JVC UX-V30 User Manual

UX-V30
3-18
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 05
A
C 101 NCS21HJ-821X C CAPACITOR 820PF 5% 50V
C 102 NCS21HJ-221X C CAPACITOR 220PF 5% 50V
C 103 QEKJ0JM-227Z E CAPACITOR 220MF 20% 6.3V
C 104 NCB21HK-333X C CAPACITOR .033MF 10% 50V
C 105 NCB21HK-222X C CAPACITOR 2200PF 10% 50V
C 106 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 107 NCS21HJ-561X C CAPACITOR 560PF 5% 50V
C 108 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 109 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 110 NCB21HK-682X C.CAPA. C.M 6800PF 10% 50V
C 111 NCB21HK-122X C CAPACITOR 1200PF 10% 50V
C 112 NCB21EK-683X C CAPACITOR .068MF 10% 25V
C 113 NCB21HK-222X C CAPACITOR 2200PF 10% 50V
C 121 NCS21HJ-331X C CAPACITOR 330PF 5% 50V
C 201 NCS21HJ-821X C CAPACITOR 820PF 5% 50V
C 202 NCS21HJ-221X C CAPACITOR 220PF 5% 50V
C 203 QEKJ0JM-227Z E CAPACITOR 220MF 20% 6.3V
C 204 NCB21HK-333X C CAPACITOR .033MF 10% 50V
C 205 NCB21HK-222X C CAPACITOR 2200PF 10% 50V
C 206 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 207 NCS21HJ-561X C CAPACITOR 560PF 5% 50V
C 208 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 209 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 210 NCB21HK-682X C.CAPA. C.M 6800PF 10% 50V
C 211 NCB21HK-122X C CAPACITOR 1200PF 10% 50V
C 212 NCB21EK-683X C CAPACITOR .068MF 10% 25V
C 213 NCB21HK-222X C CAPACITOR 2200PF 10% 50V
C 221 NCS21HJ-331X C CAPACITOR 330PF 5% 50V
C 301 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 302 NCB21HK-393X C CAPACITOR .039MF 10% 50V
C 303 QEKJ0JM-227Z E CAPACITOR 220MF 20% 6.3V
C 304 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V
C 305 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V
C 306 QEKJ1CM-476Z E CAPACITOR 47MF 20% 16V
C 307 NCB21HK-103X C CAPACITOR .010MF 10% 50V
C 308 NCB21HK-562X C CAPACITOR 5600PF 10% 50V
C 309 NCB21HK-562X C CAPACITOR 5600PF 10% 50V
C 310 NCB21HK-223X C CAPACITOR .022MF 10% 50V
C 311 NCB21HK-682X C.CAPA. C.M 6800PF 10% 50V
C 313 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 314 QCZ0205-155Z ML C CAP I/M 1.5MF
C 315 QCZ0205-155Z ML C CAP I/M 1.5MF
C 316 QFG32AJ-103Z PP CAPACITOR .010MF 5% 100V
C 318 NCB21HK-103X C CAPACITOR .010MF 10% 50V
C 319 QFG32AJ-821Z TF CAPACITOR 820PF 5% 100V
C 321 NCB21HK-103X C CAPACITOR .010MF 10% 50V
C 322 QFG32AJ-152Z M CAPACITOR 1500PF 5% 100V
C 331 QEKJ1CM-476Z E CAPACITOR 47MF 20% 16V
C 351 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C 371 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 374 QEKJ1AM-107Z E CAPACITOR MOTOR +B
C 375 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 376 NCB21HK-103X C CAPACITOR .010MF 10% 50V
CN 31 QGF1205F1-06 CONNECTOR PRI/HEAD
CN 32 QGB2011M1-10 PWB CONECTOR PRI/MECHA
CN 33 QGF1205F1-09 CONNECTOR PRI/MICON
CN 34 QGF1205F1-10 CONNECTOR PRI/AMP
D 301 MA152WA-X DIODE
D 309 MA704A-X S.K.DIODE
D 375 MA3051/M/-X ZENER DIODE
FW 31 QUM024-06A2Z3 EF FLAT
IC 31 BA3126N IC HEAD SW
IC 32 AN7317 IC PB&REC
IC 33 BU4094BCF-X IC
L 301 QQR0620-001 OSC COIL(BIAS)
L 303 QQL01BK-100Z INDUCTOR
Q
101 DTC114TKA-X TRANSISTOR
Q
102 DTC114TKA-X TRANSISTOR REC E
Q
CONT.
Q
201 DTC114TKA-X TRANSISTOR
Q
202 DTC114TKA-X TRANSISTOR REC E
Q
CONT.
Q
301 DTA144EKA-X TRANSISTOR REC E
Q
CONT.
Q
302 2SC2001/K/-T TR I/M
Q
303 2SC2001/K/-T TR I/M
Q
304 2SC2001/LK/-T TRANSISTOR
Q
305 2SC2001/LK/-T TRANSISTOR
Q
306 2SC2412K/RS/-X CHIP TR.C.M
Q
307 2SC2412K/RS/-X CHIP TR.C.M
Q
308 2SC2412K/RS/-X CHIP TR.C.M
Q
309 2SC2412K/RS/-X CHIP TR.C.M
Q
321 DTC144EKA-X TRANSISTOR
Q
323 2SC2412K/RS/-X CHIP TR.C.M
Q
371 2SA952/LK/-T TRANSISTOR MOTER+B
Q
372 DTC124EKA-X TRANSISTOR
Q
375 2SB562/C/-T TRANSISTOR SOLENOID DRIVE
Q
376 2SC2412K/RS/-X CHIP TR.C.M
R 101 NRSA02J-220X MG RESISTOR 22 5% 1/10W
R 102 NRSA02J-182X MG RESISTOR 1.8K 5% 1/10W
R 103 NRSA02J-242NY MG RESISTOR 2.4K 5% 1/10W
R 104 NRSA02J-122X MG RESISTOR 1.2K 5% 1/10W
R 105 NRSA02J-104X MG RESISTOR 100K 5% 1/10W
R 106 NRSA02J-332X MG RESISTOR 3.3K 5% 1/10W
R 107 NRSA02J-123X RES. C.M 12K 5% 1/10W
R 108 NRSA02J-562X MG RESISTOR 5.6K 5% 1/10W
R 109 NRSA02J-122X MG RESISTOR 1.2K 5% 1/10W
R 110 NRSA02J-472X RES. C.M 4.7K 5% 1/10W
R 111 NRSA02J-333X MG RESISTOR 33K 5% 1/10W
R 112 NRSA02J-222X MG RESISTOR 2.2K 5% 1/10W
R 113 NRSA02J-472X RES. C.M 4.7K 5% 1/10W
R 114 NRSA02J-272X MG RESISTOR 2.7K 5% 1/10W
R 116 NRSA02J-102X RES. C.M 1.0K 5% 1/10W
R 121 NRSA02J-102X RES. C.M 1.0K 5% 1/10W
R 201 NRSA02J-220X MG RESISTOR 22 5% 1/10W
R 202 NRSA02J-182X MG RESISTOR 1.8K 5% 1/10W
R 203 NRSA02J-242NY MG RESISTOR 2.4K 5% 1/10W
R 204 NRSA02J-122X MG RESISTOR 1.2K 5% 1/10W
R 205 NRSA02J-104X MG RESISTOR 100K 5% 1/10W
R 206 NRSA02J-332X MG RESISTOR 3.3K 5% 1/10W
R 207 NRSA02J-123X RES. C.M 12K 5% 1/10W
R 208 NRSA02J-562X MG RESISTOR 5.6K 5% 1/10W
R 209 NRSA02J-122X MG RESISTOR 1.2K 5% 1/10W
R 210 NRSA02J-472X RES. C.M 4.7K 5% 1/10W
R 211 NRSA02J-333X MG RESISTOR 33K 5% 1/10W
R 212 NRSA02J-222X MG RESISTOR 2.2K 5% 1/10W
R 213 NRSA02J-472X RES. C.M 4.7K 5% 1/10W
R 214 NRSA02J-272X MG RESISTOR 2.7K 5% 1/10W
R 216 NRSA02J-102X RES. C.M 1.0K 5% 1/10W
R 221 NRSA02J-102X RES. C.M 1.0K 5% 1/10W
R 301 NRS181J-221X MG RESISTOR 220 5% 1/8W
R 303 NRSA02J-393X MG RESISTOR 39K 5% 1/10W
R 304 NRS181J-101X MG RESISTOR 100 5% 1/8W
R 305 NRSA02J-222X MG RESISTOR 2.2K 5% 1/10W
R 306 NRSA02J-222X MG RESISTOR 2.2K 5% 1/10W
R 310 NRS181J-560X MG RESISTOR 56 5% 1/8W
R 311 NRS181J-560X MG RESISTOR 56 5% 1/8W
R 313 NRSA02J-3R3NY RES. C.M 3.3 5% 1/10W
R 314 NRSA02J-223X RES. C.M 22K 5% 1/10W
(Head amp board)
Item
Parts number Parts name Area
Remarks
A
