UX-V30
3-15
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
CN601 QGF1201F3-13 CONNECTOR
CN602 QGF1201F3-10 CONNECTOR
CN603 QGF1016F1-16 FFC/FPC CONNE
CN605 QGA2001C1-06 6P PLUG ASSY
C6001 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C6002 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C6003 NDC21HJ-3R5X C CAPACITOR
C6005 NCS21HJ-331X C CAPACITOR
C6007 NCB21HK-222X C CAPACITOR
C6008 QEKC1HM-105Z E.CAPACITOR 1.0MF 20% 50V
C6009 NCS21HJ-101X C CAPACITOR
C6010 NCB21HK-273X C CAPACITOR
C6011 NCB21HK-222X C CAPACITOR
C6012 NCB21HK-103X C CAPACITOR
C6014 NCB21EK-104X C CAPACITOR
C6015 NCB21HK-223X C CAPACITOR
C6016 NCB21HK-223X C CAPACITOR
C6017 NCB21HK-223X C CAPACITOR
C6018 NCB21HK-222X C CAPACITOR
C6019 NCS21HJ-271X C CAPACITOR
C6020 NCS21HJ-181X C CAPACITOR
C6021 NCS21HJ-821X C CAPACITOR
C6022 QEKC0JM-476Z E.CAPACITOR 47MF 20% 6.3V
C6023 NCB21EK-104X C CAPACITOR
C6028 NCB21EK-473X C CAPACITOR
C6029 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C6031 EEKC1AM-227ZJC E CAPACITOR 220MF 20% 10V
C6032 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C6051 NDC21HJ-120X C CAPACITOR
C6052 NDC21HJ-150X C CAPACITOR
C6053 NCB21HK-223X C CAPACITOR
C6055 NCB21EK-473X C CAPACITOR
C6058 NCS21HJ-6R0X C CAPACITOR
C6061 NCS21HJ-471X C CAPACITOR
C6062 NCB21HK-223X C CAPACITOR
C6063 NCB21HK-223X C CAPACITOR
C6064 NCB21HK-223X C CAPACITOR
C6065 NCB21CK-334X C CAPACITOR
C6071 NCB21HK-222X C CAPACITOR
C6072 NCB21HK-222X C CAPACITOR
C6073 EEKC1AM-227ZJC E CAPACITOR 220MF 20% 10V
C6074 EEKC1AM-227ZJC E CAPACITOR
C6075 NCB21HK-102X C CAPACITOR
C6076 NCB21HK-102X C CAPACITOR
C6077 NCB21HK-223X C CAPACITOR
C6080 EEKC1AM-227ZJC E CAPACITOR 220MF 20% 10V
C6081 EEKC1AM-227ZJC E CAPACITOR
C6083 NCB21HK-223X C CAPACITOR
C6089 NCB21HK-472X C CAPACITOR
C6090 NCB21HK-153X C CAPACITOR
C6091 QEQF1HM-105Z NP E CAPACITOR 1.0MF 20% 50V
C6092 QEQF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C6094 NCB21HK-104X C CAPACITOR
C6096 NCS21HJ-391X C CAPACITOR
C6097 NCS21HJ-391X C CAPACITOR
C6098 NCS21HJ-391X C CAPACITOR
C6099 NCS21HJ-391X C CAPACITOR
C6154 NCS21HJ-151X C CAPACITOR
C6156 NCS21HJ-151X C CAPACITOR
C6157 NCS21HJ-151X C CAPACITOR
C6158 NCS21HJ-151X C CAPACITOR
D6061 1SS355-X DIODE
D6062 1SS355-X DIODE
D6063 1SS355-X DIODE
IC601 AN8806SB-W IC
IC602 LA6541-X IC
IC603 MN35510AL IC
K6051 QQR0621-001Z FERRITE BEADS
Q
6001 2SA1037AK/R/-X TRANSISTOR
Q
6031 2SA952/LK/-T TRANSISTOR
R6001 NRSA02J-123X MG RESISTOR
R6002 NRSA02J-225X MG RESISTOR
R6003 NRSA02J-102X MG RESISTOR
R6005 NRSA02J-274X MG RESISTOR
R6006 NRSA02J-473X MG RESISTOR
R6007 NRSA02J-273X MG RESISTOR
R6008 NRSA02J-564X MG RESISTOR
R6009 NRSA02J-563X MG RESISTOR
R6010 NRSA02J-104X MG RESISTOR
R6012 NRSA02J-103X MG RESISTOR
R6013 NRSA02J-121X MG RESISTOR
R6014 NRSA02J-100X MG RESISTOR
R6015 NRSA02J-120X MG RESISTOR
R6016 NRSA02J-910X MG RESISTOR
R6021 NRSA02J-101X MG RESISTOR
R6022 NRSA02J-101X MG RESISTOR
R6023 NRSA02J-101X MG RESISTOR
R6024 NRSA02J-154X MG RESISTOR
R6025 NRSA02J-104X MG RESISTOR
R6026 NRSA02J-393X MG RESISTOR
R6027 NRSA02J-393X MG RESISTOR
R6028 NRSA02J-393X MG RESISTOR
R6029 NRSA02J-393X MG RESISTOR
R6031 NRSA02J-0R0X MG RESISTOR
R6032 NRSA02J-0R0X MG RESISTOR
R6041 NRSA02J-104X MG RESISTOR
R6042 NRSA02J-472X MG RESISTOR
R6043 NRSA02J-392X MG RESISTOR
R6044 NRSA02J-623X MG RESISTOR
R6045 NRSA02J-433X MG RESISTOR
R6046 NRSA02J-0R0X MG RESISTOR
R6047 NRSA02J-332X MG RESISTOR
R6048 NRSA02J-222X MG RESISTOR
R6049 NRSA02J-152X MG RESISTOR
R6050 NRSA02J-332X MG RESISTOR
R6051 NRSA02J-102X MG RESISTOR
R6052 NRSA02J-102X MG RESISTOR
R6053 NRSA02J-102X MG RESISTOR
R6054 NRSA02J-102X MG RESISTOR
R6055 NRSA02J-102X MG RESISTOR
R6056 NRSA02J-0R0X MG RESISTOR
R6057 NRSA02J-0R0X MG RESISTOR
R6058 NRSA02J-0R0X MG RESISTOR
R6059 NRSA02J-471X MG RESISTOR
R6060 NRSA02J-471X MG RESISTOR
R6061 NRSA02J-104X MG RESISTOR
R6063 NRSA02J-124X MG RESISTOR
R6064 NRSA02J-681X MG RESISTOR
R6066 NRSA02J-220X MG RESISTOR
R6067 NRSA02J-220X MG RESISTOR
R6068 NRSA02J-220X MG RESISTOR
R6069 NRSA02J-155X MG RESISTOR
R6071 NRSA02J-102X MG RESISTOR
R6072 NRSA02J-102X MG RESISTOR
R6076 NRSA02J-0R0X MG RESISTOR
R6080 NRSA02J-0R0X MG RESISTOR
(CD board)
Item
Parts number Parts name Area
Remarks
A
