X MG RESISTOR
R7705 NRSA02J-102X MG RESISTOR
R7711 NRSA02J-222X MG RESISTOR
R7712 NRSA02J-102X MG RESISTOR
R7713 NRSA02J-222X MG RESISTOR
R7715 NRSA02J-222X MG RESISTOR
R7716 NRSA02J-222X MG RESISTOR
R7717 NRSA02J-472X MG RESISTOR
R7718 NRSA02J-102X MG RESISTOR
R7719 NRSA02J-102X MG RESISTOR
R7720 NRSA02J-102X MG RESISTOR
R7721 NRSA02J-102X MG RESISTOR
R7722 NRSA02J-102X MG RESISTOR
R7723 NRSA02J-222X MG RESISTOR
R7724 NRSA02J-222X MG RESISTOR
R7725 NRSA02J-222X MG RESISTOR
R7726 NRSA02J-222X MG RESISTOR
R7728 NRSA02J-222X MG RESISTOR
R7729 NRSA02J-222X MG RESISTOR
R7730 NRSA02J-222X MG RESISTOR
R7731 NRSA02J-222X MG RESISTOR
R7732 NRSA02J-222X MG RESISTOR
R7733 NRSA02J-222X MG RESISTOR
R7734 NRSA02J-222X MG RESISTOR
R7735 NRSA02J-222X MG RESISTOR
R7738 NRSA02J-222X MG RESISTOR
R7739 NRSA02J-222X MG RESISTOR
R7741 NRSA02J-222X MG RESISTOR
R7742 NRSA02J-222X MG RESISTOR
R7743 NRSA02J-222X MG RESISTOR
R7744 NRSA02J-222X MG RESISTOR
R7745 NRSA02J-222X MG RESISTOR
R7746 NRSA02J-302X MG RESISTOR
R7747 NRSA02J-222X MG RESISTOR
R7748 NRSA02J-153X MG RESISTOR
R7749 NRSA02J-123X MG RESISTOR
R7750 NRSA02J-222X MG RESISTOR
R7799 NRSA02J-102X MG RESISTOR
R8001 NRSA02J-102X MG RESISTOR
R8002 NRSA02J-102X MG RESISTOR
R8003 NRSA02J-122X MG RESISTOR
R8005 NRSA02J-473X M.G.RESISTOR
R8011 NRSA02J-102X MG RESISTOR
R8012 NRSA02J-102X MG RESISTOR
R8013 NRSA02J-122X MG RESISTOR
R8014 NRSA02J-152X MG RESISTOR
R8015 NRSA02J-222X MG RESISTOR
R8016 NRSA02J-272X MG RESISTOR
R8017 NRSA02J-392X MG RESISTOR
R8018 NRSA02J-562X MG RESISTOR
R8019 NRSA02J-103X MG RESISTOR
R8020 NRSA02J-183X MG RESISTOR
R8021 NRSA02J-433X MG RESISTOR
R8031 NRSA02J-681X MG RESISTOR
R8032 NRSA02J-681X MG RESISTOR
R8201 NRSA02J-471X MG RESISTOR
R8202 NRSA02J-471X MG RESISTOR
R8203 NRSA02J-471X MG RESISTOR
R8204 NRSA02J-471X MG RESISTOR
R8601 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R8602 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R8602 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R8611 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R8612 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R8621 NRSA02J-104X MG RESISTOR
R8622 NRSA02J-473X MG RESISTOR
R8623 NRSA02J-473X MG RESISTOR
R8631 QRJ146J-3R9X UNF C.RES I/M 3.9 5% 1/4W
S8001 QSW0674-001Z TACT SW REVERSE MODE
S8002 QSW0674-001Z TACT SW REC
S8003 QSW0674-001Z TACT SW AUX
S8004 QSW0674-001Z TACT SW POWER
S8011 QSW0674-001Z TACT SW OPEN/CLOSE
S8012 QSW0674-001Z TACT SW VOLUME -
S8013 QSW0674-001Z TACT SW VOLUME +
S8014 QSW0674-001Z TACT SW AHB PRO
S8015 QSW0674-001Z TACT SW TIMER
S8016 QSW0674-001Z TACT SW CLOCK
S8017 QSW0674-001Z TACT SW CD
S8018 QSW0674-001Z TACT SW TUNER
S8019 QSW0674-001Z TACT SW TAPE
S8020 QSW0674-001Z TACT SW DOWN
S8021 QSW0674-001Z TACT SW STOP
S8022 QSW0674-001Z TACT SW UP
S8101 QSW0451-001 DETECT SW OPEN DETECT
S8102 QSW0451-001 DETECT SW CLOSE DETECT
W 701 QUM154-12Z4Z4 FLAT WIRE
W 821 QJK018-032403 WIRE
W 823 WJK0076-001A E-SI C WIRE C-B CN722
X7001 QAX0401-001 CRYSTAL SUB CLOCK
X7002 QAX0410-001Z CERA LOCK MAIN CLOCK
X7002 QAX0410-001Z CERA LOCK MAIN CLOCK
(Micon board & regurator)
Item
Parts number Parts name Area
Remarks
A
